1610 laser co2 engraver cutter machine for cutting leather fabric with automatic feeder
Product Description
Feature:
1: AUTOMATIC FEEDING
2: PMI square guide rail from Taiwan; lens form USA; Belt from Germany;
percision: 0.05mm
3: Advanced LCD Touch Screen+ USB port+ DSP Offline Control
4: Water Cooling System with Alarm Protection
5: Red dot positioning Synchronize with the laser, which make the operation more convenient.
Detailed Images
Specializing in the processing of fabrics with laser machines, the co2 laser machine can add a auto feeding system, this can improve work efficiency.
RD control system
This control system is very easy learn and operate. It support for multiple languages, for example English, Russian, French, Portuguese, Spanish, German, Turkish,.... And many new features, for example automatic focus (easy operate), parameter adjustment, add Z and U keys (easy to install this conveyor system),....
Reci laser tube
This machine used Reci laser tube, It is famous brand in world. Its life time is 1000H, can be use 3-4 years. For the laser tube, we provide 12 months warranty.
This machine used Reci laser tube, It is famous brand in world. Its life time is 1000H, can be use 3-4 years. For the laser tube, we provide 12 months warranty.
Laser head:
This is laser head, used to cut and engrave non-metal material.
This is laser head, used to cut and engrave non-metal material.
Water chiller
Used for cooling machine, usually, It is necessary when machine power up 100W. (If machine with 80W power, water pump is enough.)
Used for cooling machine, usually, It is necessary when machine power up 100W. (If machine with 80W power, water pump is enough.)
Optional parts:
1. An extra laser tube (Laser tube is consumable, warranty is 3000 working hours.)
2. Motorized up and down platform(Cut or engrave more thick materials)
3. Rotary attachment (Cut or engrave cylindric materials)
4. Ruida controller
5. Servo motor, imported from Japan
6. CW 5000/5200 water chiller (Cooling performance better than water pump)
7. Auto-feeding device ( For fabric, leather and more longer materials cut and engrave)
2. Motorized up and down platform(Cut or engrave more thick materials)
3. Rotary attachment (Cut or engrave cylindric materials)
4. Ruida controller
5. Servo motor, imported from Japan
6. CW 5000/5200 water chiller (Cooling performance better than water pump)
7. Auto-feeding device ( For fabric, leather and more longer materials cut and engrave)
Product Paramenters
Machine Description: | GC-1610 | Options |
Working size: | 1600*1000mm | custormizable |
Laser power: | 80W | 40w-150w |
Laser tube: | Co2 sealed glass laser tube | RECI laser tube |
Engraving speed | 0-1500mm/s | |
Cutting speed: | 0-800mm/min | |
Repeating location: | ±0..05mm | |
Resolution ratio: | 0.025mm | |
Minimum shaping character | English Letters 1 x 1mm | |
Highest scanning precision | 2000DPI | |
Laser output control | 1-100% software setting | |
Control system | DSP control system | |
Interface | USB | |
Software supported | Coreldraw Phototshop ,Autocad output | |
Support graphic format | DST, PLT, BMP, DXF AI,CDR | |
Cooling system | water-cooling and protection system | industrial Chiller |
Driving system | Stepper motor | serve motor |
Exhaust system | exhaust fan and air pump | |
Offline work: | support | |
Working voltage: | AC100V-220V±10%,50-60HZ | 3800V/60Hz |
Operating temperature: | 0-45°C | |
Operating humidity: | 5%-95% free of condensed water |
Advantage:
1. Beijing Reci laser tube (the best brand in China).
2. Auto-feeding system, need one people operate
3. Adopt Taiwan Hiwin linear motion guide
4. Transmit files directly in CorelDraw, AutoCAD ,etc.
5. Owns functions of restoring from power off, continuation on break point
6. Easy operating control panel
7. Water chiller to protect the laser tube
8. Suitable for fabric, jeans, leather, clothes, garment, textile, etc
9. Powercut control card with rich functions both can engrave and cut on various materials
10. Servo Motors, fast speed ( can up to 700mm/s)
2. Auto-feeding system, need one people operate
3. Adopt Taiwan Hiwin linear motion guide
4. Transmit files directly in CorelDraw, AutoCAD ,etc.
5. Owns functions of restoring from power off, continuation on break point
6. Easy operating control panel
7. Water chiller to protect the laser tube
8. Suitable for fabric, jeans, leather, clothes, garment, textile, etc
9. Powercut control card with rich functions both can engrave and cut on various materials
10. Servo Motors, fast speed ( can up to 700mm/s)
Application
Applicable Materials:
Cotton cloth, linen cloth, leather, paper, chemical fiber and other textile and garment fabrics
Application Industries:
Clothing, footwear, home textiles, embroidery, toys, leather, bags and suitcases, umbrellas and other industries
Cotton cloth, linen cloth, leather, paper, chemical fiber and other textile and garment fabrics
Application Industries:
Clothing, footwear, home textiles, embroidery, toys, leather, bags and suitcases, umbrellas and other industries
After Sales Service
* Pre-sale and In-sale
Consulting service, sample’s process experiment, equipment selection, training to the engineers and the user of the buyer.
Training:
After the acceptance check by the buyer, we offer training and maintenance guidance.
Training content:
1.Laser safety protection knowledge, the basic principles of lasers and laser marking machine construction.
2.Control system operating skills, equipment operation and precautions.
3.Equipment routine maintenance, laser adjustment and parts replacement operation skills.
* After-sale:
1.24 months guarantee for whole machine free of charge, except tube and lens 10 months
2.Perfect 7*24 hours technical support by e-mail
3.Calling or online service, professional training to your workers
4.Use friendly English software, user manual and detailed Videos/CD
5.Priority to become our agent in your city,we offer you our factory price
Consulting service, sample’s process experiment, equipment selection, training to the engineers and the user of the buyer.
Training:
After the acceptance check by the buyer, we offer training and maintenance guidance.
Training content:
1.Laser safety protection knowledge, the basic principles of lasers and laser marking machine construction.
2.Control system operating skills, equipment operation and precautions.
3.Equipment routine maintenance, laser adjustment and parts replacement operation skills.
* After-sale:
1.24 months guarantee for whole machine free of charge, except tube and lens 10 months
2.Perfect 7*24 hours technical support by e-mail
3.Calling or online service, professional training to your workers
4.Use friendly English software, user manual and detailed Videos/CD
5.Priority to become our agent in your city,we offer you our factory price
