5 Ton 2 Ton 4WD Mini wheel Dumper Truck for mining canter construction work
Model | FCY-10 | FCY-20 | FCY30 |
Performance |
|
|
|
Rated Loading Weight | 1000KG | 2000KG | 3000KG |
Bucket capacity | 0.5 | 1. 2m3 | 1.50m3 |
Wheel base | 1700 | 1280mm | 1360mm |
Thread | 1300 | 1500mm | 1960mm |
Gradeability | 21 | 21 | 21 |
Overall dimensions | 2600*1450*2050mm | 3017x1900x2465mm | 3650x1800x2550mm |
Mini turning radicus | 3500 | 4000mm | 4000mm |
Walking speed |
|
|
|
Forward gear 1 | 6.5km/h | 6.5km/h | 6.5km/h |
Forward gear II | 11km/h | 11km/h | 11km/h |
Forward gear III | 24km/h | 24km/h | 24km/h |
Backward gear | 4.5km/h | 4.5km/h | 4.5km/h |
Engine |
|
|
|
Engine model | ZS1100 | CHANGCHAI390 | Quanchai490 |
Engine type | 3 cylinders | 3 cylinders | 4 cylinders |
Cooler type | water | water | Water cooler |
Rated power | 12.1KW | 20KW | 38KW |
Tire size | Front tire 750-16 | 825-16 | 20.5/70-16 |
Model | FCY50 | FCY70 |
Performance |
|
|
Rated Loading Weight | 5000kg | 7000kg |
Bucket capacity | 2.5CBM | 3.5 m3 |
Wheel base | 2000mm | 2200 mm |
Thread | 1580mm | 1580 mm |
Gradeability | 21 | 21 |
Overall dimensions | 4300*1920*2650MM | 5250*2250*2700 mm |
Mini turning radicus | 4000MM | 4000MM |
Walking speed |
|
|
Forward gear 1 | 6.5km/h | 6.5km/h |
Forward gear II | 11km/h | 11km/h |
Forward gear III | 24km/h | 24km/h |
Backward gear | 4.5km/h | 4.5km/h |
Engine |
|
|
Engine model | Weichaihuafeng 4102 | Yuchai 60kw engine |
Engine type | 4 cylinders | 4 cylinders |
Cooler type | Water cooler | Water cooler |
Rated power | 47kw | 60kw |
Tire size | 14-17.5 | 16/70-20 |
Dimensions | 1250*700*1100mm | 1450*780*1100 |
product weight | 130kg | 75KG |
Safe load | 600-700kg | 600-700KG |
Gradeability | 35° | 0-45° |
operating hours | 8-10h | 8-10h |
Charging time | 8h | 7-8h |
battery | 48V20AH*4 | 48V20AH*4 |
Motor | 800W | 800W |
1.Hydraulic steering,can unload materials smoothly by strong hydraulic pressure unloading system.
2.Low walking speed,short-distance transport of bulk materials.
3.Easy operation,small turning radius can be used in a narrow environment.
4.With self loading bucket can realize the multiple function tools. With full seal cabin optional.
5.Off road wider types as option ,can work in muddy and bumpy roads.
6.With bucket 180 rotate can realize side dumping and dumping in each direction can have high efficiency working.
As a low-volume, short-distance transport of bulk materials for small site dumpers. Dumpers are widely used in many different occasions, such as the construction industry, the factory floor, battlefield ,protecting road section, the municipal engineering, underground mines and so on.
Jining Aowei Machine Co., Ltd. is a modern enterprise which is specialized in producing all kinds of Mini excavators,Road rollers,Self Dumpers ,Skid steer loaders, wheel loaders, Tractors and Forklifts etc. Our products are exported to clients in such countries and regions as United States, Southeast Asia, Australia, Europe, Russia, the Middle East, Africa. We also welcome OEM and ODM orders.
Our company locates in Jining city, Shandong province, which is the "Home of Confucius and Mencius, the State of Etiquette”,and also Jining is one of four Chinese construction machinery bases famous of Shantui and Komatsu brand. Our company offers bulk export processing trade products, and other services to meet customer's needs.We hope to cooperate with you mutual success and we can be your trustworthy friend in the future!
