1300ml/h Lab Powder Granulating and Aqueous Spray Drying Machine

Spray Dryer For Water Soluble Samples ADL311-A

Product Summary:

Feature:

Easy setup, easy operation

Suitable for heat sensitive samples. High heat is not directly applied to dry, fine powder

Obtain contaminant free fine powder which is not oxidized and contains minimal moisture

Direct drying of solution or solution liquid into fine powder. No pre- or post processes such as filtration, separation, or pulverization required

Easy operation with one-touch detachable mechanism for drying chamber and cyclone

Unique peristaltic pump, nozzle cooling mechanism, pulse jet mechanism and a nozzle knocker for stable spray drying

An arm jack is equipped as standard for easy installation and removal of glassware attachment

A service outlet (max.2A) and a sample stand are equipped as standard for connecting a magnetic mixer for stirring suspended liquid samples

Specifications:

Specifications

Model

ADL311-A

Sample Type

For aqueous soluble samples

Temp. adjusting unit setting range

inlet temp: 40 to 220 °C; outlet Temp: 0 to 60°C

Temperature adjusting accuracy

Inlet temperature 1 °C

Drying air amount adjusting range

0-0.7m3 / min

Spray air pressure adjusting range

0-0.6 MPa

Liquid evaporation range

0-1300 ml/h

Spray air line washing function

Spraying at the nozzle tip, manual pulse jet system

External output

Inlet temperature, outlet temperature, temperature outlet ( 4-20 mA)

Temperature adjusting device

PID digital temperature adjusting device

Touch panel

Blower, heater, liquid sending pump, pulse jet switch, error display

Control select switch

Inlet temperature, outlet temperature control switch (Outlet temp. control is conditional.)

Temperature sensor

K-thermocouple

Heater

2.0 kW at 200V to 2.88 kW at 240V

Liquid sending

Fixed amount peristaltic pump

Spraying air pump

Spraying air compressor (sold separately) is used

Service outlet

For stirrer: AC100V, MAX: 2A

 Suction blower

Bypass blower

 Filter

Suction filter, exhaust filter

 Recovery of solvent

None

 Spray nozzle cooling mechanism

Connector: nipple * 2, O.D.: 10.5 mm

 Spray air connection diameter

Nipple diameter: 7 mm

 Spray air pressure

Bourdon tube: 0.3 MPa

 Exhaust connecting diameter

 50mm

 Safety function pharmaceutical

Inlet/outlet temperature overheat, sample feed reverse rotation mechanism, over current electric leakage breaker, nozzle connection error

 External dimensions (W*D*H)

580*420*1125 mm

 Power Source

AC110V / AC220V Single phase

 Weight

80kg
