Высокоэффективная домашняя солнечная панель цена 570Wp 580Wp 590Wp для дома
0,10-0,12 $
Morelsolar JA Trina солнечная панель 360 Вт 370 375 380 400 410 445 450 455 500 моно солнечные панели
- Категория: >>>
- Поставщик: Jiangsu Morel Energy Co. Ltd.Jiangsu Ltd.
Сохранить в закладки 1600173744600:
Описание и отзывы
Характеристики
Product Description
ELECTRICAL DATA @STC | Trina-435MBB | Trina-440MBB | Trina-445MBB | Trina-450MBB | Trina 455MBB | |
Peak Power Watts-Pmax(Wp) | 435 | 440 | 445 | 450 | 455 | |
Power Output Tolerance-Pmax(W) | 0-+5 | 0-+5 | 0-+5 | 0-+5 | 0-+5 | |
Maximum Power Voltage-Vmpp(V) | 40.5 | 40.7 | 40.8 | 41.0 | 41.4 | |
Open Circuit Voltage- Voc (V) | 10.74 | 10.82 | 10.90 | 10.98 | 11.00 | |
Open Circuit Voltage-Voc(V) | 49.0 | 49.2 | 49.4 | 49.6 | 49.6 | |
Short Circuit Current-Isc(A) | 11.31 | 11.39 | 11.46 | 11.53 | 11.54 | |
Module Efficiency nm(％） | 19.7 | 19.9 | 20.2 | 20.4 | 20.6 |
STC:Irradiance 1000w/m²，Cell Temperature 25℃，Air Mass AM1.5 according to EN 60904-3.
Average efficiency reduction of 4.5％ at 200 W/m² according to EN 60904-1.
ELECTRICAL DATA @NOCT | PHC-430MBB | PHC-435MBB | PHC-440MBB | PHC-445MBB | PHC- 450MBB |
Maximum Power-PMAX(Wp) | 318.3 | 322 | 325.8 | 329.8 | 333.2 |
Maximum Power Voltage-Vmpp(V) | 37.48 | 37.68 | 37.88 | 38.07 | 38.26 |
Maixmum Power Current-Impp(A) | 8.48 | 8.54 | 8.59 | 8.64 | 8.7 |
Open Circuit Voltage-Voc(V) | 45.88 | 46.08 | 46.28 | 46.52 | 46.76 |
Short Circuit Current-Isc(A) | 9 | 9.06 | 9.11 | 9.16 | 9.22 |
NOTC:Irradiance at 800W/m²，Ambient Temperature 20℃.Wind Speed 1 m/s.
MECHANICAL DATA | ||||||||
Solar Cells | 9BB Mono PERC 166×83mm | |||||||
Cell Orientation | 144 cells(6×24） | |||||||
Module Dimensions | 2111*1046*30mm | |||||||
Weight | 28.6kg | |||||||
Glass | High Transparency,Anti-Refiective,AR Coated and Heat Tempered Solar Glass-3.2mm | |||||||
Backsheet | White | |||||||
Frame | Silver Anodized Aluminium Alloy (Black Available) | |||||||
J-Box | IP 68 rated | |||||||
Cables | Photovoltaic Technology cable 4.0mm²，1200mm | |||||||
Connector | MC4 Compatible | |||||||
Recommend Products
Why Choose Us
100% Cells Sorting
Ensure Colour and Power Difference.
Ensure high yields,consistent performance and durability,
First of 52 steps strict quality control and inspection process.
Before and After Lamination.
Most stringent acceptance criteria and tightest tolerance,
Intelligent alarm and stop mechanism in case of any deviation or errors.
Before and Following Lamination
Ensure "Zero" micro crack monitoring before final inspection, Continuous line monitoring and video/photo record for each cell and
panel
100% "Zero"
Defects Objective Before Shipment.
Most stringent acceptance criteria and tightest tolerance,
Ensure the best modules on the market- guaranteed!
Defects Objective Before Shipment.
Most stringent acceptance criteria and tightest tolerance,
Ensure the best modules on the market- guaranteed!
Ensure 3% Positive Power Tolerance
Comprehensive QC information management system with barcode ID.Quality traceable system in place to allow quality data flow
constantly.
Product packaging
Our factory
Project case
300kw on grid solar system in Germany
1.5MW on grid solar system in Mexico
FAQ
Q1: How to choose a right system and products?
A1:Tell us your requirements, then our seller will recommend a suitable product and system to you.
Q2: The advantages of home photovoltaic system
A2: Solar photovoltaic power generation performance is stable and reliable, with a service life of more than 25 years;Small
investment, big income;zero pollution;Low maintenance costs;
Q3: Why choose us?
A3: SUVPR have been engaged in new energy power generation for more than 20 years. Our products and services cover more than 60
countries. Our R&D team is composed of top experts in various fields. We are committed to providing first-class solutions for PV
power plants.
Q4: What is the warranty of solar system?
A4: 5 years for whole system,10 years for inverter,modules,frame.And we can make sure our products will through very strictly
testing,and then send to you.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.And we have offices in many
countries,if you have problems,we can arrange people to help you solve problem.
Q6:What about the package?
A6:Strict double-layer packaging design,Rigorous vibration testing.Ensure that the product is not damaged during transportation.
A1:Tell us your requirements, then our seller will recommend a suitable product and system to you.
Q2: The advantages of home photovoltaic system
A2: Solar photovoltaic power generation performance is stable and reliable, with a service life of more than 25 years;Small
investment, big income;zero pollution;Low maintenance costs;
Q3: Why choose us?
A3: SUVPR have been engaged in new energy power generation for more than 20 years. Our products and services cover more than 60
countries. Our R&D team is composed of top experts in various fields. We are committed to providing first-class solutions for PV
power plants.
Q4: What is the warranty of solar system?
A4: 5 years for whole system,10 years for inverter,modules,frame.And we can make sure our products will through very strictly
testing,and then send to you.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.And we have offices in many
countries,if you have problems,we can arrange people to help you solve problem.
Q6:What about the package?
A6:Strict double-layer packaging design,Rigorous vibration testing.Ensure that the product is not damaged during transportation.
Certifications
