Высокомощная фотоэлектрическая солнечная панель 540 Вт монокристаллическая 545
- Категория: Солнечные панели >>>
- Поставщик: S K Tech Co. Ltd.S Ltd.
Сохранить в закладки 1600180386894:
Описание и отзывы
Характеристики
Products Description
IP68 junction box, connector
IP68 junction box and connector have a high degree of waterproof, effectively resist the harsh environment;
PID Resistant
Excellent PID resistance at 96 hours (85℃/85%) test,and also can be improved to meet higher standards
for the particularly harsh environment;
10BB half-cut cell technology
New circuit design, lower internal current, lower Rs loss
Significantly lower the risk of hot spot
Special circuit design with much lower hot spot temperature
Lower LCOE
2% more power generation, lower LCOE
IP68 junction box and connector have a high degree of waterproof, effectively resist the harsh environment;
PID Resistant
Excellent PID resistance at 96 hours (85℃/85%) test,and also can be improved to meet higher standards
for the particularly harsh environment;
10BB half-cut cell technology
New circuit design, lower internal current, lower Rs loss
Significantly lower the risk of hot spot
Special circuit design with much lower hot spot temperature
Lower LCOE
2% more power generation, lower LCOE
Electrical Characteristics(STC) | ||||||||||||
Module Type | 525-144M | 530-144M | 535-144M | 540-144M | 545-144M | 550-144M | ||||||
Rated output(Pmp/Wp) | 525 | 530 | 535 | 540 | 545 | 550 | ||||||
Maximum power voltage(Vmp/V) | 40.6 | 40.8 | 41 | 41.2 | 41.4 | 41.6 | ||||||
Maximum power current(Imp/A) | 13.71 | 13.76 | 13.05 | 13.11 | 13.17 | 13.23 | ||||||
Open circuit voltage(Voc/V) | 48.8 | 49.0 | 49.2 | 49.4 | 49.6 | 49.8 | ||||||
Short circuit current (Isc/A) | 12.94 | 13.0 | 13.81 | 13.87 | 13.93 | 13.99 | ||||||
Module efficiency (%) | 20.2% | 20.4 | 20.6% | 20.8% | 21% | 21.2% | ||||||
Power tolerance (W) | 0~+5 | |||||||||||
Maximum systems voltage | 1000V/1500V DC | |||||||||||
Maximum series fuse | 25A | |||||||||||
Standard Test Condition（STC）: Irradiance 1000W/m², Cell Tempera ture 25℃, AM1.5 | ||||||||||||
Product Display
Glass
*Anti-reflective glass
*High-transmittance and low reflection Increase model efficiency
*High mechanical strength
*High-transmittance and low reflection Increase model efficiency
*High mechanical strength
Solar Cell
*High model efficiency up to 20% *High shunt-resistance: adapt the several environmental conditions
*High PID resistant
* Low breakage rate
*Uniform color
*High PID resistant
* Low breakage rate
*Uniform color
Frame
*Optional silvery or black frame
* Tensile Strength Frame
*Boost bearing capability and prolong service life
* Tensile Strength Frame
*Boost bearing capability and prolong service life
Junction Box
*Waterproofness Junction Box
*Innovative Full-Glue-Filled Combination of series circuit and parallel circuit, reduced internal power loss Quality diode ensures module running safety
*Heat dissipation
*Long service life
*Innovative Full-Glue-Filled Combination of series circuit and parallel circuit, reduced internal power loss Quality diode ensures module running safety
*Heat dissipation
*Long service life
Product Data
Lower EPC Cost
Comparing with normal ribbon,using TR module can save ＞1.2% EPC cost.
Frame Design - Higher structure strength
Framed modules are less prone to bending and cracking during transportation and installation than frameless ones.
Superior stain resistance
The hydrophobic surface of the transparent DuPont Tedlar film backsheet outer layer, offers excellent anti-staining performance,making cleaning of the modules easier, and reducing O&M costs and reducing water waste.
Product Details
Product packaging
Note: The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.
Production & QC
Manufacturing systems are equipped with sophisticated scheduling and dispatching capabilities, automated material handling functionality, automated manufacturing systems, and smart devices utilization.
All cells and modules must past through a list of 48 different tests to ensure that the visual, optical, electrical, physical, and mechanical properties of the products meet high standards before reaching customers
Company Profile
♦ Founded in 2012 , 150MW solar panel production capacity , millions of battery, charge controller and inverter production capacity
♦ Products are exported to more than 150 countries
♦ Products are certified by TUV(Germany) , ETL(America) ,CE
♦ Turn-key solar systems are offered , to save the time and money for the clients
♦ Rich experience in overseas construction of solar projects
♦ Products are certified by TUV(Germany) , ETL(America) ,CE
♦ Turn-key solar systems are offered , to save the time and money for the clients
♦ Rich experience in overseas construction of solar projects
Project Case
Certifications
