Vertical connection Stainless steel carbon pneumatic ball valve for oil and gas recovery system

The pneumatic two-stage control valve provides a three-position operation mode of 0°-45°-90° or 0°-90°-180°. The middle position is achieved by the movement of two auxiliary pistons to generate a mechanical brake. This middle position is adjustable, such as the 900 stroke actuator can provide 20°, 30°, 50°, 75° and other intermediate positions.

1.It can realize multi-position action control functions such as opening and closing of the valve for two sections, opening of the second section of the second section, and opening of the third section of the third section.
2.The speed of the on-off valve is adjustable;
3.The valve is opened and the valve opening degree is adjustable;
4.Automatic and manual control;
5.Safe return (FC/FO) for gas shutoff/de-energization;
6.Meet APl607 fire protection, APl6D anti-static requirements

Solenoid valves S1, S2 use 2-position 5-way solenoid valve, position as above
NSS1: 220VA or 24VDC relay output contact control S1
NSS2: 220VA or 24VDC relay output contact control S2

Electro hydraulic valve structure diagram

Diagram of oil depot

The action process is as follow

Main technical parameters and configuration, installation dimensions

Pneumatic control ball valve selection

HUBEI HONGYI ELECTRONIC&TECHNOLOGY CO.,LTD,in 2009,which covers an area of more than 3500 m2,has 4standard plants of over 6000 m2 in area,in which ,the building area of the office building ,R&D center,etc.is about 4500 m2,has more than 100 sets of nc press,nc bending machine,prectreatment system and spraying equipment that are the most advanced in china,a complete set of advanced online flow calibration system as well as a number of instrument and electronics testing equipment.We also lay emphasis on cooperation with the domestic and foreign excellent industrial control manufactures,and have established cooperation relationship with the design institutes of the Ministry of Chemical industry as well as the electronic control institutes of a number of universities.Through these cooperators,by combining our core products,we provide the users with the best system solutions.
