Product Overview
waste bottle pet crushing washing drying line
This waste bottle pet crushing washing drying line is designed and manufactured by MOOGE TECH, which is widely used for waste plastic PET material, such as water bottles, pet sheet, pet containers, etc.The waste dirty pet bottle go through de-labelling, crushing, washing, drying, and collecting process will turn to be clean pet flakes for reuse.
This pet bottle recycling machine can be displayed "L" or "U" shape according to clients' workshop.
We can also customize the washing line components according to client's material and product requirement.
Final Product---Clean PET Flakes
Flakes Size: 10-12mm
Moisture Content: <1%
PVC Content<150ppm
Non-PET Content<150ppm
Color<200ppm
Intrinsic Viscosity>0.7
PH: 7.5+/-0.5
Suitable used for: Polyester/ PET strapping/ PSF/ PET Sheet
Product Specification
Model | Capacity | Installed Power | Steam Use | Water Supply | Area Requied |
MT-500 | 500 kg/hr | 185 KW | Optional Choose | 4-5 m3/hr | 55*3.5*4.5 m |
MT-1000 | 1000 kg/hr | 315 KW | Optional Choose | 5-6 m3/hr | 62*5*4.5 m |
MT-2000 | 2000 kg/hr | 450 KW | Suggest Use | 10-15 m3/hr | 80*6*5 m |
MT-3000 | 3000 kg/hr | 600 KW | 80000 Kcal | 20-30 m3/hr | 100*8*5.5 m |
MT-4000 | 4000 kg/hr | 800 KW | 100000 Kcal | 30-40 m3/hr | 135*8*6.5 m |
MT-5000 | 5000 kg/hr | 1000 KW | 120000 Kcal | 40-50 m3/hr | 135*8*6.5 m |
Machine Details
Bale Opener
Function: Opening the plastic bottle bales and scatter the bottlesTrommel Machine
Function: Loosen the bottles, remove the sand or stone from bottles, feeding out bottles constantlyLabel Remover Machine
Function:Remove out the labels from the waste PET bottles
Pre-washer Machine (Optional)
Function: With water to pre-wash the bottles and remove out the dirtySorting Belt (with high platform)
Function: Sorting out the remain labels manually, selecting out different color and Non-PET bottlesPlastic Crusher Machine
Function: Crushing the bottles into small flakes, wet working with waterFloating Washing Tank
Function: Washing out the floating caps, rings and dirty from bottle flakesHot Washer Tank
Function: With hot water and chemical reagent to wash off the oil, glue, dirtyHorizontal Dewatering Machine
Function: Remove out the water from the bottle flakesPipe Drying System
Function: With hot air drying the bottle flakesZig-zag Air Classifier
Function: Remove residual fines, dust, labelsColor Sorter (Optional)
Function: Sorting out different color of flakesCustomer Onsite
MT-1000 PET Washing Line in Korea
MT-3000 PET Washing Line in Turkey
MT-2000 PET Washing Line in South Africa
MT-4000 PET Washing Line in Algeria
Related Product
We also supply plastic strap production line which is mainly used to make different sizes of pet straps with virgin or recycled pet flakes.
PET packing strap is widely used to replace the steel strap for packing carton, wooden case, etc. It is popular with its good tensile strength, non-rustiness, and low use-cost.
PET packing strap is widely used to replace the steel strap for packing carton, wooden case, etc. It is popular with its good tensile strength, non-rustiness, and low use-cost.
With this plastic strap production line, we can achieve the purpose of protecting our environment by reusing the waste plastic.
Packing & Delivery
• For the loose cargo we will packing by wooden box.
• For the full container loading we are packing the machine by film and some on pallet accordingly.
• We can also ship the goods by air or by sea as buyer request.
• We will send pictures of cargo loading to our client to check and keep recording.
• We can send cargo to client's warehouse to loading.
• For the full container loading we are packing the machine by film and some on pallet accordingly.
• We can also ship the goods by air or by sea as buyer request.
• We will send pictures of cargo loading to our client to check and keep recording.
• We can send cargo to client's warehouse to loading.
Company Profile
We attend the Chinaplas Exhibition every year (In Shanghai and Guangzhou) and take with our machine for test run at the booth. Besides, we also attend the plastic exhibition in other countries such as Mexico, Turkey, Egypt, Russia, Malaysia, etc. Please kindly contact with us in advance if you also have time to attend, Sincerely welcome to our booth for visit and discuss about detailed issues.
Our Service
• Pre-sale: we provide our client the detailed technical offer, the sales contract etc.
• In-sales: we supply the machine layout, installation instruction, and technician support for the clients.
• After sales: we arrange engineer to install the machine and train the workers for our client.
• We have 24 hours service line to solve the after sales problem.
• We have free spare parts with the machine.
• We supply long term spare parts for every customer.
• We always update the new technology to every customer.
In order to match your requirement and provide you a proper offer, please advise:
• What material do you want to recycling? PE film/PP bag? HDPE/PP bottle? PET bottles? or other plastic?
• What capacity(kg/h) do you want? such as 500kg/hr or 1000kg/hr?
• What is the final size(mm) of flakes you want?
• Other special requirements about the waste bottle pet crushing washing drying line if you have?
• In-sales: we supply the machine layout, installation instruction, and technician support for the clients.
• After sales: we arrange engineer to install the machine and train the workers for our client.
• We have 24 hours service line to solve the after sales problem.
• We have free spare parts with the machine.
• We supply long term spare parts for every customer.
• We always update the new technology to every customer.
In order to match your requirement and provide you a proper offer, please advise:
• What material do you want to recycling? PE film/PP bag? HDPE/PP bottle? PET bottles? or other plastic?
• What capacity(kg/h) do you want? such as 500kg/hr or 1000kg/hr?
• What is the final size(mm) of flakes you want?
• Other special requirements about the waste bottle pet crushing washing drying line if you have?
