(High Recovery Rate) JT5-2 JT2-2 Jig Concentrator Small Gold Tailing Concentrator Diamond Washing Tungsten Jig Machine
Jig Machine Features:
1.High capacity, high concentration ratio and high recovery ratio.
2.Fabricated with highest quality material
3.Easy to install, operate and maintain
4.Water conservation ,Saving water 30-40% than ordinary jig.
5.The pulsation speed very easy adjusted by regulator
6.Suitable to separate out big and small size heavy minerals.
1.High capacity, high concentration ratio and high recovery ratio.
2.Fabricated with highest quality material
3.Easy to install, operate and maintain
4.Water conservation ,Saving water 30-40% than ordinary jig.
5.The pulsation speed very easy adjusted by regulator
6.Suitable to separate out big and small size heavy minerals.
The Main Products we can supply: Material Hopper,Jaw Crusher,Hammer Mill,Hammer Crusher,Cone Crusher,Impact Crusher,Double Roller Crusher,Trommel Screen,Trommel Scrubber,Vibrating Screen,Ball Mill,Wet Pan Mill,Spiral Classifier,FX Hydrocyclone,Agitation Tank,Flotation Separator,Shaking Table,Spiral Chute,Jig Machine,Roller Magnetic Separator, 3 Disc Magnetic Separator,Thickener,Filtering Equipment,Drying Equipment,High Frequency Gold Melting Furnace, Medium Frequency Gold Melting Furnace etc
When you find us, you have find the Best Gold Mining Processing Solution Manufacturers.
Jig separator Machine is one energy-saving gravity separation equipment ,It used mainly in the mining industry for mineral processing, to separate particles within the ore body, based on their specific gravity.
1.Details Applications:
Rectangular gold jigs are made of either a single 1 jig-cell as stand-alone, or a series of cells organized in modules of two, three or four cells. The popular one is 2 cells.
In a multiple-cell jig design/setup, the rejected tailings from the front cell passes thru as feed to the following second cell compartment. Tailing from the second cell vessel is feed to the 3rd cell and on down the bank.
Ordinarily, roughing duty is done using three or four cell modules. The double or two-cell arrangement that is commonly called the duplex is ordinarily confined to secondary circuits and cleaning systems.
Saw tooth wave jig belongs to gravity-based equipments, which can separate mineral based on different specific gravity. saw-tooth wave jig is mainly consist of tyhree parts: main frame, driving set and jigging chamber.
It is widely used to separator tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other minerals.
There are many applications where the jig separator of particular value and cannot be equaled for economical and efficient performance. They are effective in processing precious and base metal, raremetal and non-metallic minerals.
There are many applications where the jig separator of particular value and cannot be equaled for economical and efficient performance. They are effective in processing precious and base metal, raremetal and non-metallic minerals.
2.Description of our Jigging Separator:
The gold jigging is a simple gravity separation metallurgy machine as it's essentially an open tank filled with water with a slightly inclined screen at the top and provided with a spigot on the underside for drawing off the concentrate.
Rectangular gold jigs are made of either a single 1 jig-cell as stand-alone, or a series of cells organized in modules of two, three or four cells. The popular one is 2 cells.
In a multiple-cell jig design/setup, the rejected tailings from the front cell passes thru as feed to the following second cell compartment. Tailing from the second cell vessel is feed to the 3rd cell and on down the bank.
Ordinarily, roughing duty is done using three or four cell modules. The double or two-cell arrangement that is commonly called the duplex is ordinarily confined to secondary circuits and cleaning systems.
Saw tooth wave jig belongs to gravity-based equipments, which can separate mineral based on different specific gravity. saw-tooth wave jig is mainly consist of tyhree parts: main frame, driving set and jigging chamber.
Model | Area (m²) | Feed Size (mm) | Water Added (m³/t) | Water Pressure (MPa) | Capacity (t/h) | Power (kw) | Dimension (mm) | Weight (kg) |
JT0.57-1 | 0.57 | <6 | 1-2 | ≥0.05 | 1-3 | 1.5 | 1550x780x1530 | 610 |
JT1-1 | 1.04 | <10 | 2-3 | ≥0.05 | 2-4 | 2.2 | 2270x1110x1890 | 900 |
JT2-2 | 2.28 | <10 | 2-4 | ≥0.05 | 4-8 | 3 | 3225x1550x2050 | 1640 |
JT3-1 | 3.3 | <10 | 3-6 | ≥0.05 | 6-10 | 5.5 | 2745x2000x3030 | 3260 |
JT4-2 | 4.33 | <25 | 4-8 | ≥0.05 | 10-15 | 7.5 | 4240x1990x2750 | 4200 |
JT4-2A | 4.33 | <25 | 4-8 | ≥0.05 | 10-15 | 4×2 | 4240x1990x2750 | 4200 |
JT5-2 | 4.86 | <10 | 3-6 | ≥0.05 | 12-20 | 7.5 | 3600x2000x2600 | 4500 |
Package and Delivery
1.Standard parts packed in the wooden cases.2.Big parts packed by plastic membrane.
3.The whole machine is loaded in the container.
Q: 1.What is your machine used for ?
A: Our Jigging Machine was used to separator tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other minerals.
Q: 2.Are you factory or trade company?
A: Yes dear,we are the Professional manufacturer from 1985.So we could give you original factory price than those trade companies.
We're also warmly welcome you to visting and inspection our factory at any time,Please Call at +86-18870736160
Q: 3.Can I operate it well, if I have no experience?
A: Do not worry! Our machines is designed to use easily.You are welcome to visit our company to be trained here,And we could arrange the engineer to go to your country/company to train your workers directly as your requested and the relative travel cost will be on your account.
Q: 4.Can you send me the video to show how the machine works?
A: Surely.we have made video of every machine,so if you need we can send for you to checking in clearly.
Q: 5. What should I take care when using the machine?
A: Please using the machine in regular and Keeping the machine away from thinner and other chemical liquid.
Q: 6.How about your Service ?
A: All of our machines have one year warranty and Wholelife Technology support to make sure your machine work well.
Q: 7.How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: 8.What about the payment method?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q:9 What's Information we need from your side ?
A: What kind of ore do you want to process ? The Capacity per hour do you need ? and the Max feeding size of your material ?
A: Our Jigging Machine was used to separator tungsten, tin, gold, red iron, brown iron, manganese, titanium, antimony, lead, tantalum, niobium and other minerals.
Q: 2.Are you factory or trade company?
A: Yes dear,we are the Professional manufacturer from 1985.So we could give you original factory price than those trade companies.
We're also warmly welcome you to visting and inspection our factory at any time,Please Call at +86-18870736160
Q: 3.Can I operate it well, if I have no experience?
A: Do not worry! Our machines is designed to use easily.You are welcome to visit our company to be trained here,And we could arrange the engineer to go to your country/company to train your workers directly as your requested and the relative travel cost will be on your account.
Q: 4.Can you send me the video to show how the machine works?
A: Surely.we have made video of every machine,so if you need we can send for you to checking in clearly.
Q: 5. What should I take care when using the machine?
A: Please using the machine in regular and Keeping the machine away from thinner and other chemical liquid.
Q: 6.How about your Service ?
A: All of our machines have one year warranty and Wholelife Technology support to make sure your machine work well.
Q: 7.How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: 8.What about the payment method?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q:9 What's Information we need from your side ?
A: What kind of ore do you want to process ? The Capacity per hour do you need ? and the Max feeding size of your material ?
Warmly Welcome to Sending Inquiry,We will give 100% positive responses.
