CE VDE сертификации ПВХ 3 core 2 5 мм гибкий H07RN F кабель h05vv f провода электрического кабеля 3g2.5

Сохранить в закладки 1600213528848:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


Best sell products CE Certificate H07RN-F neoprene power cable price



OUR Advantages


1. 22 years production experience and 13 years export experience. with good quality and competitive price.
2 Annual Export amount more than 400million USD. Yearly manufacturing capacity 3 Billion RMB.
3 .Main products: Rubber Cables(upto 35kV),Mining Cable,1-35kV PVC &XLPE(LV&MV)Power Cables , Elevator Cable,Reeling/Trailing Cables,ESP cable, Solar PV Cables,Bare Conductor (AAC,ACSR,AAAC), ABC cables,Electric Wires, Control Cables, Welding Cable,Screened Cables and so on.
4.Products certification:UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV;
5. OEM/ODM service available, help you on designing.
6. Cable solutions to your particular requirements
7. Strict quality control system.
8. Strong technical support (technical data, drawing, etc.)
10. Free sample is available with economic express fee.


Please contact us directlyJACK NAMECARD
















Product Description





H07RN-F RUBBER CABLE
1.Manufacturer Cable
2.famous engineers research technology
3.cable ISO9001/CCC
4.white or black color



Rubber sheathed flexible cable
H07rn-f cable 450/750V



Application
The rubber sheathed flexible cables are mostly used as power cable for equipment in industry work such as boilers, heating plates, hand lamps, transportable motor etc. They can be installed at medium mechanical stress in dry, damp and wet areas as well as in open air and in agriculture plants. These cables are also suitable for fixed installation on plaster, in temporary buildings and residential barracks. They are suitable for direct laying on components and mechanical parts of machines like lifts and cranes.
The cables are able to be used in case of protected and fixed installation in tubes or in equipment as well as rotor connecting cable of motors with a working voltage up to and including AC 1000V or DC 750V against ground.
They are designed to provide high flexibility and have the capacity to withstand weather, oils, mechanical and thermal stresses. The cable is resistant to ozone and weather effects.

Standard
Iec 60245-4: 2004

(60245 iec 57 yzw, 60245 iec 66 ycw)

Cable structure
Conductor:
Electrolytic copper, tinned, class 5 according to iec 60228

Insulation:
Epr (ethylene propylene rubber) compound

Sheath:
Heavy duty rubber compound

Technical data
Voltage rating:
H05rn-f: AC 300/500V h07rn-f: AC 450/750V

Temperature rating:
Conductor operating max temperature +90° C
Cable operating environment temperature from -40° C to +90° C
Short circuit conductor max temperature +250° C for 5s

Test voltage:
AC 50Hz 2500V/5min no breakdown

Min. Bending radius:
Up to 25mm² : 6× Overall diameter
Above 25mm² : 8× Overall diameter

Core identification:
2. Cores
Blue, brown
(VDE 0293)
3. Cores (+ earth 3G)
Blue, brown, black
Blue, brown (+ green/yellow)
4. Cores (+ earth 4G)
Blue, brown, black, black
Blue, brown, black (+ green/yellow)
5. Cores (+ earth 5g)
Blue, brown, black, brown, black
Blue, brown, black, black (+ green/yellow)
6. Cores and more
Black core, white numbering (+ green/yellow)
Sheath color:
Black Cable marking:





Product type and specification


































































































































Type



Rated voltage V



Number of cores



Normal section mm2



IEC03/YG



450/750



1,2,3,4,3+1



0.5-240



60245IEC70/YTB


60245IEC70/YT


60245IEC75/YTF



300/500



6,9,12,18,24,30



0.75,1



60245IEC81/YH


60245IEC82/YTH



-



1



16-95



60245IEC53/YZ



300/500



2,3,4,5



0.75-2.5



60245IEC57/YZW



300/500



2,3,4,5



0.75-2.5



YZ  YZW



300/500



2,3,4,5



4-6



4/3+1



1.5-6



6



0.75-6



245IEC 66/YCW



450/750



1



1.5-400



2



1.0-25



3



1.0-95



4



1.0-150



5



1.0-25



YC



1



1.5-400



2



1.5-95



3



1.5-150



5



1.5-25



4/3+1



2.5-150



5/3+2



2.5-150



YCW



2



35-95



3



120-150



4/3+1



2.5-150



5/3+2



2.5-150



YHD



500



2,3,4



1.0-25



5,6,7,8



1.0-6










Rubber cable h05rn-f (h07rn-f) **mm² 300/500V (450/750V)

























































































































Conductor


Insulation




Section mm2


No./D


Insulation thickness mm


Core diameter mm


Jacket thickness mm


Outer diameter mm





2×0.50


16×0.20


0.60


2.10


1.20


5.80



2×0.75


24×0.20


0.60


2.40


1.30


6.50



2×1.00


32×0.20


0.60


2.50


1.30


6.60



2×1.50


30×0.25


0.70


3.00


1.50


7.90



2×2.00


37×0.26


0.70


3.30


2.00


9.40



3×0.50


16×0.20


0.60


2.10


1.50


7.20



3×0.75


24×0.20


0.60


2.40


1.50


7.80



3×1.00


32×0.20


0.60


2.50


1.50


8.00



3×1.50


30×0.25


0.70


3.00


1.80


9.60



3×2.00


37×0.26


0.70


3.30


2.00


10.60













Details Show


 11 6
128923











Certification


We have got the certificate of UL,CE,KEMA,TUV,Lloyd and“National Industrial Production License”, “Certificate of Recommended Enterprises and Products for National Grid”, “Adopting International Standard Certificate”, and “High-Tech Enterprise Certificate”, “Certificate of High Quality Products”, “Certificate of Scientific and Technological Achievements”, “Qualified Supplier Certificate”, “China Classification Society Certificate of Works Approval”, “Det Norske Veritas Type Approval Certificate”, “Railway Product Certificate”, “Safety Certificate of Approval for Mining Products”, “National Mandatory Product Certification”, “Certificate for China Compulsary Products Certification” and “Practical New-Type Patent Certificate”.








Company Information


HeBei huatong wires&cables Group Co.,ltd.It was established in 1993.


Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 800 employers in our company, among which more than 150 are techniciansOur products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects.


We are top cable manufacture of rubber serious cables . Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC power cables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We are OEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.





Workshop


workshop


customer visiting_





Packaging & Shipping


 packingBV-RV-PACKAGEcontrol cable








FAQ




(1).When can I get the price?


We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.




(2).How can I get a sample to check your quality?


After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.


(3).How long can I expect to get the sample?


After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express  account or prepay us if you do not have an account.


(4).What about the lead time for mass production?


Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
