CRBC9016UU высококачественный перекрестный роликовый подшипник CRBC 9016 UU
10,00 $
Роликовые подшипники NJ NU 232 китайский цилиндрический роликовый подшипник NU232 NJ32 размер 160x290x48
- Категория: Cylindrical Roller Bearing >>>
- Поставщик: Shandong Bohong Bearing Co. Ltd.
Сохранить в закладки 1600233206591:
Описание и отзывы
Характеристики
roller type bearings NJ NU 232 chinese cylindrical roller bearing NU232 NJ32 size 160x290x48
Product Description
China cylindrical roller bearings, the cylindrical rollers are in linear contact with the raceways. They have a high radial load capacity and are suitable for high speeds.
There are different types designated as NU, NJ, NUP, N, NF (for single-row bearings), NNU, and NN (for double-row bearings depending on the design or absence of side ribs).
Specifications: NU232 cylindrical roller bearing NU 232 ECML single row | |
Roller bearing type | cylindrical roller bearing |
Number of row | single row |
Precision rate | grade p4 p5 p6 p0 abec5 |
| Cage type | M type brass cage |
Clearance | C4 C0 C3 clearance bearing |
Origin | china cylindrical roller bearing |
Dimensions: | |
Bore size | 160mm |
Outside Diameter D | 290mm |
Outside Ring Width B | 48mm |
Weight | 14.2kgs |
Basic Load Ratings: | |
Cr - Dynamic Load Rating | 585kN |
C0r - Static Load Rating | 680kN |
China cylindrical roller bearing:
| Bearing No. | Main Dimension (mm ) | Weight | |||
| d | D | B | r/min | KG | |
| mm | mm | mm | mm | approx. | |
| NJ222 EM | 110 | 200 | 38 | 2.1 | 5.37 |
| NU222 EM | 110 | 200 | 38 | 2.1 | 5.37 |
| NUP222 EM | 110 | 200 | 38 | 2.1 | 5.37 |
| NJ2222EM | 110 | 200 | 53 | 2.1 | 7.65 |
| NU2222EM | 110 | 200 | 53 | 2.1 | 7.65 |
| NUP2222EM | 110 | 200 | 53 | 2.1 | 7.65 |
| N322 | 110 | 240 | 50 | 3 | 10.3 |
| NF322 | 110 | 240 | 50 | 3 | 10.3 |
| NJ322 EM | 110 | 240 | 50 | 3 | 11.8 |
| NU322 EM | 110 | 240 | 50 | 3 | 11.8 |
| NUP322 EM | 110 | 240 | 50 | 3 | 11.8 |
| NJ422 | 110 | 280 | 65 | 4 | 22.1 |
| NU422 | 110 | 280 | 65 | 4 | 22.1 |
| N1024 | 120 | 180 | 28 | 2 | 2.43 |
| NJ1024 | 120 | 180 | 28 | 2 | 2.43 |
| NU1024 | 120 | 180 | 28 | 2 | 2.43 |
| NUP1024 | 120 | 180 | 28 | 2 | 2.43 |
| N224 | 120 | 215 | 40 | 2.1 | 5.63 |
| NF224 | 120 | 215 | 40 | 2.1 | 5.63 |
| NJ224 EM | 120 | 215 | 40 | 2.1 | 6.43 |
| NU224 EM | 120 | 215 | 40 | 2.1 | 6.43 |
| NUP224 EM | 120 | 215 | 40 | 2.1 | 6.43 |
| NJ2224EM | 120 | 215 | 58 | 2.1 | 9.51 |
| NU2224EM | 120 | 215 | 58 | 2.1 | 9.51 |
| NUP2224EM | 120 | 215 | 58 | 2.1 | 9.51 |
| N324 | 120 | 260 | 55 | 3 | 12.9 |
| NF324 | 120 | 260 | 55 | 3 | 12.9 |
| NJ324 EM | 120 | 260 | 55 | 3 | 15 |
| NU324 EM | 120 | 260 | 55 | 3 | 15 |
| NUP324 EM | 120 | 260 | 55 | 3 | 15 |
| NJ2324 EM | 120 | 260 | 86 | 3 | 25 |
| NU2324 EM | 120 | 260 | 86 | 3 | 25 |
| NUP2324 EM | 120 | 260 | 86 | 3 | 25 |
| N424 | 120 | 310 | 72 | 5 | 30.2 |
| NJ424 | 120 | 310 | 72 | 5 | 30.2 |
| NU424 | 120 | 310 | 72 | 5 | 30.2 |
| NUP424 | 120 | 310 | 72 | 5 | 30.2 |
| N1026 | 130 | 200 | 33 | 2 | 3.66 |
| NF1026 | 130 | 200 | 33 | 2 | 3.66 |
| NJ1026 | 130 | 200 | 33 | 2 | 3.66 |
| NU1026 | 130 | 200 | 33 | 2 | 3.66 |
| N226 | 130 | 230 | 40 | 3 | 6.48 |
| NF226 | 130 | 230 | 40 | 3 | 6.48 |
| NJ226 EM | 130 | 230 | 40 | 3 | 8.03 |
| NU226 EM | 130 | 230 | 40 | 3 | 8.03 |
| NUP226 EM | 130 | 230 | 40 | 3 | 8.03 |
| NJ2226EM | 130 | 230 | 64 | 3 | 9.44 |
| NU2226EM | 130 | 230 | 64 | 3 | 9.44 |
| NUP2226EM | 130 | 230 | 64 | 3 | 9.44 |
| N326 | 130 | 280 | 58 | 4 | 17.7 |
| NF326 | 130 | 280 | 58 | 4 | 17.7 |
| NJ326EM | 130 | 280 | 58 | 4 | 18.7 |
| NU326EM | 130 | 280 | 58 | 4 | 18.7 |
| NUP326EM | 130 | 280 | 58 | 4 | 18.7 |
| NJ2326 EM | 130 | 280 | 93 | 4 | 30 |
| NU2326 EM | 130 | 280 | 93 | 4 | 30 |
| NUP2326 EM | 130 | 280 | 93 | 4 | 30 |
| NF426 | 130 | 340 | 78 | 5 | 39.6 |
| NJ426 | 130 | 340 | 78 | 5 | 39.6 |
| NU426 | 130 | 340 | 78 | 5 | 39.6 |
| N1028 | 140 | 210 | 33 | 2 | 3.87 |
| NJ1028 | 140 | 210 | 33 | 2 | 3.87 |
| NU1028 | 140 | 210 | 33 | 2 | 3.87 |
| NUP1028 | 140 | 210 | 33 | 2 | 3.87 |
| N228 | 140 | 250 | 42 | 3 | 8.08 |
| NF228 | 140 | 250 | 42 | 3 | 8.08 |
| NJ228EM | 140 | 250 | 42 | 3 | 9.38 |
| NU228EM | 140 | 250 | 42 | 3 | 9.38 |
| NUP228EM | 140 | 250 | 42 | 3 | 9.38 |
| NJ2228EM | 140 | 250 | 68 | 3 | 15.2 |
| NU2228EM | 140 | 250 | 68 | 3 | 15.2 |
| NUP2228EM | 140 | 250 | 68 | 3 | 15.2 |
| N328 | 140 | 300 | 62 | 4 | 21.7 |
| NF328 | 140 | 300 | 62 | 4 | 21.7 |
| NJ328EM | 140 | 300 | 62 | 4 | 22.8 |
| NU328EM | 140 | 300 | 62 | 4 | 22.8 |
| NUP328EM | 140 | 300 | 62 | 4 | 22.8 |
| NJ2328 EM | 140 | 300 | 102 | 4 | 37.7 |
| NU2328 EM | 140 | 300 | 102 | 4 | 37.7 |
| NUP2328 EM | 140 | 300 | 102 | 4 | 37.7 |
| N428 | 140 | 360 | 82 | 5 | 46.4 |
| NJ428 | 140 | 360 | 82 | 5 | 46.4 |
| NU428 | 140 | 360 | 82 | 5 | 46.4 |
| N1030 | 150 | 225 | 35 | 2.1 | 4.77 |
| NF1030 | 150 | 225 | 35 | 2.1 | 4.77 |
| NJ1030 | 150 | 225 | 35 | 2.1 | 4.77 |
| NU1030 | 150 | 225 | 35 | 2.1 | 4.77 |
| N230 | 150 | 270 | 45 | 3 | 10.4 |
| NF230 | 150 | 270 | 45 | 3 | 10.4 |
| NJ230EM | 150 | 270 | 45 | 3 | 11.9 |
| NU230EM | 150 | 270 | 45 | 3 | 11.9 |
| NUP230EM | 150 | 270 | 45 | 3 | 11.9 |
| NJ2230EM | 150 | 270 | 73 | 3 | 19.3 |
| NU2230EM | 150 | 270 | 73 | 3 | 19.3 |
| NUP2230EM | 150 | 270 | 73 | 3 | 19.3 |
| N330 | 150 | 320 | 65 | 4 | 25.8 |
| NF330 | 150 | 320 | 65 | 4 | 25.8 |
| NJ330EM | 150 | 320 | 65 | 4 | 27.1 |
| NU330EM | 150 | 320 | 65 | 4 | 27.1 |
| NUP330EM | 150 | 320 | 65 | 4 | 27.1 |
| NJ2330 EM | 150 | 320 | 108 | 4 | 45.1 |
| NU2330 EM | 150 | 320 | 108 | 4 | 45.1 |
| NUP2330 EM | 150 | 320 | 108 | 4 | 45.1 |
| NJ430 | 150 | 380 | 85 | 5 | 55.8 |
| NU430 | 150 | 380 | 85 | 5 | 55.8 |
| N1032 | 160 | 240 | 38 | 2.1 | 5.81 |
| NF1032 | 160 | 240 | 38 | 2.1 | 5.81 |
| NJ1032 | 160 | 240 | 38 | 2.1 | 5.81 |
| NU1032 | 160 | 240 | 38 | 2.1 | 5.81 |
| N232 | 160 | 290 | 48 | 3 | 14.1 |
| NF232 | 160 | 290 | 48 | 3 | 14.1 |
| NJ232EM | 160 | 290 | 48 | 3 | 14.7 |
| NU232EM | 160 | 290 | 48 | 3 | 14.7 |
| NUP232EM | 160 | 290 | 48 | 3 | 14.7 |
| NJ2232EM | 160 | 290 | 80 | 3 | 24.5 |
| NU2232EM | 160 | 290 | 80 | 3 | 24.5 |
| NUP2232EM | 160 | 290 | 80 | 3 | 24.5 |
| N332 | 160 | 340 | 68 | 4 | 30.8 |
| NJ332EM | 160 | 340 | 68 | 4 | 32.1 |
| NU332EM | 160 | 340 | 68 | 4 | 32.1 |
| NUP332EM | 160 | 340 | 68 | 4 | 32.1 |
| NJ2332 EM | 160 | 340 | 114 | 4 | 53.9 |
| NU2332 EM | 160 | 340 | 114 | 4 | 53.9 |
| NUP2332 EM | 160 | 340 | 114 | 4 | 53.9 |
| N1034 | 170 | 260 | 42 | 2.1 | 7.91 |
| NJ1034 | 170 | 260 | 42 | 2.1 | 7.91 |
| NU1034 | 170 | 260 | 42 | 2.1 | 7.91 |
| N234 | 170 | 310 | 52 | 4 | 17.4 |
| NF234 | 170 | 310 | 52 | 4 | 17.4 |
| NJ234EM | 170 | 310 | 52 | 4 | 18.3 |
| NU234EM | 170 | 310 | 52 | 4 | 18.3 |
| NUP234EM | 170 | 310 | 52 | 4 | 18.3 |
| NJ2234EM | 170 | 310 | 86 | 4 | 29.9 |
| NU2234EM | 170 | 310 | 86 | 4 | 29.9 |
| NUP2234EM | 170 | 310 | 86 | 4 | 29.9 |
| N334 | 170 | 360 | 72 | 4 | 36.6 |
| NJ334EM | 170 | 360 | 72 | 4 | 37.9 |
| NU334EM | 170 | 360 | 72 | 4 | 37.9 |
| NUP334EM | 170 | 360 | 72 | 4 | 37.9 |
| NJ2334 EM | 170 | 360 | 120 | 4 | 63.4 |
| NU2334 EM | 170 | 360 | 120 | 4 | 63.4 |
| NUP2334 EM | 170 | 360 | 120 | 4 | 63.4 |
| N1036 | 180 | 280 | 46 | 2.1 | 10.2 |
| NF1036 | 180 | 280 | 46 | 2.1 | 10.2 |
| NJ1036 | 180 | 280 | 46 | 2.1 | 10.2 |
| NU1036 | 180 | 280 | 46 | 2.1 | 10.2 |
| N236 | 180 | 320 | 52 | 4 | 18.1 |
| NF236 | 180 | 320 | 52 | 4 | 18.1 |
| NJ236EM | 180 | 320 | 52 | 4 | 19 |
| NU236EM | 180 | 320 | 52 | 4 | 19 |
| NUP236EM | 180 | 320 | 52 | 4 | 19 |
| NJ2236EM | 180 | 320 | 86 | 4 | 31.4 |
| NU2236EM | 180 | 320 | 86 | 4 | 31.4 |
| NUP2236EM | 180 | 320 | 86 | 4 | 31.4 |
| N336 | 180 | 380 | 75 | 4 | 42.6 |
| NF336 | 180 | 380 | 75 | 4 | 42.6 |
| NJ336EM | 180 | 380 | 75 | 4 | 44 |
| NU336EM | 180 | 380 | 75 | 4 | 44 |
| NUP336EM | 180 | 380 | 75 | 4 | 44 |
| NJ2336 EM | 180 | 380 | 126 | 4 | 74.6 |
| NU2336 EM | 180 | 380 | 126 | 4 | 74.6 |
| NUP2336 EM | 180 | 380 | 126 | 4 | 74.6 |
| N1038 | 190 | 290 | 46 | 2.1 | 10.7 |
| NJ1038 | 190 | 290 | 46 | 2.1 | 10.7 |
| NU1038 | 190 | 290 | 46 | 2.1 | 10.7 |
| N238 | 190 | 340 | 55 | 4 | 22 |
| NF238 | 190 | 340 | 55 | 4 | 22 |
| NJ238EM | 190 | 340 | 55 | 4 | 23 |
| NU238EM | 190 | 340 | 55 | 4 | 23 |
| NUP238EM | 190 | 340 | 55 | 4 | 23 |
| NJ2238EM | 190 | 340 | 92 | 4 | 38.3 |
| NU2238EM | 190 | 340 | 92 | 4 | 38.3 |
| NUP2238EM | 190 | 340 | 92 | 4 | 38.3 |
| N338 | 190 | 400 | 78 | 5 | 48.7 |
| NJ338EM | 190 | 400 | 78 | 5 | 50.6 |
| NU338EM | 190 | 400 | 78 | 5 | 50.6 |
| NUP338EM | 190 | 400 | 78 | 5 | 50.6 |
