Product Description
Electric threading machine is an electric tool equipped with a positive and negative device for processing the external thread of a pipe. Also known as: electric pipe threading machine, threading machine, pipe threading machine. It makes the pipe thread processing easy and fast during pipe installation. Reduce the labor intensity of pipeline installation workers.
Operating Principle
When use the threader, first put the pipe to be processed into the pipe chuck, hit the chuck, press the start switch, the pipe will rotate with the chuck, adjust the size of the die opening on the die head. Then set length and turn the feed wheel clockwise to make the die cutter on the die head stick to the end of the rotating pipe with constant force, and the die cutter will automatically cut the pipe thread, and the cooling system will automatically spray oil for cooling. When the thread mouth is processed to the preset length, the die cutter will automatically open, and the thread mouth processing is finished. Turn off the power, knock the chuck open, and take out the tube.
The threading machine is composed of: machine
body, motor, reduction box, pipe chuck, die head, cutter holder, feed device, and cooling system.
body, motor, reduction box, pipe chuck, die head, cutter holder, feed device, and cooling system.
Models and working range
The types of pipe threading machines generally include: 2-inch pipe threading machine (ZIT-R2), processing range: 1/2"-2" (inch), 3-inch pipe threading machine (ZIT-R3) processing range: 1/ The processing range of 2"-3" (inch) and 4-inch pipe threader (ZIT-R4) is: 1/2"-4" (inch), and the processing range of 6-inch pipe threader (ZIT-R6) is: 2 1 /2"-6"(inch)
Specification
Model | ZIT-R2 | ZIT-R3 | ZIT-R4 | ZIT-R6 |
Working Range | 1/2" - 2" | 1/2" - 3" | 1/2" - 4" | 2 1/2" - 6" |
Power | 750W | 750W | 750W | 750W |
Voltage | 220V | 220V | 220V | 220V |
Speed | 28RPM | 27RPM | 24/9RPM | 18/6RPM |
Net Weight | 65KG | 100KG | 120KG | 230KG |
Total Weight | 75KG | 110KG | 135KG | 210KG |
Dimension | 64*41*52CM | 85*55*55CM | 95*62*62CM | 106*72*70CM |
Accessory | 1/2"-3/4", 1"-2" Dies & Oil bottle & Screwdriver & 3 Legs | 1/2"-3/4", 1"-2", 2 1/2"-3" Dies & Oil bottle & Screwdriver & 4 Legs | 1/2"-3/4", 1"-2", 2 1/2"-4" Dies & Oil bottle & Screwdriver & 4 Legs | 2 1/2"-4", 5"-6" Dies & Oil bottle & Screwdriver & 4 Legs |
Detailed Images
On SIte
Company Profile
Henan Ework Industrial Equipment Co., Ltd. is a professional company dedicated to the R&D, production and sales of piping machines and tools related to pipes.
In line with the business tenet of "piping solutions expert" and the mission of "make work easy and efficient", we have
independently developed and produced a series of products that customers love. Our product series mainly include pipe cutting machines, pipe beveling machines, pipe bending machines, pipe threading machines, HDPE pipe machines and related tools. These products are widely used for stainless pipe, steel pipe, galvanized pipe, mild steel and plastic pipes.
Our company not only has a professional and skilled workforce but also has established a complete and complete quality management system. We are committed to providing customers with world-class products and look forward to sincere and friendly cooperation with our customers to have a good business together.
In line with the business tenet of "piping solutions expert" and the mission of "make work easy and efficient", we have
independently developed and produced a series of products that customers love. Our product series mainly include pipe cutting machines, pipe beveling machines, pipe bending machines, pipe threading machines, HDPE pipe machines and related tools. These products are widely used for stainless pipe, steel pipe, galvanized pipe, mild steel and plastic pipes.
Our company not only has a professional and skilled workforce but also has established a complete and complete quality management system. We are committed to providing customers with world-class products and look forward to sincere and friendly cooperation with our customers to have a good business together.
Our Products
Our product series mainly include pipe cold cutters, pipe bevelers, pipe threaders, pipe scrapers, pipe squeezers, pipe welders, pipe benders, and pipe cutting beveling machines. These products are widely used for water pipelines, fire-fighting pipelines, gas pipelines, chemical pipelines, and petroleum pipelines. If you want to buy these products, please directly contact me. Follow items are the best selling products, please tap/click to view the details.
