500l 1800L beer brewery equipment fermenting equipment turnkey plant for bar / pubs / brew kettle system
Product Description
My name is Fermenter(15BBL Stainless Steel/Red Copper Conical Dimple Cooling Conical Fermenter Fermenting Vessel 1800L Brewery Tank), and I’m born in Shandong Tiantai Beer Equipment Co., Ltd, that is the leading Microbrewery equipment supplier/manufacturer in China.
I am the most important part of beer brewing. I’m also called CCT’s (Cylindrical Conical Tanks), FV’s (Fermentation Vessel), primary fermentor or unitanks.
The fermentation & ageing take place in my vessel body. It was finally put into beer bottles, cans or directly poured into glasses for everyone to enjoy.
To be an excellent fermentation tank(15BBL Stainless Steel/Red Copper Conical Dimple Cooling Conical Fermenter Fermenting Vessel 1800L Brewery Tank), it is essential to have some high quality parts.
If you want to place an order directly through Alibaba, please read the following parameters carefully.
Function:Wort Fermentation or maturation |
Tank Capacity: 15BBL (+25% Headspace minimum) |
Dimension: Φ1560mmx2850mm |
Interior Shell: SUS304 full welded; TH=3mm |
Exterior Shell:SUS304 full welded; TH=2mm |
100% TIG welding with pure argon gas shield |
Interior Finish: Sanitary 2B finish, Pickled and Passivated; (8K Mirror finish optional) |
Exterior Finish: Oil brushed finish(2B, 8K Mirror finish optional) |
Interior full polished to 0.2~0.4 μm without dead corner |
Insulated with high density Polyurethane foam; TH=80mm |
Glycol Jacket: Dimpled plate on cone and side |
Stringent tank leakage test by water and pressured gas |
Stringent Jacket leakage test by water and pressured gas |
Dished head and 60 degree cone bottom |
Sanitary side mounted manway with pressured door |
TC connected CIP arm with 360° coverage spraying ball |
CO2 blow-off arm with butterfly valve |
Sanitary sample valve TC |
Mechanical safe valve PVRV 2 bar on top |
Hydraulic shock pressure gauge on CIP arm |
Rotating racking arm and port on cone with butterfly valve |
Tri clamp discharge arm with butterfly valve |
Thermowell for high accuracy temperature sensor |
4pcs completely SUS304 heavy duty legs with leveling pad and legs support |
Complete valves, fittings and all parts |
Dry hopping port 4'' TC with solid end cap |
Sanitary level tube and valves TC for special request |
Carbonation port TC with stone for special request |
Bunging valve 0.2-2.2bar for special request |
15BBL Stainless Steel/Red Copper Conical Dimple Cooling Conical Fermenter Fermenting Vessel 1800L Brewery Tank
From material to product, I walked step by step. I was tempered by fire, cut by laser, created by welding machine, carved by grinding wheel, and tested by high pressure. Finally, I can stand in front of you.
15BBL Stainless Steel/Red Copper Conical Dimple Cooling Conical Fermenter Fermenting Vessel 1800L Brewery Tank
Because of the super high quality and very competitive price, in the past eight years, my brothers and sisters have moved to more than 800 breweries in more than 70 countries around the world, and have also contributed their meager power to the local craft beer development.
I have also participated in many exhibitions on behalf of our company.
Packaging & Shipping
Shipping is my favorite mode of transportation, and both FCL and LCL are also suitable for me.
15BBL Stainless Steel/Red Copper Conical Dimple Cooling Conical Fermenter Fermenting Vessel 1800L Brewery Tank
FAQ
1.Q: Are you a manufacturer?
A: Yes, we have been in providing the professional products in this field for 10 years.
2.Q:What exactly does the 36 month warranty cover?
A:36 month warranty cover all the main tank.one years for the accessories and spare parts.
3.Q: Can your factory produce equipment according to our drawing or samples?
A: Yes, we can do.
4.Q: How to calculate the daily output? How many fermenters do I need?
A: Usually the equipment models such as 300L and 500L are only 300L, 500L wort for mashing capacity. Beer production is according to your fermentation process requirements and the number of fermenters configured.
5.Q: How you pack the products?
A: Normally as the export standard packaging or as you required.
6.Q: What is your available port of shipment?
A: Qingdao port, Ningbo Port etc.
Company Information
If you like me, please take me home!
