40L High Purity Neon Gas 99.9999%

Product Description

1.Neon is a rare atmospheric gas which is odorless, colorless, tasteless, nontoxic, monatomic and chemically inert. The concentration of Neon in the atmosphere, by volume percent, is 1.8 x 10-3.

2.Newradar's high purity neon in 5N were good in sales in the past year 2015 for export 400 cylinders

per month . The quality details as follows:

Specifications:

Component	Specification	Concentration
NEON	99.999%	>99.999%
HELIUM	≤6 ppm	≤6 ppm
HYDROGEN	≤1 ppm	≤1 ppm
OXYGEN+AIR	≤1 ppm	≤1 ppm
NITROGEN	≤2 ppm	≤2 ppm
CARBON MONOXIDE (CO)	≤0.5 ppm	≤0.5 ppm
CARBON DIOXIDE(CO2)	≤0.5 ppm	≤0.5 ppm
CH4	≤0.5 ppm	≤0.5 ppm
MOISTURE	≤2 ppm	≤2 ppm

PHYSICAL CONSTANTS
Chemical name	Ne
Molecular weight	20.183
Density of the gas at 70oF (21,1o C), 1 atm	0.05215 lb/ft3, 0.83536 kg/ m3
Specific gravity of the gas at 70oF (21,1o C), 1 atm	0.696
Specific volume of the gas at 70oF (21,1o C), 1 atm	19.18 ft3/lb, 1.197 m3/kg
Boiling point at 1 atm	–410.9°F, –246.0°C
Melting point at 1 atm	–415.6°F, –248.7°C
Critical temperature at 1 atm	–379.8°F, –228.8°C
Critical pressure	384.9 psia, 26.54 bar
Critical density	30.15 lb/ft3, 483 kg/m3
Triple point at 6.29 psia (0.434 bar)	–415.4°F, –248.6°C
Latent heat of vaporization at normal boiling point	37.08 Btu/lb, 86.3 kJ/kg
Latent heat of fusion at triple point	7.14 Btu/lb, 16.6 kJ/kg
Specific heat of the gas at 70oF (21,1o C), 1 atm Cp Cv	0.25 Btu/(lb) (°F) 1.05 kJ/(kg) (°C) 0.152 Btu/(lb) (°F) 0.636 kJ/(kg) (°C)

Applications:

1. Neon is often used in signs and produces an unmistakable bright reddish-orange light.

2. Neon is used in vacuum tubes , high-voltage indicators, lighting arresters,wave meter tubes,televsion

tubes,and helium-neon lasers.

3. Neon is used in some plasma tube and refrigerant applications but has few other commercial uses.

It is commercially extracted by the fractional distillation of liquid air.Since air is the only source, it is

considerably more expensive than helium.

SHIPPING DATA:

SHIPPING DATA
Synonyms	Ne
CAS Register Number	7440-59-7
DOT Classification	Nonflammable gas
DOT Label	Nonflammable gas
Transport Canada Classification	2.2
Substance Identification (SI)	1046
UN Number	UN 1046
Hazards	High Pressure and suffocation
Toxicity (TLV)	Asphyxiant
Flammability Range (in air)	Nonflammable gas
Odor	None
