Product Description

CARBON FIBER FBARIC-Colorful carbon kevlar fiber hybrid fabric

1K means 1 carbon yarn contains 1000 filaments, 2K means 2000 filaments, and so on. We have 1K/3K/6K/12K carbon fiber fabric.
The two-way cabon fiber fabric are woven with Plain and Twill style, we have 120gsm, 140gsm, 200gsm, 240gsm, 280gsm, 320gsm,400gsm, 480gsm,640gsm for choosing.
Some commonly used types of weave are twill, plain and satin. Compared with traditional meterial, carbon fiber fabric has manyadvantages such as high stiffness, high tensile strength, low weight, high temperature tolerance and low thermal expansion. These make the weight greatly reduced. Meanwhile, carbon fiber fabrics are compatible with various resin systems including epoxy,polyester and vinyl ester resins.
With a light weight, high strength, high modulus, fatigue resistance, heat resistance, corrosion resistance, drug resistance,
electrical conductivity, X-ray penetrability, the carbon fiber fabrics are mainly used in aircraft, tail and body: auto engine,
synchronous, machine covers, bumpers, trimming ; Bicycle frames, faucets bat, the sound, Kayaks, skis, various models, skull, building reinforcing, watches, pens, bags and so on.

TWILL WEAVE

PLAIN WEAVE

REFLECT GREEN CARBON FIBER

3D JACQUARD WEAVE

SQUARE JACQUARD WEAVE

CAMOUFLAGE WEAVE

Specification

TYPE	REINFORCEMENT YARN			WEAVE	FIBER COUNT(10mm)			WEIGHT(g/sqm)	THICKNESS(mm)	WIDTH(mm)
TYPE		WARP YARN	WEFT YARN	WEAVE		WARP ENDS	WEFT ENDS	WEIGHT(g/sqm)	THICKNESS(mm)	WIDTH(mm)
ZD-1K-P	1K	1K	PLAIN	9	9	120	0.16	1000-1500
ZD-1K-T	1K	1K	TWILL	9	9	120	0.16	1000-1500
ZD-1K-P	1K	1K	PLAIN	10.5	10.5	140	0.17	1000-1500
ZD-1K-T	1K	1K	TWILL	10.5	10.5	140	0.17	1000-1500
ZD-3K-P	3K	3K	PLAIN	5	5	200	0.30	1000-1500
ZD-3K-T	3K	3K	TWILL	5	5	200	0.30	1000-1500
ZD-3K-P	3K	3K	PLAIN	6	6	240	0.32	1000-1500
ZD-3K-T	3K	3K	TWILL	6	6	240	0.32	1000-1500
ZD-3K-P	3K	3K	PLAIN	7	7	280	0.34	1000-1500
ZD-3K-T	3K	3K	TWILL	7	7	280	0.34	1000-1500
ZD-6K-P	6K	6K	PLAIN	4	4	320	0.38	1000-1500
ZD-6K-T	6K	6K	TWILL	4	4	320	0.38	1000-1500
ZD-6K--P	6K	6K	PLAIN	5	5	400	0.42	1000-1500
ZD-6K-T	6K	6K	TWILL	5	5	400	0.42	1000-1500
ZD-12K-P	12K	12K	PLAIN	2.5	2.5	400	0.46	1000-1500
ZD-12K-T	12K	12K	TWILL	2.5	2.5	400	0.46	1000-1500
ZD-12K-P	12K	12K	PLAIN	3	3	480	0.52	1000-1500
ZD-12K-T	12K	12K	TWILL	3	3	480	0.52	1000-1500
ZD-12K-T	12K	12K	TWILL	4	4	640	0.64	1000-1500

Application

1.Aerospace:Fuselage, Rudder.
2.Sport equipment: Automobile parts, fish pole, baseball bat, sled, speedboat, badminton racket,etc.
3.Industry: Engine component, reinforced material of concert structure, air-blower vane, driving shaft,etc.
4.Fire protection: Apply for fireproof clothing production of army, fire forces, steel plants, etc.
