Улучшенный Эргономичный 6 тонный дизельный/Электрический вилочный погрузчик DIBO грузоподъемностью 6 5 тонн Лидер продаж

Сохранить в закладки 1600288983883:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


.jpg

Product Advantage







.jpg





 Parameter

Model  DBD30DBD35DBD38
power   Diesel
Rated Lifting Force kg300035003800
Center distance of load mm500500500
The wheelbase mm171017101730
Curb Weight kg435047505000
Tire type Pneumatic tyre
Tire front tire  28*9-1528*9-1528*9-15
 rear tire 6.50-106.50-106.50-10
Wheel basefront Wheel basemm100010001000
 rear Wheel basemm970970970
Whole lengthno fork mm272727882808
 have fork mm384739083928
Whole widthThe tire widthmm122812281228
 The frame widthmm122012201220
Whole heightMaximum height for operationmm426242624262
Minimum ground clearanceThe bottom door framemm135135135
 Central framemm165165165
Free lifting height mm657070
Standard hoisting height mm300030003000
The dimensions of the fork wide*thickmm45*12545*12545*125
length Standard/optional mm1070/12201070/12201070/1220

minimum turning radius
 mm 252025602580
maximum travelling speed km/h25.9/26.325.9/26.325.9/26.3
Maximum lift speedFull load/no loadkm/h440/480330/370360/400
Full load maximum hook tractionFull load/no loadKN16.716.716.7
Maximum climbing speed %201720









Product Details

 .jpg





.jpg

Application



.jpg
