Лайнер для разведения рыбы HDPE LDPE EPDM резервуар воды из ПВХ 1 мм геомембрана/Подводка пруда подкладка рыбного
0,12-0,35 $
Нетканая геотекстильная мембрана
- Категория: >>>
- Поставщик: Tinhy Geosynthetics Co. LtdTinhy Ltd
Сохранить в закладки 1600306779072:
Описание и отзывы
Характеристики
Product Description
* Non-woven geotextile membranes
polypropylene (PP). It's wont to construct retaining structures, linear constructions, waste deposits, drainage systems etc.
Produced from top quality polypropylene fibers, Tinhy non woven geotextiles are needle-punched to make a robust fabric that
retains its dimensional stability and is immune to damage from construction stresses. Tinhy non-woven geotextiles are available in
varying strengths and thicknesses to make sure appropriate materials selection for your project.
* Non-woven geotextile membranes
Tinhy Non-woven fabrics are defined as a sheet, web, or bat of directionally or randomly oriented fibers/filaments, bonded either by
friction, and/or cohesion, and/or adhesion. Generally, the formation of nonwoven fabrics is generally considered to be a two-step
process: forming a web (making fibers have certain orientation characteristics) and bonding these fibers by mechanical, thermal or
chemical means. These two steps form the classification of non-woven fabric structure, i.e. carded, air laid, spun laid, melt
blown, needle punched, hydro entangled, adhesive bonded, thermal bonded, stitch bonded, etc.
* * Non-woven geotextile membranes
Non-woven geotextile are often wont to spate two layers of materials with different grain size, making these materials retain its
mechanical properties struggling , especially pressure from large moving vehicles.
Non-woven geotextiles help to save lots of construction costs. it's used as a separator between two layers of fabric with
different properties, avoiding loss of fabric , allowing to scale back the quantity of soil.
* * Non-woven geotextile membranes
Protection:
Beside its mechanical strength like lastingness , high puncture resistance, non-woven geotextile also has high sustainability(salt
water resistance) and quick drainage. Therefore, it are often associated with other materials like gabion, dry rip-rap stone,
concrete….to make a corrosion resistance layer for dyke, embankment, coastal and bridge pier.
Beside its mechanical strength like lastingness , high puncture resistance, non-woven geotextile also has high sustainability(salt
water resistance) and quick drainage. Therefore, it are often associated with other materials like gabion, dry rip-rap stone,
concrete….to make a corrosion resistance layer for dyke, embankment, coastal and bridge pier.
* * Non-woven geotextile membranes
Filtration and drainage:
Non-woven geotextile plays an important role as a filtering layer between two materials layer with different permeability andgrain size. The function of the filter layer is to prevent the smoother granular material layer from corroding the remaining
material layer. In addition, it has right-angle permeability, and non-woven geotextiles can also be used to create underground
ditches. Flows within the bottom will focus to ditch equipped with non-woven geotextile and attend water reservoir by pipeline.
Specification
item | value |
Type | Geotextiles |
Warranty | More than 5 years |
After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement |
Project Solution Capability | graphic design, 3D model design, total solution for projects, Cross Categories Consolidation |
Application | water pond, landfill, road construction, slop, green roof |
Design Style | Industrial, construction |
Place of Origin | China |
Shandong | |
Brand Name | Tinhy |
Model Number | 100g/m2 |
color | Black White Green |
Material | PP/Polypropylene; PET/Polyester |
Standard | ASTM/ISO/EN/GB Standard |
MOQ | 1x40ft Container |
Package | Plastic Woven Bags |
Width | 3m to 8m |
Roll length | 50m to 100m |
Thickness | 0.2mm-3mm |
Product Name | non woven geotextile |
Surface | bond or no bond |
Packing & Delivery
PET staple fiber non woven geotextile technical data | ||||||||||||||||||
Specification(g) Properties | 100g | 150g | 200g | 250g | 300g | 350g | 400g | 500g | 600g | |||||||||
Tolerances of weight(%) | —8 | —8 | —8 | —8 | —7 | —7 | —7 | —5 | —6 | |||||||||
Thickness(mm) ≧ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.6 | 4.1 | |||||||||
Tensile strength(kN/m)≧ | 2.5 | 4.5 | 6.5 | 8 | 9.5 | 11.0 | 12.5 | 16 | 19 | |||||||||
Elongation(%)≧ | 25—100 | |||||||||||||||||
Tear strength(KN) ≧ | 0.08 | 0.12 | 0.16 | 0.20 | 0.24 | 0.28 | 0.33 | 0.42 | 0.46 | |||||||||
CBR Puncture Strength(KN)≧ | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.7 | 3.2 | |||||||||
Opening Size(O90/O95) | 0.07--0.2 | |||||||||||||||||
Permeability(cm/s) | K x （10-1~10-3）；K=1.0--9.9 | |||||||||||||||||
PET long fibers needle punched non woven geotextiles | ||||||||||||||
specification | 100g | 150g | 200g | 300g | 400g | 500g | 600g | |||||||
breaking strength/(KN/M)≥ | 4.5 | 7.5 | 10.0 | 15 | 20.0 | 25 | 30.0 | |||||||
elongation % | 40--80 | |||||||||||||
CBR Bursting strength，kN | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | |||||||
Tearstrength ，kN ≥ | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.7 | 0.82 | |||||||
Equivalent aperture O90（O95)，mm | 0.05--0.2 | |||||||||||||
Vertical permeability，cm/s | Kx（10-1～10-3） among K=1.0～9.9 | |||||||||||||
thickness mm ≥ | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | |||||||
Width deviation，% | --0.5 | |||||||||||||
Deviation of mass per unit area % | --5 | |||||||||||||
PP non woven geotextile technical data | ||||||||||||||
Property | Test Method | Unit | Class | |||||||||||
Mass per unit area | ISO 09864 | g/m2 | 350 | 400 | 600 | 800 | 1000 | |||||||
Tensile strength | ISO 10319 | kN/m | 16 | 21 | 27 | 32 | 45 | |||||||
strain at max. load | ISO 10319 | % | 50 | 50 | 50 | 50 | 50 | |||||||
Trouser Tear Strength | ISO 13937-2 | kN | 0.42 | 0.51 | 0.66 | 0.89 | 0.96 | |||||||
CBR Puncture max. force | ISO 12236 | kN | 3.1 | 3.6 | 4.1 | 4.9 | 7.6 | |||||||
elongation at max. force | ISO 12236 | mm | 38 | 38 | 38 | 38 | 38 | |||||||
UV Str. Ret. after 500 lt. hrs. exposure | ASTM D7238 | % | 70 | 70 | 70 | 70 | 70 | |||||||
For non woven geotextile shipment, in order to avoiding water when shipping on the boat, we specially use a thin layer plastic firm to
package the geomembane in the side, then white or black woven bags for outside, paper tube inside, easy to load and download.
Paste our label or as per client request, loading them into container safely at our factory, make all goods arriving clients no
damage, keep perfect. They are packed in the woven bags 50m/roll,100m/roll or follow your demand
Shipping: load container directly from our plant by truck, then go to the port, than go your site by sea.
package the geomembane in the side, then white or black woven bags for outside, paper tube inside, easy to load and download.
Paste our label or as per client request, loading them into container safely at our factory, make all goods arriving clients no
damage, keep perfect. They are packed in the woven bags 50m/roll,100m/roll or follow your demand
Shipping: load container directly from our plant by truck, then go to the port, than go your site by sea.
Company Profile
Our company is located in Zhangqiu, Shandong-the hometown of the famous merchant, Luochuan Meng. Set up in 2002 year,
Our company enjoys a favorably geographical location and convenient transportation conditions. We are near Ji-Qing Highway to the south and Jinan International Airport to the south. Our company has a registered capital of RMB 20 million and a fixed asset of more than RMB 60 million.
After many years of dedicated efforts in the basic research and application development of geotechnical synthetic materials, our company has now grown into a large-scale specialized geotechnical synthetic material enterprise, integrating the research & development, production, sales, construction and service. In 2002, our Zhangqiu Diaozhen Town Industrial Park was put into production. The park covers a land area of 70000 square meters and is equipped with all necessary various facilities. Our major production facilities include three-layer co-extrusion film blowing machines (inner-cooling automatic width control), high-elevation stentering systems introduced from Germany and geomembrane production lines (calendering methods). Moreover, we are the first company to introduce 7-meter-width geotextile production lines, 7-meter-width composite geomembrane production lines, geo-grid production lines and bottom plate lines in China. We are capable of producing various geotechnical synthetic materials.
Our major products include short fiber needle punched geotextile, PET spunbonded geotextile, composite geomembrane, geomembrane (HDPE, LDPE and LLDPE), PE/EVA/ECB/PVC water-proof board, swelling soil waterproof layer, composite drainage network, composite waterproof and drainage board, geogrid, steel-plastic grid, geo-nets, geo-cell, rubber water-proof strip, plastic blind drain, soft permeable pipe and other waterproof, drainage, water-saving & flood prevention material. Our company also provides engineering design consultation service. We can annually produce 20000 tons of geomembrane with the thickness from 0.1mm to 3.0mm, 16 million square meters of geotextiles from 100g to 800g, 10 million square meters of composite geomembrane (one non-woven fabric with one piece of membrane, two non-woven fabric with one piece of membrane, and multiple non-woven fabric with multiple membrane), 8 million square meters of bottom plates, 5 million square meters of swelling soil waterproof layers, 6 million square meters of composite drainage networks and 15 million square meters of geo-grids. Our products are widely applied in hydraulic engineering (reservoirs, channels and dams), landfill places, mines, power plants, sea walls, subways, airports, tunnels, railways, highways, artificial lakes, environmental protection places, gardens and other engineering places.
Our products are well sold to various regions in China, and are exported to South Africa, Algeria, Russia, Australia and Israel. Our company has passed ISO9001:2000 International Quality System Certification, ISO14001:2004 Environment Management System Certification and GB/T28001:2001 Vocational Health and Safety System Certification. Besides, our company has successfully passed on-site check on production license, and has gained "National Industrial Product Production License" and water-proof qualification. We have been the member of Chinese Technical Association on Geosynthetics and have been recognized as a "Provincial-level Enterprise Abiding by The Contract, Keeping Promise" for several successive years. Besides, we were awarded with the titles of "One of Top 10 Famous Brands with Recognized Quality Assurance Standards in China's Plastic Products Industry", "Well-Known Products in China" and "One of Top 10 Enterprises among China's Composite Geomembrane Industry". We have obtained self-supporting import and export rights.
After many years of dedicated efforts in the basic research and application development of geotechnical synthetic materials, our company has now grown into a large-scale specialized geotechnical synthetic material enterprise, integrating the research & development, production, sales, construction and service. In 2002, our Zhangqiu Diaozhen Town Industrial Park was put into production. The park covers a land area of 70000 square meters and is equipped with all necessary various facilities. Our major production facilities include three-layer co-extrusion film blowing machines (inner-cooling automatic width control), high-elevation stentering systems introduced from Germany and geomembrane production lines (calendering methods). Moreover, we are the first company to introduce 7-meter-width geotextile production lines, 7-meter-width composite geomembrane production lines, geo-grid production lines and bottom plate lines in China. We are capable of producing various geotechnical synthetic materials.
Our major products include short fiber needle punched geotextile, PET spunbonded geotextile, composite geomembrane, geomembrane (HDPE, LDPE and LLDPE), PE/EVA/ECB/PVC water-proof board, swelling soil waterproof layer, composite drainage network, composite waterproof and drainage board, geogrid, steel-plastic grid, geo-nets, geo-cell, rubber water-proof strip, plastic blind drain, soft permeable pipe and other waterproof, drainage, water-saving & flood prevention material. Our company also provides engineering design consultation service. We can annually produce 20000 tons of geomembrane with the thickness from 0.1mm to 3.0mm, 16 million square meters of geotextiles from 100g to 800g, 10 million square meters of composite geomembrane (one non-woven fabric with one piece of membrane, two non-woven fabric with one piece of membrane, and multiple non-woven fabric with multiple membrane), 8 million square meters of bottom plates, 5 million square meters of swelling soil waterproof layers, 6 million square meters of composite drainage networks and 15 million square meters of geo-grids. Our products are widely applied in hydraulic engineering (reservoirs, channels and dams), landfill places, mines, power plants, sea walls, subways, airports, tunnels, railways, highways, artificial lakes, environmental protection places, gardens and other engineering places.
Our products are well sold to various regions in China, and are exported to South Africa, Algeria, Russia, Australia and Israel. Our company has passed ISO9001:2000 International Quality System Certification, ISO14001:2004 Environment Management System Certification and GB/T28001:2001 Vocational Health and Safety System Certification. Besides, our company has successfully passed on-site check on production license, and has gained "National Industrial Product Production License" and water-proof qualification. We have been the member of Chinese Technical Association on Geosynthetics and have been recognized as a "Provincial-level Enterprise Abiding by The Contract, Keeping Promise" for several successive years. Besides, we were awarded with the titles of "One of Top 10 Famous Brands with Recognized Quality Assurance Standards in China's Plastic Products Industry", "Well-Known Products in China" and "One of Top 10 Enterprises among China's Composite Geomembrane Industry". We have obtained self-supporting import and export rights.
FAQ
1. who are we?
We are based in Shandong, China, start from 2002,sell to South America(60.00%),Africa(28.59%),North America(10.00%),Mid East(1.41%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Geomembrane,Geotextile,Drainage board,GCL,Composite geomembrane
4. why should you buy from us not from other suppliers?
Tinhy is a leading Geosynthetics manufacturer with more kinds of earthwork products, professional in producing and installing, the products pass CE, ISO and MSDS certificates.
We have more than 13years experience to research and produce geomemebrane Etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU；
Accepted Payment Currency:USD,EUR,AUD,HKD;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Shandong, China, start from 2002,sell to South America(60.00%),Africa(28.59%),North America(10.00%),Mid East(1.41%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Geomembrane,Geotextile,Drainage board,GCL,Composite geomembrane
4. why should you buy from us not from other suppliers?
Tinhy is a leading Geosynthetics manufacturer with more kinds of earthwork products, professional in producing and installing, the products pass CE, ISO and MSDS certificates.
We have more than 13years experience to research and produce geomemebrane Etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU；
Accepted Payment Currency:USD,EUR,AUD,HKD;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
* Non-woven geotextile membranes
Bale Opener---Cabin blender---Carding Machine---Cross Lapper---Draffer---Needle---Calender---Cutting and Winding
Mechanical bonding: It can be divided into two categories: acupuncture and spun lace. Needling is a physical method that uses a
barbed needle to redirect some fibers from horizontal to vertical, thereby mechanically interlocking the fiber web. Using spun
lace technology, high-pressure multi-drainage jets replace mechanical needles to reorient and entangle the loose fiber array into
a self-locking and coherent fabric structure. It should be noted that a significant proportion of needle punched nonwovens are
used for geotextile applications.
barbed needle to redirect some fibers from horizontal to vertical, thereby mechanically interlocking the fiber web. Using spun
lace technology, high-pressure multi-drainage jets replace mechanical needles to reorient and entangle the loose fiber array into
a self-locking and coherent fabric structure. It should be noted that a significant proportion of needle punched nonwovens are
used for geotextile applications.
Tinhy Geosynthetics non woven geotextile features and applications
Features:
Combines filtration properties and high water permeabilityHigh resistance to puncture and abrasion
Large choice of thickness of fabric (weight)
Top level protection at high strain
Excellent chemical compatibility.
Long-term performance in terms of strength and durability.
Extend the service life of roads and railways.
A cost-effective and environmentally friendly alternative to traditional building materials.
Prevent bank soil erosion.
Easy to install.
Long-term performance in terms of strength and durability.
Extend the service life of roads and railways.
A cost-effective and environmentally friendly alternative to traditional building materials.
Prevent bank soil erosion.
Easy to install.
Common Applications:
Landfill
Landscaping
Roof Garden
Drainage Application
Root Barrier System
Road Construction
As a weed barrier fabric in landscaping
Filtration when soils are very fine such as clays and silts
As a filter sock material for perforated pipe
Can be used to combine separation and water filtration
Landscaping
Roof Garden
Drainage Application
Root Barrier System
Road Construction
As a weed barrier fabric in landscaping
Filtration when soils are very fine such as clays and silts
As a filter sock material for perforated pipe
Can be used to combine separation and water filtration
Filtration
Soil separation
Erosion & sediment control
Protection for geomembrane liners
Sub-grade stabilization
Shoreline protection
Railroad stabilization
Roadway separation
Containment
Subsurface drainage
Gas venting
Under riprap or around pipes
Soil separation
Erosion & sediment control
Protection for geomembrane liners
Sub-grade stabilization
Shoreline protection
Railroad stabilization
Roadway separation
Containment
Subsurface drainage
Gas venting
Under riprap or around pipes
Tinhy Geosynthetics clients visit
Our HDPE geomembranes, non woven geotextiles, GCL, Geocomposite drainage boards, Geocomposite drainage net have been widely exported to the United States, Mexico, Chile, Ecuador, Russia, Kazakhstan, South Africa, Indonesia, the Philippines, India. A large number of customers visit our company every year and have reported to customers for aquaculture fish and shrimp pond farming, landfills, lagoons, and environmental protection.
Tinhy Geosynthetics exhibitions
We participate in industry exhibitions, environmental protection exhibitions, and aquatic products exhibitions every year to conduct industry exchanges, learning, customer exchanges and visits, and to solve communication problems for customers in a timely manner. At the exhibition, we can provide customers with better and faster HDPE geomembrane, HDPE liner, GCL, non woven geotextile anti-seepage solutions and provide more good service.
Tinhy Geosynthetics company activities
In order to improve the company's corporate culture, employee cohesion, product quality, and better serve customers, the company will hold half-year meetings, annual meetings, employee training meetings, employee exchange meetings, employee birthday parties, employee travel, and organize various activities every year. We are a big family, love the company, love employees, love customers, love our environmental protection business more, and contribute to a green planet
Похожие товары
Геомембрана HDPE 2 00 мм для сточных вод отходов угольной шахты химических заводов зефирей
SDM 8000 литровый резервуар для воды пруд рыбы/пластиковый аквариума/контейнер выращивания рыбы аквариума
0,28-0,88 $
0 2 мм 4 6 1 3 HDPE геомембранный вкладыш для пруда
0,25-0,56 $
Геомембранные накладки для бассейна HDPE LDPE PVC EPDM Geomembranes свалки
Полиэтиленовый полиэтилен низкой плотности рулонная пленка вьетнамская мембрана geo для дорожного строительства
0,43-0,50 $
Геомембраны из полиэтилена
0,21-0,32 $
Hdpe пруд лайнер геомембраны ремонт утечки
0,32-0,35 $
Новые поступления
Новинки товаров от производителей по оптовым ценам
Высокое качество Sunpal 450W-600W 48V фотоэлектрические солнечные панели 500W 500Wp 600W заводская цена с белой задней простыней
0,28-0,32 $
2025 руиба новый продукт зажим для пуповины оптовая продажа медицинский стерильный одноразовый пластиковый
Оптовая продажа индивидуальные синие 3-слойные одноразовые маски для лица хирургические медицинские защитные взрослых
40-41,80 $
Съемная пластиковая ручка штукатурка строительный инструмент для отделки бетона с помощью меток
SHIDU U30 двойной беспроводной Перезаряжаемый Профессиональный UHF микрофон караоке с
39,90-57,40 $
1688 закупка Taobao дропшиппинг агент по покупке онлайн-покупки Китай в Испания Румыния Литва от двери до ddp servic
1 $
OEM стираемая зеленая пластиковая клипса с держателем для ручки магнитная футбольная тренировочная
2-2,80 $
