Тестер сопротивления attery тестер емкости батареи для измерения внутреннего

Сохранить в закладки 1600311463548:


Цена:73 238,70 ₽ - 219 716,10 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики

Feature:
1.Three functions of charging, discharging and activation. It can used online and offline;
2.Parameters such as charge-discharge current, upper and lower limits of charge voltage can be set freely;
3.Charging: adopt standard three stage charge method “constant current, voltage limiting →constant voltage, current limiting →floating charge”;
4.Discharging: according to set discharge, it carries on fixed constant-current discharge;
5.Activation: adopt the unique “impulse type” activation mode, effectively eliminate the sulfuric acid phenomenon of storage
battery, maximum recover battery performance;
6.2V/12V compatible design;
7.Use LCD screen display in English, operation is simple and easy to use;
8.All the parameters are displayed in real time and automatically stored in the instrument, no lost when power off;
9.Multiple self-protection functions: reverse connection, fault connection and over-temperature;
10.It’s small and light and can be carried by one person, easy to use, safe and reliable.

 Product Parameter
Model
ZC-DC12/10
Applicable battery type
2V
Charge &discharge current
0-10A
Current setting step
0.1A
Precision of constant current
±0.5%
Voltage Testing accuracy
±0.5%
Communication interface
USB
Data storage
Built-in FLASH memory, support power off save
Power
220V
Software
The operating system:Win2000 / XP / 7
Remark
Other voltage levels, currents or special requirements can be customized
Details Images
Our Advantages
The Schematic diagram of three-stage charging Process
Stage I: Constant-current limit voltage charge. Stage II: Constant-voltage limit current charge. Stage III: Floating charge.
The Operation Systerm
Click “Curve” button and it will display as shown
