GEYA REVO VM кВт автономный солнечный инвертор производитель 24 В 102VDC MPPT контроллер низкочастотный трансформатор Электрический с TUV
- Категория: >>>
- Поставщик: Zhejiang Geya Electrical Co. Ltd.
Сохранить в закладки 1600312201280:
Описание и отзывы
Характеристики
********This link price is for inverter REVO VM2200-24********
MODEL | REVO VP 1000-12 | REVO VM 1200-12 | REVO VP 2000-24 | REVO VM 2200-24 | REVO VP 3000-24 | REVO VM 3200-24 | REVO VP 5000-48 | REVO VM 5000-48 | ||||||||
Rated Power | 1000VA/1000W | 1200VA/1200W | 2000VA/2000W | 2200VA/2200W | 3000VA/3000W | 3200VA/3200W | 5000VA/5000W | |||||||||
INPUT | ||||||||||||||||
Voltage | 230 VAC | |||||||||||||||
Selectable Voltage Range | 170-280 VAC(For Personal Computers); 90-280 VAC(For Home Appliances) | |||||||||||||||
Frequency Range | 50 Hz/60 Hz(Auto-sensing) | |||||||||||||||
OUTPUT | ||||||||||||||||
AC Voltage Regulation (Batt. Mode) | 230VAC±5% | |||||||||||||||
Surge Power | 2000VA | 4000VA | 6000A | 10000VA | ||||||||||||
Efficiency (Peak) | 90%~93% | |||||||||||||||
Transfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances) | |||||||||||||||
Waveform | Pure sine wave | |||||||||||||||
BATTERY | ||||||||||||||||
Battery Voltage | 12VDC | 24 VDC | 48 VDC | |||||||||||||
Floating Charge Voltage | 13.5 VDC | 27 VDC | 54 VDC | |||||||||||||
Overcharge Protection | 16 VDC | 31 VDC | 33 VDC | 63 VDC | ||||||||||||
SOLAR CHARGER& AC CHARGER | ||||||||||||||||
Solar Charger type | PWM | MPPT | PWM | MPPT | PWM | MPPT | PWM | MPPT | ||||||||
Maximum PV Array pen Circuit voltage | 55 VDC | 102 VDC | 80 VDC | 102 VDC | 80 VDC | 102 VDC | 105VDC | 145VDC | ||||||||
Maximum PV Array Power | 600 W | 700 W | 1200 W | 1400 W | 1200 W | 1800 W | 2400 W | 3000 W | ||||||||
MPPT Range @ operating Voltage | N/A | 17~ 80 VDC | N/A | 30~ 80 VDC | N/A | 30~80 VDC | N/A | 60~115 VDC | ||||||||
Maximum Solar Charge Current | 50A | 50A | 50 A | 50A | 50A | 65A | 50A | 65A | ||||||||
Maximum AC Charge Current | 20A | 20A | 20A | 20A | 25A | 25A | 60A | 60 A | ||||||||
Maximum Charge Current | 50A | 60A | 50A | 60 A | 70A | 80 A | 110A | 120A | ||||||||
PHYSICAL | ||||||||||||||||
Dimension, DxWxH(mm) | 88×225 x320 | 103×225 x320 | 88×225 x320 | 103×245 x 330 | 100 x285 x334 | 118,3×285 360.4 | 100×300 x440 | 100x 302 x440 | ||||||||
Net Weight (kgs) | 4.4 | 4.4 | 5 | 5 | 6.3 | 6.5 | 8.5 | 9.7 | ||||||||
Communication interface | USB/RS232 | |||||||||||||||
ENVIRONMENT | ||||||||||||||||
Humidity | 5% to 95%Relative Humidity (Non-condensing) | |||||||||||||||
operating Temperature | -10℃ to 50℃ | |||||||||||||||
storage Temperature | -15℃ to 60℃ | |||||||||||||||
