UP3000 M6322 EPEVER UPower Инвертор солнечной энергии 3 кВт 24 В автономный солнечный инвертор Гибридный с контроллером солнечного заряда 60A 220 MPPT
- Категория: >>>
- Поставщик: Shenzhen Suns Energy Co. LimitedShenzhen Limited
Сохранить в закладки 1600317794491:
Описание и отзывы
Характеристики
Product Description
UP3000-M6322 Solar Power Inverter 3KW 24V Off Grid Solar System with 60A MPPT Solar Charger Controller 220V for EPEVER Upower
Model Number:
| UP1000-M3212 | UP1000-M3222 |
| UP1500-M3222 | UP2000-M3322 |
| UP3000-M2142 | UP3000-M3322 |
| UP3000-M6142 | UP3000-M6322 |
| UP5000-M6342 | UP5000-M8342 |
| UP5000-M10342 |
UPower Series
Inverter/Charger
Overview
UPower inverter/charger combines with solar utility charging and AC output in one unit, which adopts a multi-core processor design and advanced MPPT control algorithm to realize intelligent management. The device is usually used in remote area where is lack of reliable utility but rich of sun shine.
Specifications:
| Model | UP3000-M3322 | UP3000-M6322 | UP3000-M2142 | UP3000-M6142 |
| System battery voltage | 24VDC | 24VDC | 48VDC | 48VDC |
| Battery input voltage range | 21.6~32VDC | 21.6~32VDC | 43.2~64VDC | 43.2~64VDC |
| Inverter output | ||||
| Continuous output power | 2400W | 2400W | 2400W | 2400W |
| Output power (15min.) | 3000W | 3000W | 3000W | 3000W |
| Overload power(5s) | 4800W | 4800W | 4800W | 4800W |
| Max. surge power | 6000W | 6000W | 6000W | 6000W |
| Output voltage range | 220VAC±3%,230VAC(-7%~+3%) | |||
| Output frequency | 50Hz/60Hz | |||
| Output wave | Pure Sine Wave | |||
| Distortion THD | ≤3%(12V or 24V resistive load) | |||
| Inverter efficiency | 95% | 95% | 95% | 95% |
| Transfer time | 20mS | |||
| Utility input | ||||
| Utility input voltage range | 160VAC~280VAC(Working voltage range) | |||
| 170VAC~270VAC(Utility starting voltage range) | ||||
| Max. utility charge current | 30A | 30A | 15A | 15A |
| Solar charging | ||||
| Max. PV open circuit voltage | 100V | 150V | 150V | 150V |
| 92V | 138V | 138V | 138V | |
| Max. PV input power | 780W | 1500W | 1040W | 3000W |
| Max. PV charging current | 30A | 60A | 20A | 60A |
| Equalization voltage | 29.2V | 29.2V | 58.4V | 58.4V |
| Boost voltage | 28.8V | 28.8V | 57.6V | 57.6V |
| Float voltage | 27.6V | 27.6V | 55.2V | 55.2V |
| Tracking efficiency | ≤99.5% | |||
| Charging conversion efficiency | ≤98% | |||
| Temperature compensate coefficient | -3mV/℃/2V (Default) | |||
| Others | ||||
| No load consumption | ≤0.8A | ≤0.8A | ≤0.6A | ≤0.6A |
| Enclosure | IP30 | |||
| Relative humidity | < 95% (N.C.) | |||
| Working environment temperature | -20℃~50℃(100% input and output) | |||
| Mechanical Parameters | ||||
| Dimension(mm) | 444×300×126 | 518×310×168 | 444×300×126 | 518×310×168 |
| Mounting dimension(mm) | 230 | |||
| Mounting hole size | Φ8mm | |||
| Weight | 9.2kg | 14.9kg | 7.3kg | 14.7kg |
| At minimum operating environment temperature | ||||
| At 25℃ environment temperature | ||||
Remarks:
UP as reliable industrial standard equipment has quick response speed and excellent high transfer efficiency. Intelligent adjustment of total charging current from both solar and utility, automatic adjustment is realized via different working modes selection, which ensure to provide power energy supply maximally.
The PV charging module adopts the up-to-date optimized MPPT tracking technology, it can quickly track the maximum power point of the PV array in any environment even has the multi crest tracking ability. The MPP tracking speed and energy transfer efficiency is quite high. The PV and AC charge current can be adjusted manually, which can meet total charge current limit, and PV & utility charge current ratio distribution. Full electronic protection functions are available.
