C1118-8P Specification | ||
GE | C1118-8P | |
GE/SFP combo | N/A | |
ADSL2/VDSL2+ | 1 | |
LTE Advanced (CAT6) | 1 G.SHDSL | |
802.11ac | N/A | |
GE | N/A | |
PoE | 4 | |
PoE+ | 2 | |
Integrated USB 3.0 AUX/console | 1 | |
Pluggable | Yes | |
Memory (default and maximum) | DRAM: 4 GB, Flash: 4 GB | |
Console | · Micro USB console (USB 3.0). | |
Mini-USB port (reserved) | · Micro-USB port to support remote LTE diagnostics and monitoring tools (Qualcomm CAIT and Spirent UDM) (USB 3.0). | |
Standard safety certifications | · UL 60950-1.and EN 60950-1. · CAN/CSA C22.2 No. 60950-1. · CB to IEC 60950-1, 2nd edition with all group differences and national deviations. | |
EMC emissions | · EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, and EN61000-6-1. | |
EMC immunity | · EN55024/CISPR24, (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11), and EN300-386. | |
Radio immunity | · EN301 489-1, EN 301 489-7, and EN301 489-24. | |
Cellular radio | · EN 301 908-1, EN 301 908-2, EN 301 511, 47 CFR Part 22, 47 CFR Part 24, and EN 301 908-13. | |
Environmental operating range | · Nonoperating temperature: -4° to 149°F (-0° to 65°C). · Nonoperating humidity: 5% to 95% relative humidity (noncondensing). · Nonoperating altitude: 0 to 15,000 ft (0 to 4570 m). · Operating temperature: 32° to 104°F (0° to 40°C). C1101 support 32° to 113°F (0° to 45°C). · Operating humidity: 10% to 85% relative humidity (noncondensing). · Operating altitude: 0 to 10,000 ft (0 to 3000 m). | |
Nonoperating humidity | 5 to 95% relative humidity (noncondensing) | |
Nonoperating altitude | 0 to 15,000 ft (0 to 4570m) | |
AC input current range, AC power supply (maximum) | 7.1 to 3.0A | |
AC input surge current | 60 A peak and less than 12 Arms per half cycle | |
Typical power (no modules) (watts) | 48 | |
Maximum power with AC power supply (watts) | 430 | |
Maximum power with PoE power supply (platform only) (watts) | 990 | |
Maximum endpoint PoE power available from PoE power supply (watts) | 500 |
