Android 9 OS Oem производитель Ip67 Прочный планшет Водонепроницаемая камера USB 4G беспроводной GPS Wifi автомобиль планшетный ПК
- Категория: >>>
- Поставщик: Shandong Senter Electronic Co. Ltd.
Сохранить в закладки 1600340573707:
Описание и отзывы
Характеристики
Overview
Powerful Industrial Android Rugged Tablet
S917V10 adopts Qualcomm MSM8953 Octa core 2GHz CPU and Android 9.0 operation system; 4G RAM, 64G ROM,4G LTE.
1980*1200 500 nits screen is readable under sunlight; Optional functions like barcode scanning, RFID reader, fingerprint
identification
It has 10000mAH battery (Wide temperature battery); IP67 high reliable three-proof structure water/dust proof; drop resistance
from 1.2m.
1980*1200 500 nits screen is readable under sunlight; Optional functions like barcode scanning, RFID reader, fingerprint
identification
It has 10000mAH battery (Wide temperature battery); IP67 high reliable three-proof structure water/dust proof; drop resistance
from 1.2m.
Video
Pictures
Application
Industrial tablet computer, also known as industrial touch panel computer, has all the functions of ordinary tablet computer, and also has an integrated touch design. It can be operated independently without a mouse and keyboard. The operation is portable and simple. It is currently in the industrial field. Used extensively. Common application industries for industrial tablet computers include medical equipment, environmental protection monitoring, communication security, intelligent traffic control systems, building monitoring and security, POS counter cash registers, CNC machine tools, fuel dispensers, financial information processing, petrochemical data acquisition and processing, geophysical prospecting, and field Portable operations, environmental protection, military industry, electric power, railways, highways, aerospace, subways, smart buildings, outdoor advertising, etc.
Key Features
Advanced system
Android 9.0 operating system,CPU Qualcomm MSM8953,8core 2GHz ,RAM 4G ROM 64G,Micro SD 128GVisble under strong light
10 inch LCD screen,1920*1200IPS capacitive touch screen with 500 nits brightness
Powerful function
Multi function, 1D/2D bar code scanning,LF/HF/UHF RFID reader,fingerprint identification
Multi communication modes
3G/4G,WIFI,BT and many wireless commnication modes
Support jcaket extension
Satisfy custom applications from customers
Industrial protection
IP68 three protection grade,drop resistance from 1.2m
Battery
38Wh,10000mAh,endurance is about 12 hours
Certification
CCC/CE/ROSH/FCC/IP67/MIL-STD-810G
Dimension
277*183*19mm,1109g
General Specifications
General Specification | ||||||||
Display Screen | 8 inch LCD screen,1920*1200IPS screen,500 nits brightness standard capacitive touch screen | |||||||
Operating System | Android 9.0 | |||||||
CPU | Qualcomm MSM8953,8 core,2.0GHz,RAM 4G ROM 64G,Micro SD maximum 512G | |||||||
USB port | Type-C port;Support to connect U-disk/Mouse/Keyboard/OTG line | |||||||
HDMI | HDMI port | |||||||
OTG | Through OTG can meet 100M network port,network card setup,PPPoE dial-up,web browsing.Support OTG extend RS232 serial port/RJ45 port/485 serial port) | |||||||
External port | Charge port,headphone port | |||||||
Protection Grade | ||||||||
Industrial Protection Grade | IP67 | |||||||
Drop Grade | Drop resistance from 1.2m | |||||||
Wireless Communication | ||||||||
BT | Support 4.2 | |||||||
GPS | Support GPS,BDS,GLONASS,accuracy about 10 meters | |||||||
WIFI | IEEE 802.11a/b/g/n/ac,2.4G and 5G dual band | |||||||
2G/3G/4G LTE | China/India: LTE FDD:B1/B3/B5 LTE TDD:B34/B38/B39/B40/B41 WCDMA:B1/B8 TD-SCDMA:B34/B39 EVDO/CDMA:BC0 GSM:900/1800MHz Europe/Africa: LTE FDD:B1/B3/B5/B7/B8/B20/B28 LTE TDD:B38/B40/B41 WCDMA:B1/B2/B5/B8 GSM:850/900/1800/1900MHz America: LTE FDD:B2/B4/B5/B7/B8/B12/B13/B14/B25/B26 LTE TDD:B41 WCDMA:B1/B2/B4/B8 GSM:850/1900MHz | |||||||
Physical Parameters | ||||||||
Camera | 5MP front camera,13MP rear camera with automatic focus and lighting function | |||||||
Keyboard | Android menu,Homepage,Return,Volume+ -,Barcode,ON/OFF,Reset | |||||||
Headset | 3.5mm audio Interface | |||||||
Mic and Loudspeaker | Support | |||||||
LED indicator light | Support(ordinary flicker,Call fast flicker,missed calls,charge indicator) | |||||||
Flashlight Function | Support,can be used for emergency lighting | |||||||
Gravity Sensor | Support | |||||||
Compass | Support | |||||||
Gyroscope | Support | |||||||
Acceleration Sensor | Support | |||||||
Light and distance Sensor | Support | |||||||
Vibrating motor | Support | |||||||
FM | Support | |||||||
Lithium Battery | 3.8V,10000mAh temperature wide battery,Supporting working 2.5-3 hour on -20°C | |||||||
Dimension | 232*158*22mm | |||||||
Weight | 810g | |||||||
Enviromental Characteristics | ||||||||
Working Temperature | -20°C~+60°C | |||||||
Storage Temperature | -40°C~+70°C | |||||||
Humidity | 5%-95%relative humidity;no condensation | |||||||
Optional function | ||||||||
Barcode Scanning | 1D Laser Scanner Index(Internal): Honeywell N4313 or Zebra EM1350 Scannning speed :104 times/second+12times/second(two way sanning) Scannning distance:2.5cm-114.3cm Scanning angle:47±3°(default)35±3°(reduced code) 2D Barcode Scanner Index(Iternal) Newlands EM3096 Honeywell N3680 Motorola SE4750 Honeywell N6603 Identification ability:1D,2D,OCR Scanning angle:rotate 360°,incline±50°,deflection±50° Field of View:Horizontal 36°，vertical23° Depth of field:4cm-23.5cm Enviromental Luminace:0~100000LUX | |||||||
RFID | HF RFID(Internal) Support NFC/NXP,13.56MHz ISO14443A,B and ISO15693 protocol,reading distance 0-3cm,Tag support type:SR176,SRIX4K(TYPE-B),I-Code2,TI RFID Tag-it HF-I,EM4034,Mifare Classic ETC LF RFID(Internal): 134.2KHz LF RFID support ISO11784/5 protocol,support to read IC card(FDX/HDX) 125KHz LF RFID,support to rea ID card UHF RFID(Internal): Ray links RLM060 or ThingMagic M6E-NANO,EPC C1 GEN2/ISO18000-6C,Output power 10dBm-30dBm Reading distance:1m Ceramic antenna:0.3db(25*25*4mm) | |||||||
Far infrared meter reading | Working frequency 37.9K | |||||||
Fingerprint read module | Supports fingerprint entry,image collection,fingerprint recognition,fingerprint deletion etc. Type:TCSIST Sensor type :capacitive Effective image size:12.8*18.0mm Image size:256*360 Resolution :508ppi(dpi) contrast mode(1:1);search mode(1:N) FIPS 201 ompliant capability(TCS1) | |||||||
Our Company
ABOUT US
Shandong Senter Electronic Co., Ltd. was founded in 1996, is a Telecommunication test and maintenance solution provider. Annual
sales 50 million USD in year 2018. SENTER owns more than 400 staffs, covers an area of 20,000 square meters. Main product include
Android Telecom Test PDA, PON ID Reader, 10G/1G PON Power Meter, ONU tester, OTDR, Fusion Splicer, VDSL Tester, OPM, Laser source.
sales 50 million USD in year 2018. SENTER owns more than 400 staffs, covers an area of 20,000 square meters. Main product include
Android Telecom Test PDA, PON ID Reader, 10G/1G PON Power Meter, ONU tester, OTDR, Fusion Splicer, VDSL Tester, OPM, Laser source.
Company Profile
· Shandong SENTER is the first short-listed enterprise of China Unicom and China Telecom Group's instrument centralized purchasing collection
· Telecom Test PDA ST327 has been sold more than 150,000 units in Markets,Markets share first in China operators
· Fully passed the ISO9001 international quality system certification
· Products comply with CE certification, has software copyright 34 items
· “High-tech enterprises” and “software companies” granted by the government
· SENTER has total 161 patent applications, including 49 invention patents
FAQ
Q: How to order and pay?
A: We accept T/T (bank transfer), Western Union / Trade Assurance / Crypto-Currency BTC/LTC/ETH/Cash.
Q: What's Your Products Warranty?
A: We Offer 12 Months Warranty after shipment sent.
Q: How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we could send the parts or components and teach customer to fit if they have technician or can also send back to us to fix it.
