Литий ионная аккумуляторная батарея большой мощности 18650 24 в 2500 мАч для солнечных уличных фонарей систем видеонаблюдения

Сохранить в закладки 1600344480743:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Your Lithium Battery














Hot-sale Products






































































































































































































Parameter of 24V Split-type solar street light battery pack(NCM battery)
Battery packBattery specification22.2V10AH22.2V20AH22.2V30AH22.2V40AH22.2V50AH
Cell type18650 NCM lithium-ion battery cell
Cell capacity2500mAh
Norminal voltage22.2V
Norminal capacity10AH20AH30AH40AH50AH
Cell layout6S4P6S8P6S12P6S16P6S20P
BMS current15A
Cycle life800~1000 cycles
Depth of discharge≥97%
Charge cut-off votltage25.2V
Discharge cut-off votltage16.8V
Solar inputAdvised PV input power20~40W40~60W60~80W80~100W100~130W
PV input voltage36V
ControllerCharge methodPWM
Discharge methodFlat/rise voltage, continuous current
Charge current15A(MAX)
Discharge current3.3A(MAX)
load(LED-1W)24V:10~18 series
Output voltage24V:30~55V
Dimming value10%~90%
Working modeProgrammable, works 8 hrs per night, 3hrs*80%+3hrs*40%+2hrs*20%(load power)
LoadAdvised load power10W20W30W40W60W
Voltage platform24V
Advised pole height3m4m6m8m10m
Continuous working days3 days
Other infoWorking temperature-20℃~+60℃
Warranty2 years
IP levelIP65
Weight(Approx)2kg3.2kg4.5kg5.8kg7kg
Shell size(plastic)272*204*80mm360*232*76mm380*231*76mm
Shell size(aluminum)220*160*95mm300*160*95mm500*160*95mm600*160*95mm700*160*95mm
Input terminal2pin, 2*1.5mm2, 15cm long, male connector
Output terminal4pin, 4*0.75mm2, 15cm long, male connector
AccessoryPV cable2pin, 2*1.5mm2, 50cm long, female connector
Load cable4pin, 4*0.75mm2, 250cm long, male connector

 Details_01.jpgDetails_02.jpgDetails_03.jpgDetails_04.jpgDetails_05.jpgDetails_06.jpgDetails_07.jpgDetails_08.jpgDetails_09.jpgDetails_10.jpg



Our Advantage











Company Information










Certifications








Packaging & Shipping








FAQ





1.What products do you make?
We provide lithium ion battery for street light, customized lithium battery pack for the most electrics appliances, solar storage battery, electric bicycle battery, and portable power station.

2.Do you provide OEM service?
YES. The required quantity is 200 pcs and above.
3.How long does it take for sampling?
It takes 2-3 days for small battery pack(with capacity below 50AH), and 4~7days for big battery pack(with capacity above 50AH).
4.How long is your lead time?
The lead time is 5~7 days for orders with quantity below 50 pcs, 8~15 days for 50-300 pcs, and 10~20 days for 500 pcs and above.
5.How do you ship the goods?
We generally ship the sample via DHL, UPS, EMS, Fedex, TNT, and normal orders by sea or by air, depends on the quantity of the order. If you need us to arrange shipping for you, we will approach the best method to lower your cost.
6.How do you guarantee the quality?
Our production is proceeding with the guideline of ISO9001 quality management system and we have a strict QC procedure for picking out unqualified products, which is battery capacity classifying, aging, sampling inspection, general testing, discharge testing and appearance checking, with all the procedure gone over, we can control the faulty rate below 0.003%.
7.How long is your warranty?
3 years for solar street light battery, battery pack and solar storage battery, 1 year for portable power station. Besides, all of our products have been insured by CPIC, so please rest assured of the safety performance.
8.For solar street light battery, what should I know about rainy or cloudy days?
The battery for solar street light is hardly being charged during rainy or cloudy days, so it should be customized to be capable for working in the worst weather condition locally, so please let us know how long are the continuous rainy or cloudy days that your could estimate.
