Products Description
Esclarecedor de placas lamelar Lamella Separators Clarifier lamella clarifier Sedimentation tank Inclined plates clarifier enhancement WWTP inclined tube settler sedimentation tank lamella clarifier industrial waste water
The lamella separator (also lamella clarifier) separates settleable solids (particles) from liquids and is used for instance in the treatment of process water and waste water.Basically all solids that sediment in a given time, can be separated easily and economically with the lamella separator. Depending on the density those are usually solids larger than approximately 50 μm in diameter. For separating smaller particles and turbid substances, flocculants are used in order to create settleable flakes.Dairy Industry And Distillery Manual Lamella Clarifier
Lamella Separators PARALLEL PLATE LAMELLA CLARIFIERS TUBE SETTLERS PARALLEL PLATE CLARIFIERS Lamella Plate Vertical Clarifiers Inclined Clarifier increased flow reduced footprint Lamella Clarifier inclined plate settler IPS | ||||||||||||||||
Model | Capacity (m3/h) | Dimensions(m) | Piping Connections | |||||||||||||
L | W | H | Inlet (a) | Effluent (b) | Sludge (c) | Backwash(d) | ||||||||||
LBJ | 5 | 2.55 | 1.6 | 3 | 80 | 80 | 50 | 50 | ||||||||
10 | 3.35 | 1.82 | 100 | 100 | 50 | |||||||||||
15 | 3.35 | 2.02 | 100 | 100 | ||||||||||||
20 | 3.35 | 2.02 | 100 | 100 | ||||||||||||
30 | 4.2 | 2.22 | 150 | 150 | ||||||||||||
40 | 4 | 2.8 | 150 | 150 | ||||||||||||
50 | 4.65 | 2.82 | 200 | 200 | ||||||||||||
60 | 4.7 | 3.0 | 200 | 200 | ||||||||||||
70 | 6.4 | 2.6 | 250 | 200 | ||||||||||||
80 | 6.8 | 2.82 | 250 | 200 | ||||||||||||
100 | 7.05 | 3.02 | 250 | 250 | ||||||||||||
Lamella Clarifier can be customized based on raw water quality, quantity, effluent request, project situation | ||||||||||||||||
Application
Lamella Inclined Plate Clarifier is mainly used for the wastewater pretreatment and the rear end of the aerobic pool.
♦ Industrial wastewater treatment ♦Affordable water for industrial production ♦Industrial Chemistry - purification and enrichment♦Pulp & paper mills♦Iron and steel industry, phosphorus removal♦Metal hydroxide wastewater♦Sealed / vacuum filtration♦Purification of biological cleaning process♦Circulating water from potatoes and vegetables
♦Water treatment of dust remover in power plant lamella plate clarifier Package Lamella Clarifier System Lamella packs
♦Water treatment of dust remover in power plant lamella plate clarifier Package Lamella Clarifier System Lamella packs
lamella clarifiers for municipal wastewater treatment
COMPACT DIMENSIONSINCREASING SETTLEMENT AREA
SAFETY FRAME SIMPLE CONTROL EASY MAINTENANCE
PVC PLATES HIGH STRENGTH EQUIPPED BACK-WASHING PARTS Lamella Separator Settler Tilting Dishwasher
SAFETY FRAME SIMPLE CONTROL EASY MAINTENANCE
PVC PLATES HIGH STRENGTH EQUIPPED BACK-WASHING PARTS Lamella Separator Settler Tilting Dishwasher
PARALLEL PLATE LAMELLA CLARIFIERS TUBE SETTLERS
Lamella Clarifier lamella water treatment Waste Lamella Clarifier wastewater treatment industrial process water Sloping dishwasher lamella clarifier wastewater treatment Tilting dishwasher wastewater treatment
Suspended solids removal for metal plating and finishing wastewater
Package Lamella Clarifier System reduce turbidity for lake water, river water and pond water,Paper mills wastewater treatment pulp and water recycling
Pretreatment for food processing and slaughterhouse wastewater
reduce turbidity for water from coal mine, mineral processing,Solid pollutants removal for tannery wastewater, Polishing of biological treatment effluent
Color and impurities removal for textile dyeing wastewater
remove cr, cu, Fe, Zn, Ni etc heavy metal ion in electroplate effluent,Suspended solids removal for dairy wastewater,For chemical wastewater treatment - Other solid-liquid separation
Work shop
Company Profile
FAQ&Shipping
Slant Plate Clarifier Package Lamella Clarifier System lamella clarifiers for municipal wastewater treatment
Customized Products; No Standard Specification Sheet.
Please provide these below information to us, so that we can check and provide professional solution for you.
- Wastewater Source:
i.e. Where or which industry does the wastewater comes from?
- Wastewater Quantity:
i.e. How many cubic meter(m3) wastewater should be purified per hour?
- Working Hours:
i.e. How many hours do you prefer to run this wastewater treatment equipment per day?
- Wastewater Quality Analysis Report
If you have this report, please send us one copy, that will be help for design and calculation.
Please provide these below information to us, so that we can check and provide professional solution for you.
- Wastewater Source:
i.e. Where or which industry does the wastewater comes from?
- Wastewater Quantity:
i.e. How many cubic meter(m3) wastewater should be purified per hour?
- Working Hours:
i.e. How many hours do you prefer to run this wastewater treatment equipment per day?
- Wastewater Quality Analysis Report
If you have this report, please send us one copy, that will be help for design and calculation.
