Safety Binding Leash Polyester Straps Seat Belt Harness Slings Pattern Sewing Machine.






Product Character


1. The operation of this computer pattern machine is very simple. It only needs three steps: inputting patterns, putting materials in, and pressing the foot pedal.





No matter how complex the pattern is, it can be perfectly sewn at one time, and anyone can skillfully operate the machine in a very short time.





2. Help enterprises save manpower, reduce scrap rate, improve quality, improve production efficiency, and provide customer satisfaction, so as to improve the core competitiveness of the company.





3. The machine can sew any pattern you want, including straight line, curve, rectangle, square, circle, herringbone, embroidery, herringbone, fork, polygon, regular and irregular, within a limited range and with a needle pitch of 0.1mm-12.7mm.





4. The pattern can be permanently stored in the internal memory of the host or your own USB flash disk as long as you input the design once, which is convenient for you to carry and use on other computer pattern machines.





5. The machine has the functions of automatic stop, automatic thread cutting, automatic thread loosening, automatic thread dialing, automatic presser foot lifting, etc. it can be used for selection and simple operation. It is suitable for sewing uppers, gloves, trademarks, clothing, pet crafts, tourism products, automobile safety belts, Velcro, belts, watch belts, plastics and other patterns of all kinds of fabrics.





6. Wide application range, strong stability, can adapt to various difficult movements, fast speed, labor saving, double large rotary shuttle, more stable and beautiful stitch.











Technical data





Technical specification:

























































































Item No:



GT-5030



Sewing rang :



50cm X 30cm



Sewing speed:



2700-3500rpm/min



Work holder lift:



25mm (max:30mm)



Stepping foot lift:



20mm



Stepping foot stoke:



4-10mm (Optional)



Hook :



Double capacity hook



Stitch Formation:



Single needle Lock Stitch



Motor :



750W direct drive servo motor



Memory device:



USB



Stitch Length:



0.1-12.7mm



Needle :



DP*17(#16-#23)



Operation screen:



7 inch LCD touch control panel



Voltage :



Single phase 220-240V



Presser foot system:



Air pressure.



Air pressure :



0.5Mpa 1.8L/min



Memory Card:



999 patterns



Max. needle number:



Each pattern 20,000 needles.



Packing size :



150x150x165cm



G.W/N.G:



300kgs/250kgs.















Detail Image





5030 pattern machine 1





Electric control system with stable performance: DAHAO electric control system supports multiple languages. Easy to learn and use, complete functions.





5030 pattern machine 7





High processing precision, imported accessories, long service life.





5030 pattern machine 6





The material and processing of the casing body shall be in strict accordance with the original Mitsubishi process standard with class u tolerance.





5030 pattern machine 5





 T5 polyurethane steel wire synchronous belt.





5030 pattern machine 4





Double shaft device, stable feeding.





5030 pattern machine 3





High quality high-precision gear, accurate fit, low wear.





gear wheel


hook





Double capacity hook.





5030 pattern machine 13





Great wisdom, multi-purpose, small footprint, multi-function.





5030 pattern machine 10





Original factory, high quality with reasonable price.





5030 pattern machine 12





Private customization(with different working size, multifunctional) is acceptable.











Recommended Products








































Application display





Computer pattern sewing machine is widely used for sewing patterns of handbags, clothing, textiles, leather products, bags, shoes, belts, sports leisure equipment and so on.


It is suitable for sewing uppers, gloves, trademarks, clothing, pet crafts, tourism products, automobile safety belts, Velcro, belts, watch belts, plastics and other patterns of all kinds of fabrics.






2Wide Application








Company Information


-1_02


1_07 2Production--Line-4factory 1





FAQ




-1_03




Q1. Are you a factory?
  Re. Yes.  we are both a trading company an
d a factory, and we only focus on excellence sewing machine.


Q2.How about your machine quality?


  Re. I cannot answer to you from our side. But our customer said to us our machine quality is good and high, use it about two years no change voice and vibration. After you use it, you will more understand our quality.


Q3. How about your price?


  Re. Our price not expensive, but also not very cheap, in general, quality is better than price


Q4. How long could your sewing machine be used?
  Re. Generally, more than 6 years.


Q5. What is the shipping port?
  Re. We ship the goods via Guangzhou port or as you like


Q6. How about payment ?


  Re. At beginning cooperation, 100% TT in advance, or LC at sight for big amount order , after we have good cooperation, we will try to accept DP OR DA payment


Q7. Can you do OEM or ODM for us?


  Re. Yes, of course, and we also can do all kinds of the sewing machine by customized.


Q8. Can you supply spare parts?


  Re. Yes, of course we can.


Q9.  What guarantee you can supply ?


Re: Limited spare parts one-year guarantee, not including quick-wear parts, like needle, hook, needle plate.
