Испаритель с тонкой пленкой 200 1000 л/ч/испаритель поднимающейся пленкой/испаритель
- Категория: >>>
- Поставщик: Nanjing Ningkai Instrument Co. Ltd.
Сохранить в закладки 1600384920644:
Описание и отзывы
Характеристики
Product Description
Falling film evaporation is to add the feed liquid from the upper tube box of the heating chamber of the falling film evaporator, and distribute it evenly into each heat exchange tube through the liquid distribution and film forming device. Under the influence of gravity and vacuum induction and air flow, it forms a uniform film. Flow up and down. During the flow process, it is heated and vaporized by the shell-side heating medium, and the generated steam and liquid phase enter the separation chamber of the evaporator together. After the vapor and liquid are fully separated, the steam enters the condenser to condense (single-effect operation) or enters the next-effect evaporator as The medium is heated to achieve multi-effect operation, and the liquid phase is discharged from the separation chamber.
Specification
Model | FFE-100L | FFE-200L | FFE-300L | FFE-500L | |||
Evaporation Rate | 100L/hr | 200L/hr | 300L/hr | 500L/hr | |||
Feeding Pump | Flow:1m3/h, Lift:14m, Power:0.55kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:0.55kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:0.75kw,explosion-proof | Flow:2m3/h, Lift:24m, Power:1.5kw,explosion-proof | |||
Circulating Pump | Flow:1m3/h, Lift:16m, Power:0.75kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:0.75kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:1kw,explosion-proof | Flow:3m3/h, Lift:24m, Power:1.5kw,explosion-proof | |||
Condensate pump | Flow:1m3/h, Lift:16m, Power:0.75kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:0.75kw,explosion-proof | Flow:1m3/h, Lift:18m, Power:1kw,explosion-proof | Flow:2m3/h, Lift:24m, Power:1.5kw,explosion-proof | |||
Vacuum pump | Model:2BV-2060 Max pumping speed:0.45 m2/min, Ultimate vacuum:-0.097MPa, Motor power:0.81kw,explosion-proof Speed:2880r.min, Working fluid flow:2L/min, Noise:62dB(A) | Model:2BV-2061 Max pumping speed:0.86 m2/min, Ultimate vacuum:-0.097MPa, Motor power:1.45kw,explosion-proof Speed:2880r.min, Working fluid flow:2L/min, Noise:65dB(A) | Model:2BV-2071 Max pumping speed:1.83 m2/min, Ultimate vacuum:-0.097MPa, Motor power:3.85kw,explosion-proof Speed:2860r.min, Working fluid flow:4.2L/min, Noise:72dB(A) | Model:2BV-5110 Max pumping speed:2.75 m2/min, Ultimate vacuum:-0.097MPa, Motor power:4kw,explosion-proof Speed:1450r.min, Working fluid flow:6.7L/min, Noise:63dB(A) | |||
Panel | <50kw | <50kw | <50kw | <50kw | |||
Height | Around 2.53m | Around 2.75m | Around 4.3m | Around 4.6m | |||
Electricity | 220V/380V /460V 3 Phase,50- 60Hz | ||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Details Images
Company Profile
1.Professional
We are a professional manufacturer which is specialized in designing,producing and saling. Meanwhile,we obtained many patents,all of our products is being innovated all the time.
2.Superior Quality and Moderate Price
With advanced technology and high-end equipment, all of our products are made with the highest quality. To guarantee zero defect
rate, we do quality control before shipping to our customers.According to our strong manufacture and supply chain structure,we can
provide our customers with competitive pricing.
3.OEM and ODM
We have strong developing team to support OEM and ODM service. The products can be made according to every customer’ requirement.
4.Efficient and Safe Transportation
We have good cooporation with leading international shipping companies such as DHL/UPS/FedEx/TNT to provide various sea shipping
and air shipping options.After we received the payment, we can ship them within 3 days , it will need 4 to 6 days from Shanghai to your place by DHL express.Strict packing process to ensure the safty and completeness of the goods.
5.Great Customer Service
Over 30 years of expertise, our customers can expect a high level of satisfaction. We provide professional Pre-sale,sale,after sale Service for every customer.
We are a professional manufacturer which is specialized in designing,producing and saling. Meanwhile,we obtained many patents,all of our products is being innovated all the time.
2.Superior Quality and Moderate Price
With advanced technology and high-end equipment, all of our products are made with the highest quality. To guarantee zero defect
rate, we do quality control before shipping to our customers.According to our strong manufacture and supply chain structure,we can
provide our customers with competitive pricing.
3.OEM and ODM
We have strong developing team to support OEM and ODM service. The products can be made according to every customer’ requirement.
4.Efficient and Safe Transportation
We have good cooporation with leading international shipping companies such as DHL/UPS/FedEx/TNT to provide various sea shipping
and air shipping options.After we received the payment, we can ship them within 3 days , it will need 4 to 6 days from Shanghai to your place by DHL express.Strict packing process to ensure the safty and completeness of the goods.
5.Great Customer Service
Over 30 years of expertise, our customers can expect a high level of satisfaction. We provide professional Pre-sale,sale,after sale Service for every customer.
FAQ
Q1. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 7 to 10 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We also can design for you.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 7 to 10 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We also can design for you.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
