Китай Лучшая цена под заказ латунные булавки Pogo соединители пружинные Позолоченные

Описание и отзывы

Характеристики

Advantage of pogo pin:

Spring Loaded Pogo Pin, test pin, contact probe and receptacle are developed especially for testing electrical requirements in a veriety of applications. They provide a reliable means to test in bare or loaded printed circuit boards and other circuitries where a number of contact points must be accessed.

 Photo of pogo pin:

Material and Plating Treatment:

Barrel: Brass, Bronze, Beryllium Copper

Plunger: Brass, Bronze, Beryllium Copper

Spring: Stainless steel, Music wire

Pleating Treatment: Nickel-plated or gold-plated over nickel

Technical Specification:

Head Style: Concave, Convex, Flat, Spear Point, Serrated, Star, Spherical Radius

Diameter of Barrel: 0.68mm, 1.01mm, 1.37mm, 2.02mm, 2.36mm

Spring Pressure: 80g, 100g, 150g, 200g, 250g

Reference: Pogo Pin connector, Test Probe, Contact Probe, pin connector, cnc machining pogo pin and probe

***********************************************************************************

<<Model: OEM-038>>

Material

Material of Plunger: Brass, gold-plated

Material of Barrel: Brass, gold-plated

Material of Spring: Stainless steel

Technical Specification

Size: 2.5x6mm

Full Travel: 2.0mm

Spring Pressure(+/- 20%): 40g

Current Rating: 2A, continuous

***********************************************************************************

<<Model: OEM-036>>

Material

Material of Plunger: Brass, gold-plated

Material of Barrel: Brass, gold-plated

Material of Spring: Stainless steel

Technical Specification

Size: 3x8mm

Full Travel: 3mm

Spring Pressure(+/- 20%): 60g

Current Rating: 5A, continuous

Contact Resistance: <40m ohm

If you have any inquiry, please do not hesitate to contact our sales team
