Прецизионный стол для проверки гранита завод в Китае высокая точность хорошее

Granite flat surface is in black color with bright, homogeneous structure,good stability, high hardness, anti-rust and chemical-resistance.

Material: Black Jinan granite, India Black Granite

Standard: GB/T 20428-2006, DIN876, JIS

Specification: The maximum workability is 10000mm in length, 8000mm in width and 800mm in height or customized (special size is acceptable following customers’ requirement)

Surface: T-slots, dovetail-shaped slots, holes, etc.

Hardness of the working surface: more than HS70

Surface treatment: ground finish

Precision grade: 00-1

Packaging: Export wooden box

ND Group -------Precision Granite Department

1.Our History

ND Group has focused on top quality precision granite products, cnc machine, laser machine and so on for over many decades. We are one of the largest company in manufacturing granite mechanical components in China.

ND has 6 subsidiaries all over the world that located in Shanghai, Jinan, Beijing, Shenzhen, Hongkong and Japan. Our big customers include HEXAGON, US BOEING, South Korea's SAMSUNG, LG group, Chinese High Train, Big Plan C919 etc.

Until now, ND Group has been one of the top producers of a variety of precision granite products, such as granite base, granite assy, granite square, precision granite surface plate, granite float guides and so on.

2. Our Factory

ND factory is at the foot of Black Jinan Granite mine which boasts rich mineral resources and advantaged resource condition. It has complete machinery processing equipment, is equipped with advanced electronic detection instrument, realizes computer data processing and has a group of high-quality dedicated staffs.

The factory has more than 200 employees,including professional and technical personnel 140 people .The main granite products include mechanical components, bridge, assy, gantry, inspection plate, angle plate, parallel, square rulers, guideway, block, measuring device, precision machine base, cube, surface plate stand, V block, air bearing, pillars, column etc..In product production and testing progress, following DIN876/GB/204228-2006 rock and JJG117-2013 flat panel measurement verification regulations, our products in domestic and international markets have enjoyed a high reputation.

 3. Our certificates and Patents:

4. Our Customers:

1. Our sale managers are always avialable.

2.we can take photos and video about the process from starting to manufacture your products and send them to you so that you can know every detail all the time.

3. All customers will have their own special service worker to answer their questions.

4. We have a strong After-service team. We can offer service in fixing rails, screw and motors on site. We also could fix your products as semi-finished and then delivery them. It can save your a lot of time.

1. What precision can you make?

We can manufacture high precision according to DIN 876 standard. Our head office are specialized in ultra-precision inspection and control for many years and we have many advance inspection machines.

2. Do you have any certificates and Inspection reports?

Many certificates such as CE, BUV, ISO9001 etc has been obtained.

Each of our product will be tested by many times in different time within one week and then we will make report by our Head Office. By the way, our ultra-precision inspection and control technologies are used on Chinese big plane--C919, High Train and big ship. We also cooperate with US Boeing.

3. Is there white line, spot or crack on granite surface plate?

It’s normal that there is white line, spot or crack on the natural granite. But We have a lot of processes to test granite material. Our head office is specialized in ultra-precision inspection for many years. We can not only detect the white lines, spots and cracks on the granite surface, but also detect the internal cracks in the granite!

It is very easy to find white line, crack on granite surface, but it’s very difficult to find the internal crack in the granite. We all worked in precision field and know how importance of precision and stability of granite surface plate. If there is a internal crack in granite, it will mostly threat our workers’ life, and it will also affect the precision of granite surface plate.

 Why many supplier do not make internal inspection in granite even they how importance for precision and stability if there is a internal crack?

1) The Inspection cost is too high. They can not afford a suit of inspection devices.

2) The material cost is high. Some suppliers will choose bad material only the surface is good even they there is a internal crack. They will try to repair it to make the appearance looks good.

Our head office cooperated with German company, XRD and NDT are our products, which can be used inspect the internal crack in granite!

We can choose excellent material for you!

4. What should we do when we get granite surface plate?

1) Open the package for checking. If there is any Knocked wounded on the products, do not worry, take photos and video and send them to : serviceatnd-cnc.com.

Our After-service team will contact you within 0.5 hours and deal with it!

2)If everything is ok, please put your products in constant temperature plant for 24 hours. And then you could use it!

Selling Units:  more than 1 piece

Package Type: Granite surface plate export wood case and container.

Lead  Time: we can finish your products within 25 days

Contact me for more information: arvinatnd-cnc.com     Whatsapp/Wechat: +86-15069133209
