Пожарная машина в Таиланде воздушный пожарный грузовик запасной поставщик
33 000,00-33 200,00 $
Пекин Yongshi бренд 4x4 двухрядный лес водяной грузовик с пожарным
- Категория: >>>
- Поставщик: Hubei Jiangnan Special Automobile Co. Ltd.Hubei Ltd.
Сохранить в закладки 1600424950166:
Описание и отзывы
Характеристики
Product Description
Beijing Yongshi brand 4x4 double row forest water truck with firefighter
Product features: Fire water supply vehicle
Customization: Yes
Capacity: 2.360 L
Engine model :YCY24140-60A
Crew/seats :5
Chassis model :BAW2043HMS61D
Rated power: 103kW
Rated load :103kg
Tyre size: 265/70R16lt 10PR
Tyre number: 4
Emission standard: Country 6
Drive mode :4*4
Dimensions (l * W * H):5640*1870*2080mm
Spare mass :2840kg
The wheelbase: 3695 mm
Shaft: 2
Total quality: 4465 kg
Maximum torque :123nm
Maximum speed :4465km/h
Type of fuel: gasoline
Type: water supply fire engine
Customization: Yes
Capacity: 2.360 L
Engine model :YCY24140-60A
Crew/seats :5
Chassis model :BAW2043HMS61D
Rated power: 103kW
Rated load :103kg
Tyre size: 265/70R16lt 10PR
Tyre number: 4
Emission standard: Country 6
Drive mode :4*4
Dimensions (l * W * H):5640*1870*2080mm
Spare mass :2840kg
The wheelbase: 3695 mm
Shaft: 2
Total quality: 4465 kg
Maximum torque :123nm
Maximum speed :4465km/h
Type of fuel: gasoline
Type: water supply fire engine
Beijing Warrior country 6 2 tons of forest fire water supply vehicle 2 side emergency fire water supply vehicle. Effective tank volume 1.36 cubic meters; Transport medium: water, density :1000 kg/m3; Tank size (long × long axis × short axis)(mm):1250×1500×1000;
The vehicle
Dimensions: 5640,5790 mm×1870 mm×2080 mm
Crew: 2+3
Water tank: volume 1360 L
Water pump: flow 30L/7MPa
Water cannon: flow rate 30L/S@0.7MPa, range not less than 45m.
chassis
Model: BAW2043HMS61D
Drive type: 4×4
The wheelbase: 3695 mm
Engine: Model YCY24140-60A, inline four cylinder, water cooled, high pressure common rail, supercharged intercooled diesel engine. Rated output power: 103KW. Emission standard: ⅵ
Transmission: mechanical manual transmission with 5 forward gears
Transfer box: four-wheel drive mechanical manual, full drive/rear drive two gear conversion
Steering system: left, hydraulic power steering, steering wheel height and Angle adjustable
The braking system
Service braking: vacuum assisted braking
Parking brake: central drum brake
Auxiliary braking: engine exhaust braking
Speed: 120 km/h
Power extractor: full power sandwich type extractor, solenoid valve control, splash lubrication.
Iii. Driving room
1. Structure: integral steel frame welded flat head cab, fixed type.
2. Layout: double row, four doors, 2+3 passengers.
3. Equipment: In addition to the equipment of the original vehicle, it is also equipped with the power switch, side sign light switch, hand throttle and so on.
Four, jacket
(1) tank body
1. Volume: 1300L (water).
2. The structure:
Square and square welding structure, internal partition board.
Manhole and manhole cover 1 set, diameter φ500 mm.
The water injection pipe is located on the right side of the tank and the diameter is DN65.
One sewage pipe, located at the bottom of the tank, diameter DN40.
3. Material: welded by carbon steel, the thickness of cylinder is 3mm, the thickness of head is 4mm. The inner wall is treated with anticorrosion,
The vehicle
Dimensions: 5640,5790 mm×1870 mm×2080 mm
Crew: 2+3
Water tank: volume 1360 L
Water pump: flow 30L/7MPa
Water cannon: flow rate 30L/S@0.7MPa, range not less than 45m.
chassis
Model: BAW2043HMS61D
Drive type: 4×4
The wheelbase: 3695 mm
Engine: Model YCY24140-60A, inline four cylinder, water cooled, high pressure common rail, supercharged intercooled diesel engine. Rated output power: 103KW. Emission standard: ⅵ
Transmission: mechanical manual transmission with 5 forward gears
Transfer box: four-wheel drive mechanical manual, full drive/rear drive two gear conversion
Steering system: left, hydraulic power steering, steering wheel height and Angle adjustable
The braking system
Service braking: vacuum assisted braking
Parking brake: central drum brake
Auxiliary braking: engine exhaust braking
Speed: 120 km/h
Power extractor: full power sandwich type extractor, solenoid valve control, splash lubrication.
Iii. Driving room
1. Structure: integral steel frame welded flat head cab, fixed type.
2. Layout: double row, four doors, 2+3 passengers.
3. Equipment: In addition to the equipment of the original vehicle, it is also equipped with the power switch, side sign light switch, hand throttle and so on.
Four, jacket
(1) tank body
1. Volume: 1300L (water).
2. The structure:
Square and square welding structure, internal partition board.
Manhole and manhole cover 1 set, diameter φ500 mm.
The water injection pipe is located on the right side of the tank and the diameter is DN65.
One sewage pipe, located at the bottom of the tank, diameter DN40.
3. Material: welded by carbon steel, the thickness of cylinder is 3mm, the thickness of head is 4mm. The inner wall is treated with anticorrosion,
Packing & Delivery
waxed before shipment
Company Profile
Established in 1995, Hubei Jiangnan Special Automobile Co., Ltd. is a professional manufacturer and exporter that is concerned with the design, development and production of Special Automobiles. We are located in Suizhou City, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
Covering an area of 150000 square meters, we now have over 1000 employees and an annual sales figure that exceeds USD100 Million. We are currently exporting 60% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Besides, we have received ISO9001, CCC and Government High Technology Enterprises certificates.
As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Southeast Asia, South America, Southeast Asia, Africa, Oceania, the Middle East and Eastern Asia. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
Covering an area of 150000 square meters, we now have over 1000 employees and an annual sales figure that exceeds USD100 Million. We are currently exporting 60% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Besides, we have received ISO9001, CCC and Government High Technology Enterprises certificates.
As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Southeast Asia, South America, Southeast Asia, Africa, Oceania, the Middle East and Eastern Asia. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
Exports
Customer Photos
FAQ
Q:How about the warranty?
A:One year
Q:Do you have ISO certificate ?
A:Yes , we have,pls contact us to get our certifications.
Q:How about the delivery time?
A: Most of our trucks are all have in stock ,We can delivery to you within 7 days, if specially ordered , we always need around 30 days for production.
Q:How about shipping ?
A:Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container , small type can shipping by container ,Pls contact us to get a shipping quotation .
Q: How many trucks does your factory produce per years?
A:Almost 3500 units
Q: How do you control the quality of product?
A:Our Factory is standard production workship,got ISO CCC BV Certification,our workers are well trained. Our very product under goes a scrutinizing inspection process.
Q: How about your product After-sales service system?
A:Our main export country have accepted after-sales service,some of country used the third department service.
Q: Do you accept Custom orders? What’s is your MOQ order?
A:Yes, we do, our MOQ is 1 set.
Q: What’s the payment terms?
A:By T/T or L/C at sight.
Q: How about your shipment?
A:Small one put into container,bigger one By Ro-Ro ship, Bulk ship,or 40FR.
