                      Concrete Road Surface Shot Blasting Cleaning Equipment For Sale






Product Description






Horizontal shot blasting machine blasts the pills on the road surface at high speed and certain angle by the method of mechinery , make pills impect the surface of the road and make the road surface roughness, reach the effect of removing residuum,at the same time,dust collector will produce negative pressure to make pills and impurities and dust dust recovery after air cleaning, intact pills will automatically be recycled to used, and impurities and dust will drop into the dust collecting box.










     Function of road surface blasting once will be enough clear away surface laitance of concrete and remove impurities, and can undertake  hair treatment on the surface of concrete, make its surface well-distributed roughness, greatly improving the adhesive strength of the waterproof layer and concrete base layer, so that the waterproof layer and bridge deck can better combination, and at the same time the crack of concrete can be fully exposed, have the effect of nip in the bud.





22124429











 Mobile shot blasting machine ,Road surface portable sand blasting machine, Portable sand blast equipment





How it works:


Shot material in the lower part of separation box is from the feeding tube into the blasting  compo nents and driven by the motor. The high-speed rotating shot will be thrown and stroke against the surface of workpieces at the speed of 80m/s. And thus carry out clean-up operation. Under the effect of negative pressure, the shot abrasive and dust will be back into sand separation box where the shot, dust and impurities will be separated completely. Good shot materia into the blast is expected to continue to use.


 20140605164836


Where is it used:


1. Cleaning the rubber on airport runway


2. Cleaning, derusting and depitching for the surface of steel structure


3. Maintenance of bridge


4. Ground floor project-based surface treatment


5. Maintenance of highways


6. Maintenance of municipal road


7. Mantenance and derusting of hull surface


8. Removal of zebra crossing


9. Other surface treatment........





 Products models

































































HC



HC270



HC550



HC850



Working width



270mm



550mm



850mm



Working efficiency



On the concrete surface






150m2/h



300m2/h



450m2/h







On the surface of steel plate


(SA2.5Depends on the steel corrosion degree)



30m2/h



60m2/h



100m2/h



Power



11KW



2*11KW



2*15KW



Walking speed



0.5-20m/min



0.5-20m/min



0.5-20m/min



Projectile consumption



100g/m2



100g/m2



100g/m2



Outline size



1940*380*


1100mm



1940*720*1100mm



1940*920*1300mm



Weight



~460kg



~650kg



~810kg






Notice:the Shot blast cleaning width can be Customized to produce by our company according to your requirements


HC550HC39HC550(2)





Cleaning effect





Main machineCleanging steel





                               On concrete                                                                   On steel





HC270





                       Marking line removal









Company Information


 We are QINGDAO HUACHUAN MACHINERY CO., LTD.  Located in the machinery manufacture base of QINGDAO Seaport (top 10 of world), develop for over 30 years of experience of R&D and sales, pass of ISO 9000 managment system & CE quality certification. As one of the leading machinery manufacturers such as: Shot/Sand blasting machine(polish the steel surface rust, strength the steel qulity suit for steel plate, road surface, H beam, outer/inside pipe, oil pipeline casting etc);





Our Services





1.Pre-sale services:





Provide the consultation of the equipment. According to the clients’ special requirement, offering the reasonable plan helping to select the equipment.Welcome to visit our factory.





2.Services during the sales:





Inspect the machine before leaving the factory.Oversea install and debug the equipment. Train the first-line operator.





3.After sale services:


Provide technical exchanging and timely problem solving support.














FAQ






Q1. Are you manufacturer?

Yes. We are one of leading manufacturers in China., also produce and export for more than ten years .

Q2. How to control your quality ?

First of all, we have professional technical team to design the machine. And we have strict production system, the quality inspection department will check the quality regularly.

Q3. Do you inspect the finished products?

Yes.Each step of products will be carried out inspection strictly, many times test good until shipping.

Q4. What's your machine quality guarantee?

Usually it's one year. We will choose the famous brand components to keep our machine in perfect working condition.

 Q5: How long is your delivery time?

It depends on the machine you order. Generally it is 5-7 days if the machine is in stock. And it will take 15-25days if customized type.

Q6: What is your payment term?

We accept T/T. Payment<=USD 2000, 100% in advance.
Payment>=USD 2000, 30% T/T in advance, balance before shipment.





If you are interested in this shot blasting machine ,


Please let me know freely.
