Высокоскоростной медицинский ткацкий станок с воздушной струей/медицинская линия по производству рулонов марли/ткацкий для
- Категория: Textile Dyeing Machines >>>
- Поставщик: Hefei Kerrian Machinery Co. Ltd.
Сохранить в закладки 1600436695552:
Описание и отзывы
Характеристики
Product Description
This medical gauze air jet loom machine is used to weave medical use jumbo gauze roll.
Technique and Specification:
1. Fabric type: plain, twill or satin
2. Machine working width:150cm
3. fabric width:142cm
4. fabric width:60cm
5. P.M/Speed:450-550
6. Thread count:12-48 pick per inch
7. Cotton yarn:16s-40s
8. Raw material requirement :non-sizing cotton yarn
9. Warp beam diameter:800mm
10. Cloth roller diameter will be ≤600mm
11. Production capacity: depends on thread count and R.P.M
12. Loom motor power:1.8KW
13. Electricity consumption:1.8kw/hour
14. Air consumption:0
15. One air pump is installed in the machine
16. Productionfor example:
120cm x 1000m
yarn 40`s or 32`s mesh 26*18
800m per day-24 hours
Above record is for your reference. The actual production maybe higher or lower, but almost correct record.
17.Machine size :3000 x 1800 x 1700mm (L x W x H)
18.Machine weight: 1500kg
Technique advantage
1) Low investment. this machine can run without air compressor, save much cost for electricity charge. And no need to make air
tunnel.
2) Can use non-sizing yarn to produce fabric by this machine, save the sizing cost also.
3) The production is much higher than shuttle loom and rapier loom.
4) This is the latest model machine, easy to operate, and low maintenance charge.
Technique and Specification:
1. Fabric type: plain, twill or satin
2. Machine working width:150cm
3. fabric width:142cm
4. fabric width:60cm
5. P.M/Speed:450-550
6. Thread count:12-48 pick per inch
7. Cotton yarn:16s-40s
8. Raw material requirement :non-sizing cotton yarn
9. Warp beam diameter:800mm
10. Cloth roller diameter will be ≤600mm
11. Production capacity: depends on thread count and R.P.M
12. Loom motor power:1.8KW
13. Electricity consumption:1.8kw/hour
14. Air consumption:0
15. One air pump is installed in the machine
16. Productionfor example:
120cm x 1000m
yarn 40`s or 32`s mesh 26*18
800m per day-24 hours
Above record is for your reference. The actual production maybe higher or lower, but almost correct record.
17.Machine size :3000 x 1800 x 1700mm (L x W x H)
18.Machine weight: 1500kg
Technique advantage
1) Low investment. this machine can run without air compressor, save much cost for electricity charge. And no need to make air
tunnel.
2) Can use non-sizing yarn to produce fabric by this machine, save the sizing cost also.
3) The production is much higher than shuttle loom and rapier loom.
4) This is the latest model machine, easy to operate, and low maintenance charge.
Specification
item | value |
Applicable Industries | Manufacturing Plant |
Showroom Location | China |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | Engine, Motor |
Condition | New |
Automatic Grade | Automatic |
Place of Origin | China |
Hubei | |
Brand Name | KERRIAN |
Voltage | 380V |
Power | 1.8kw |
Dimension(L*W*H) | 3000x1800x1700mm |
Weight | 1000KG |
Warranty | 1 Year |
Production Capacity | 450-550rpm |
Used for | air jet loom for medical gauze roll |
Machine Type | automatic |
Product name | medical gauze weaving machine |
Packing & Delivery
wooden box packing is made on request
Company Profile
As a mainstay subsidiary of China Kerrian Medical Technology Group, our company is engaged in producing and delivering medical dressing making and packing machines to worldwide with good quality, these machines have been delivered to more than thirty countries and won very good reputation. The machines can be designed and produced on users' different requests, and we always provide the best solution for our clients.
Besides machine production plant, we also have built a gauze weaving plant, for supplying raw material of jumbo gauze fabric roll, and medical gauze dressings, we have passed ISO13485 certificate already.
For further info, please feel free to contact us.
Thank you.
Besides machine production plant, we also have built a gauze weaving plant, for supplying raw material of jumbo gauze fabric roll, and medical gauze dressings, we have passed ISO13485 certificate already.
For further info, please feel free to contact us.
Thank you.
FAQ
1. who are we?
We are based in Anhui, China, start from 2016,sell to Eastern Asia(30.00%),Southeast Asia(20.00%),South America(10.00%),Eastern Europe(10.00%),Africa(10.00%),Mid East(10.00%),South Asia(10.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
medical gauze folding machine,cotton pad machine,gauze packing machine,medical bandage machine,gauze swab folding machine
4. why should you buy from us not from other suppliers?
with more than 20years experience in the production of medical dressings making and packing machines, we always provide machines with good quality by our advanced technology, we have delivered the machines to more than 40 countries and won good reputation
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
We are based in Anhui, China, start from 2016,sell to Eastern Asia(30.00%),Southeast Asia(20.00%),South America(10.00%),Eastern Europe(10.00%),Africa(10.00%),Mid East(10.00%),South Asia(10.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
medical gauze folding machine,cotton pad machine,gauze packing machine,medical bandage machine,gauze swab folding machine
4. why should you buy from us not from other suppliers?
with more than 20years experience in the production of medical dressings making and packing machines, we always provide machines with good quality by our advanced technology, we have delivered the machines to more than 40 countries and won good reputation
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
