Specifications of Graphite Gold Melting Crucible
Graphite Crucible
Crucible Melting Gold
Graphite Gold Melting Crucible
Good quality Graphite Gold Melting Crucible Description
Graphite Gold Melting Crucible is made by our high quality graphite block and widely used in all kinds of furnace to melt jewelry, gold, silver, copper, brass, aluminum, zinc, lead and so on. The size is as your requirement.
Good quality Graphite Gold Melting Crucible Features
High Strength, High Purity;
High Temperature Resistance;
High Machining Capabilities;
High Temperature Shock Resistance.
Graphite Crucible Melting Material
Our graphite crucible will give you the best suggestion according to your application. The material content vibrating forming graphite, moulded forming graphite, extruded forming graphite, isostatic forming graphite.
Graphite Crucible Technical Parameters
Description | Mode | Weight(g) | Size(mm) | |||
φ1 | φ2 | φ3 | H | |||
1kg Graphite Crucible | YJ-GC1000A | 160 | 58 | 35 | 47 | 88 |
1KG Ceramic Coat | YJ-CC1000A | 170 | 70 | 51 | 59 | 89 |
2kg Graphite Crucible | YJ-GC2000A | 240 | 65 | 44 | 57 | 110 |
2KG Ceramic Coat | YJ-CC2000A | 270 | 84 | 61 | 70.5 | 112 |
3kg Graphite Crucible | YJ-GC3000A | 390 | 85 | 60 | 75 | 105 |
3KG Ceramic Coat | YJ-CC3000A | 335 | 97 | 79 | 89 | 103 |
4kg Graphite Crucible | YJ-GC4000A | 500 | 85 | 60 | 76 | 131 |
4KG Ceramic Coat | YJ-CC4000A | 370 | 100 | 80 | 90 | 132 |
5kg Graphite Crucible | YJ-GC5000A | 700 | 100 | 69 | 89 | 131 |
5KG Ceramic Coat | YJ-CC5000A | 540 | 118.5 | 92 | 100.5 | 135 |
5.5kg Graphite Crucible | YJ-GC5500A | 800 | 105 | 70 | 90 | 156 |
5.5KG Ceramic Coat | YJ-CC5500A | 600 | 122 | 94 | 107 | 155 |
6kg Graphite Crucible | YJ-GC6000A | 970 | 115 | 79 | 97 | 178 |
6KG Ceramic Coat | YJ-CC6000A | 725 | 127 | 100 | 113 | 178 |
8kg Graphite Crucible | YJ-GC8000A | 1900 | 120 | 84 | 110 | 181 |
8KG Ceramic Coat | YJ-CC8000A | 920 | 143 | 112 | 132 | 182 |
Graphite Crucible Application
It can be used to melt jewelry, gold, silver and other precious metal. We will suggest the high purity graphite for you, because it does not have impurity and will not influence your precious metal.
