Carbonless Paper Coating Machine
800 DOUBLE SIDE CONDUCTING FILM COATING MACHINE is widly used for making CONDUCTING FILM ,RELEASE FILM and so on .
Suitable Material:
800 DOUBLE SIDE CONDUCTING FILM COATING MACHINE is mainly suitable for reel -type substrate coating production.
Characteristics:
1 overall machine adopt 6 frequency motor control, overall machine tension (unwinding, coating, traction, rewinding) adopt JAPANESE PLC to control tension automatic , through man machine interface touch screen to control and display to improve machine tension reliability
2 independent unwinding frame, adopt magnetic powder auto-control tension
3 gravure coating method, coating doctor blade shaft adopt heavy double shaft machine independent moving, blade adjust by manual with pneumatic, angle adjust freely, coating quantity depend the mesh of gravure roller, different coating quantity can change different mesh gravure roller.
4 two layer oven is uper 10m for 5section independently control, down layer oven 8m for 4section independently control, heating adopt electric, hot air intake drying system, heater outset,heating pipe adopt stainless steel with cooling fin type, adjustable inner cycle air intake and out device, air intake and out with strong air , dry thoroughly
5 oven inner guide wheel is active synchronous with the mainframe, drive adopt synchronous belt drive guide wheel to assure synchronous to reduce material stretch and deformation, cylinder pneumatic open oven and film pass operation panel so that worker can work very easily
6 the tension between coaitng roller and traction steel roller adopt float swing arm by PLC auto-control
7 auto-length and speed meter device
8 webguide adopt EPC air sensitive register to assure the trimness when rewinding
9 rewinding and unwinding adopt key type airshaft for easily operate when loading and unloading the material, air shaft take in/off adopt safety lock type
10 high presicion up press traction device, steel roller cooling adopt water cycle to make the film surface more smooth and neat.to reach good cooling effect.
11 rewinding frame is electric rotation double station, rewinding adopt frequency motor, vector inverter by PLC control
Specification
Coating method | Gravure coating |
Coating width | 800mm |
Unwinding dia. | Ø800mm |
Rewinding dia. | Ø800mm |
Oven length | Two layer oven, uper layer 10m, down layer 8m |
Oven temperature | 10-100°C |
Work speed | 10-80m/min |
Machine speed | 120m/min |
diamension | 12500×2600×5100mm |
Machine weight | 18000kg |
Total power | 32kw |
Oven heating power | Heating, 130kw, working 90kw |
Heating method | Electric |
Rewinding and unwinding form | Electric rotation double station |
Driven Type | Electric |
Company Profile
We are QINGDAO JIERUIXIN MACHINERY AND TECHNOLOGY CO.,LTD. which company is mainly working on paper coating machine, paper making machine and related technology. Through more than 20 years effort, Besides the machine self, we have our own chemist and prefer to supply chemical, formulation, technology and other suggestion to customers. Then our formulation will match our machines, and get the best quality paper for them. Now Our company had been one of the famous paper coating machine manufacturer in China and our coating machine and technology had been exported to Egypt, Mexico, Australia, India and etc.
Our Services ( We can provide turnkey works)
1.Reasonable suggestions for selection of equipment.
2.Provide detailed description and assembly drawing to make you more aware of the device ability to work.
3.Engineers on site equipment installation and commissioning.
4.Provide training for your employees.
5.Professional technical guidance and technical support during your production, make sure the device's work properly and production.
6.Equipment upgrade and remould.
7.We will testing installation machine in the factory workshop , to ensure safety and quality.
8.Supply chemical ,formulation ,technology and other suggestion to customers.
QINGDAO JIERUIXIN MACHINERY AND TECHNOLOGY CO.,LTD. the real person hood, steadfast work management concept, we warmly welcome all friends to visit.
Our Services ( We can provide turnkey works)
1.Reasonable suggestions for selection of equipment.
2.Provide detailed description and assembly drawing to make you more aware of the device ability to work.
3.Engineers on site equipment installation and commissioning.
4.Provide training for your employees.
5.Professional technical guidance and technical support during your production, make sure the device's work properly and production.
6.Equipment upgrade and remould.
7.We will testing installation machine in the factory workshop , to ensure safety and quality.
8.Supply chemical ,formulation ,technology and other suggestion to customers.
QINGDAO JIERUIXIN MACHINERY AND TECHNOLOGY CO.,LTD. the real person hood, steadfast work management concept, we warmly welcome all friends to visit.
Packing & Delivery
Wooden Case or Customized Package.
