Product Overview
We adopt highly vacuumed multi-circle insulation technology to produce the biological liquid nitrogen containers ,which have good performance of low temperature insulation ,and evaporation can be let down to minimum.
2. The lockable device can be installed to the container lid upon customer's requirements so as to protect biological samples stored (limit for 50mm,80mm and 125mm calibers)
3. Encoding system is applied on canisters for easy recognition and convenient accessing of samples
4. More than 1 years of vacuum quality guarantee is ensured with the multi-layer thermal isolation design
5. Not suitable for long –distance transportation or frequent pouring.
FEATURES AT A GLANCE
1. Shell and inner tank: aluminum alloy plate, light weight, high strength at low temperature,corrosion resistance
2. Neck tube: FRP, high mechanical strength, low thermal conductivity, etc.
3. High vacuum multi-layer thermal insulation design, low evaporation rate of liquid nitrogen, economical use.
4. Service life not less than 5 years
PRODUCT SPECIFICATIONS
Model | Capacity (L) | Mouth diameter (mm) | Outside diameter (mm) | Height (mm) | Empty weight (Kg) | Full weight (Kg) | Static evaporation loss (L/day) | Static hold time (day) | Canister Size D*H(mm) |
(L) | (mm) | (mm) | (mm) | (Kg) | weight | (L/day) | D*H | ||
(Kg) | (mm) | ||||||||
YDS2-35 | 2 | 35 | 180 | 410 | 2.1 | 3.7 | 0.07 | 28 | 25*120 |
YDS-3 | 3.15 | 50 | 224 | 425 | 3.2 | 5.7 | 0.1 | 32 | 38*120 |
YDS-6 | 6 | 50 | 285 | 460 | 4.4 | 9.2 | 0.1 | 61 | 38*120 |
YDS-10 | 10 | 50 | 305 | 530 | 6 | 14.1 | 0.1 | 101 | 38*120 |
YDS-10A | 10 | 50 | 305 | 605 | 7.6 | 15.7 | 0.09 | 112 | 38*276 |
YDS-13 | 13 | 50 | 305 | 605 | 7.6 | 18.1 | 0.1 | 131 | 38*276 |
YDS-15 | 15.2 | 50 | 355 | 600 | 8.6 | 20.9 | 0.1 | 158 | 38*120 |
YDS-16 | 16 | 50 | 355 | 600 | 8.6 | 21.5 | 0.1 | 168 | 38*276 |
YDS-20 | 21 | 50 | 355 | 620 | 9 | 26 | 0.1 | 212 | 38*120/276 |
YDS-30 | 31.5 | 50 | 455 | 670 | 13.8 | 39.2 | 0.11 | 298 | 38*120/276 |
YDS-35 | 35.5 | 50 | 455 | 720 | 17 | 45.6 | 0.11 | 326 | 38*120/276 |
YDS10-80 | 10 | 80 | 305 | 530 | 6.8 | 14.9 | 0.17 | 59 | 63*120 |
YDS30-80 | 31.5 | 80 | 455 | 670 | 14.6 | 40 | 0.18 | 175 | 63*120/276 |
YDS35-80 | 35.5 | 80 | 455 | 740 | 16.8 | 45.4 | 0.19 | 189 | 63*120/276 |
YDS30-125 | 31.5 | 125 | 455 | 690 | 16.8 | 42.3 | 0.28 | 113 | 97*120/276 |
YDS35-125 | 35.5 | 125 | 455 | 740 | 16.8 | 45.4 | 0.29 | 123 | 97*120/276 |
YDS60-210 | 63 | 210 | 560 | 900 | 27.8 | 78.7 | 0.68 | 93 | Rack |
YDS100-210 | 100 | 210 | 560 | 1100 | 31.2 | 112 | 0.85 | 117 | Rack |
Why Choose Us
Product Applications
Recommend Products
Company Profile
Henan Yuji Boiler Vessel Co., Ltd. is the general administration of quality supervision, inspection and quarantine of the People’s Republic of China approved the boiler and pressure vessel designated manufacturing enterprise, The company passes ISO 9001 international quality system certification, and gains the EU CE and other international certification ect.
We ensure the quality of our products with our life. Quality assurance systems are set, include the design production, technology management, material experiment, welding control, inspection and audit, measurement and production management. The technology center has enterprise cooperation relationship with Many famous universities in China, leading the industry with innovation and new technology, and building a strong research and development system.
We ensure the quality of our products with our life. Quality assurance systems are set, include the design production, technology management, material experiment, welding control, inspection and audit, measurement and production management. The technology center has enterprise cooperation relationship with Many famous universities in China, leading the industry with innovation and new technology, and building a strong research and development system.
FAQ
1. What information needed if we sent you the inquiry of the tanks?
The capacity, working pressure and the working medium is most important, and then your special request is also very important. If possible , tell us the usage, that will help us recommend the most appropriate tanks for you.
2. How about quality of your product ?
All the cryogenic liquid tanks are new.
All the material come from our direct suppliers, and all confirm with the national standard.
3. Is there any advantage of your price?
We have our own factory , and we are the direct supplier of our products, so your profit can be guaranteed totally.
4. How can you guarantee your cylinder quality?
For cryogenic liquid storage tank, leaking gas is one of the most important problems, so we make the leak testing more than 1 time to guarantee quality.
The capacity, working pressure and the working medium is most important, and then your special request is also very important. If possible , tell us the usage, that will help us recommend the most appropriate tanks for you.
2. How about quality of your product ?
All the cryogenic liquid tanks are new.
All the material come from our direct suppliers, and all confirm with the national standard.
3. Is there any advantage of your price?
We have our own factory , and we are the direct supplier of our products, so your profit can be guaranteed totally.
4. How can you guarantee your cylinder quality?
For cryogenic liquid storage tank, leaking gas is one of the most important problems, so we make the leak testing more than 1 time to guarantee quality.
