Product Description
Borosilicate 3.3 serves as a material of truly functional and wide applications:
1). Household electrical appliance (panel for oven and fireplace, microwave tray etc.);
2). Environmental engineering and chemical engineering (Lining layer of repellence, autoclave of chemical reaction and safety spectacles);
3). Lighting (spotlight and protective glass for jumbo power of floodlight);
4). Power regeneration by solar energy (solar cell base plate);
5). Fine instruments (optical filter);
6). Semi-conductor technology (LCD disc, display glass);
7). Iatrology and bio-engineering;
8). Safety protection (bullet proof glass)
1). Household electrical appliance (panel for oven and fireplace, microwave tray etc.);
2). Environmental engineering and chemical engineering (Lining layer of repellence, autoclave of chemical reaction and safety spectacles);
3). Lighting (spotlight and protective glass for jumbo power of floodlight);
4). Power regeneration by solar energy (solar cell base plate);
5). Fine instruments (optical filter);
6). Semi-conductor technology (LCD disc, display glass);
7). Iatrology and bio-engineering;
8). Safety protection (bullet proof glass)
Specification of Product
1) Dimension 600×1200mm(Max.800×2000mm )
2) Thickness 1.5~8mm
List of Thickness and Tolerance
Thickness mm Tolerance mm Thickness mm Tolerance mm
1.50 ±0.20 4.00 ±0.20
2.00 ±0.20 5.00 ±0.20
2.25 ±0.20 5.50 ±0.20
2.75 ±0.20 6.00 ±0.20
3.0 ±0.20 6.50 ±0.20
3.30 ±0.20 7.50 ±0.30
3.80 ±0.20 8.00 ±0.30
3) Net sized glass of strengthening can be supplied as per the customers requirement;
4) Glass of small cut size is available according the requirement from customers.
1) Dimension 600×1200mm(Max.800×2000mm )
2) Thickness 1.5~8mm
List of Thickness and Tolerance
Thickness mm Tolerance mm Thickness mm Tolerance mm
1.50 ±0.20 4.00 ±0.20
2.00 ±0.20 5.00 ±0.20
2.25 ±0.20 5.50 ±0.20
2.75 ±0.20 6.00 ±0.20
3.0 ±0.20 6.50 ±0.20
3.30 ±0.20 7.50 ±0.30
3.80 ±0.20 8.00 ±0.30
3) Net sized glass of strengthening can be supplied as per the customers requirement;
4) Glass of small cut size is available according the requirement from customers.
Performance of the Product
1). Mechanical Performance
Density ρ 2.23±0.02g/cm3
2). Thermodynamic Performance
Thermal expansion coefficient (0-300) 3.3±0.1×10-6K-1
Softening point 820±10
Strain point 516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient 1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
Long time(>10h): 450
3). Chemical Performance
Water resistance ISO719/DIN12111 HGB1/ISO720 HGA1
Acid resistance ISO1776/DIN12116 1
Alkali resistance ISO695/DIN52322 A2
4). Optical Property
Refractive index Nd: 1.47384
Transmittance spectrum curve
5). Electrical Property
Specific resistance lgρ 8.0Ω×cm at 250
Dielectric dissipation fraction tan σ (1 megacycle at 20): 38×10-4
Dielectric constant ε=4.7
Means of Processing for Customers：
Cutting
Round corner
Round edge
Surface fine polishing
Hole drilling
Coating
Surface printing and sand blasting
Thermal bending
Borosilicate fire resistant glass
Fire resistance glass for doors and windows
Fire resistance glass for cut off
Sealed insulating glass for cut off
Glass used in curtain walls
Fire resistance glass for ceiling,floor
1). Mechanical Performance
Density ρ 2.23±0.02g/cm3
2). Thermodynamic Performance
Thermal expansion coefficient (0-300) 3.3±0.1×10-6K-1
Softening point 820±10
Strain point 516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient 1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
Long time(>10h): 450
3). Chemical Performance
Water resistance ISO719/DIN12111 HGB1/ISO720 HGA1
Acid resistance ISO1776/DIN12116 1
Alkali resistance ISO695/DIN52322 A2
4). Optical Property
Refractive index Nd: 1.47384
Transmittance spectrum curve
5). Electrical Property
Specific resistance lgρ 8.0Ω×cm at 250
Dielectric dissipation fraction tan σ (1 megacycle at 20): 38×10-4
Dielectric constant ε=4.7
Means of Processing for Customers：
Cutting
Round corner
Round edge
Surface fine polishing
Hole drilling
Coating
Surface printing and sand blasting
Thermal bending
Borosilicate fire resistant glass
Fire resistance glass for doors and windows
Fire resistance glass for cut off
Sealed insulating glass for cut off
Glass used in curtain walls
Fire resistance glass for ceiling,floor
item | value |
Place of Origin | China |
Hebei | |
Brand Name | Aohong |
Model Number | Borosilicate Float Glass |
Warranty | Warranty |
Shape | Flat |
Structure | Solid |
Thickness | 1.5mm-8mm |
Product packaging
Plywood crate packing with paper between each glass sheet .
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Qinhuangdao Aohong Glass co.,ltd specializes in the manufacture and supply of various of glass products for about 15 years .
We arededicated to provide advanced glass solution for architectural, decorative and residential uses.
Export to more than100 countries including Korea,India,Mongolia and Russia.
Supply both raw glass with thickness from 2mm to 19mm in various colors and processed glass products and mirror according tocustomized options.
Supply mixed loading make it easy to purchase different requires from one supplier.
We are not only to provide high quality glass and mirror, but also to provide professional service for each customer.
No matter how big or small your requirement we will do our best to meet your demand.
Our sales group has extensive glass expertise provides the essential support and after sales service necessary to ensure all customer requirements promptly and efficiently.
WHY CHOOSE US ?
1. 15 years manufacture and export experience on glass and mirror.
2. Sell to 100 countries and areas.
3. Large stock and quick delivery.
4.100% quality checking before shipment.
5.Full insurance for shipment
6.Refund and replacement for production faulty.
2. Sell to 100 countries and areas.
3. Large stock and quick delivery.
4.100% quality checking before shipment.
5.Full insurance for shipment
6.Refund and replacement for production faulty.
7. 24 hours online service.
FAQ
1. What is your minimum order quantity?
We can do LFL depend on quantity you need .
Supply mix loading of different sizes and color in one container.
2. How can I get samples to check your quantity?
We offer samples for free.
3. Can you do the production as customized?
Yes, we have professional technique team and produce the glass depends on your requirements.
We can do LFL depend on quantity you need .
Supply mix loading of different sizes and color in one container.
2. How can I get samples to check your quantity?
We offer samples for free.
3. Can you do the production as customized?
Yes, we have professional technique team and produce the glass depends on your requirements.
