Высококачественный гибридный солнечный кондиционер с настенным креплением 12K

Сохранить в закладки 1600560876137:


Цена:570,00 $ - 670,00 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики


Product Description
Model Unit DGWA2-ACDCBLW-12K
Price     580.00-680.00USD
Climate Type Tropical</= 58℃   T3/T1
Application area             m2 12-20
Power Supply AC Power  Ph-V-Hz 1Ph 208V-240V/50-60HZ
DC Power (PV in Series) V 80-380V
DC Power Current A </=12A
Adviced Solar Panel Pcs (3-4)*330W in series
Rated Cooling Capacity(T1) W 3510(900-3900)
BTU 12000(3000-13300)
Power input(T1) W 940(190-1270)
Capacity(T3) W 2910
BTU 9900
Power input(T3) W 1050
Rated Heating Capacity W 4100(1000-4500)
BTU 14000(3000-15300)
Power input W 1170(190-1700)
T1  EER    (W/W)/ (BTU/W) / 3.75/12.75
T3  EER    (W/W)/ (BTU/W) / 2.75/9.45
COP         (W/W)/ (BTU/W) / 3.50/11.95
Dehumidification capacity          L/h 1.3
Compressor Model  / WHP04200
Type  / 2xRotary Inverter
Brand  / Highly
Indoor fan motor Model    BLDC-15W
Speed(Turbo/Hi/Mi/Lo) r/min 1300/1200/1100/950
Indoor air flow(Turbo/Hi/Mi/Lo) m3/h 540/485/435/350
Indoor noise level (Turbo) dB(A) ≤42.5
Indoor unit Dimension(W×H×D) mm 840×205×295
Packing   (W×H×D) mm 920×290×360
Net weight/Gross weight   Kg 9.0/12.5
Outdoor fan motor Model  / BLDC-40W
Speed         r/min 880
Outdoor air flow             m3/h 2100
Outdoor noise level         dB(A) ≤52
Outdoor unit Dimension(W×H×D) mm 802×564×323
Packing  (W×H×D) mm 910×622×405
Net/Gross weight   Kg 33.5/37.5
Refrigerant type / R410A
Max Design pressure          MPa 4.3/1.5
Refrigerant copper pipe Gas side/Liquid side (inch) inch  3/8  1/4
Max. refrigerant pipe length   m 15
Max. difference in level     m 8
Drain pipe size mm 16
Refrigerant connction copper pipe length m 3
Connection wire length m 4
Electronic Expansion Valve / Yes
Loading QTY 40" Hq/ 20"GP Sets 200/85
