Популярные промышленного оборудования Высокая мощность переработки AI решения Android материнская плата 1 ТБ

Сохранить в закладки 1600565363206:


Цена:598,00 $ - 605,00 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Hardware Specifications
CPU
Qualcomm QCS8250
4-core A73 2.2GHz/1.95GHz, 4-core A53 1.8GHz
RAM
On-board LPDDR4 8GB
Built-in Memory
128GB eMMC
Operating System
Android 10
Network Support
4G/5G/LTE
GNSS
GPS/BeiDou/GLONASS/Galileo
WIFI,BT
Default 2.4G 802.11 b/g/n/ac; 4.2 BLE and earlier
Video Codec
HEVC/H.264/VP8/VP9/MP4
Image Format
BMP/JPEG/PNG/GIF
Power Input
12V DC
RJ45
1 channel 10M/100M adaptive Ethernet
USB2.0
Default allocation:
6 USB 3.0 HOST interface
USB3.0
TBD
RS485/RS422
1 RS422/RS485 adaptive interface (default is 232 interface, RS422/RS485 interface can be selected through BOM)
RS232
4 RS232 interfaces (one of which can be configured as RS485/422 interface by BOM)
HDMI
1 HDMI, 1080p output by default
LVDS
1 dual-channel LVDS, the default output resolution is 1080p
1 single channel LVDS, maximum output resolution 1366*768
4K
TBD (Extensible Support)
I2C
2 I2C, configurable as touch screen interface
IO
Default 6 3.3V IO ports (internal 3.3V pull-up)
Screen backlight
2-channel brightness adjustable backlight interface
Headset
1 way 3.5mm headphone jack
Speaker
1 dual channel 8R/5W speaker driver interface
SIM Card
1.8V/3/3V, Push-Push Micro-SIM card socket
MicroSD Card
Push-Push Micro-SD card holder
Webcam
1 channel 1600M MIPI rear camera interface
Button
Switch button
Volume plus button
Volume down/reset button
Antenna
Main antenna IPEX interface
WIFI/BT IPEX interface
GNSS IPEX interface
Indicator Light
Red power indicator
Blue network status indicator
RTC Real Time Clock
stand by
System Upgrade
Local USB upgrade
