SPA-2800 Plasma Cleaning Machine/Plasma Cleaner/Atmosphere Plasma Treatment System

1.Product Profile

(1.1)Function of plasma cleaning

(A)The etching effect on the surface of the material -- physical action

A large number of active particles, such as a large number of ions, excited states and free radicals in the plasma, act on the surface of the solid sample. It can not only remove the original contaminants and impurities on the surface, but also produce etching, which makes the surface of the sample rough and forms a lot of micro potholes, which increases the specific surface of the sample. To improve the wettability of the solid surface.

(B)Activation bond energy, crosslink

The particle energy in the plasma is 0~20eV, and most of the bonds in the polymer can be in the 0~10eV. Therefore, the plasma can break the original chemical bonds on the solid surface after the plasma is acted on the solid surface. The free radicals in the plasma can form a network crosslink structure with these bonds, which greatly activates the surface activity.

(C)The formation of a new functional group -- chemical action

If a reactive gas is introduced into the discharge gas, a complex chemical reaction will occur on the surface of the activated material, and new functional groups, such as alkyl, amino, carboxyl, etc., are introduced. All these functional groups are active groups and can obviously improve the surface activity of the materials

(1.2)Advantages of plasma cleaning

Plasma cleaning, as an important material surface modification method, has been widely used in many fields.

Compared with traditional cleaning methods, such as ultrasonic cleaning and UV cleaning, it has the following advantages:

(A)Low temperature

The treatment temperature can be as low as 60 degrees Celsius. Low treatment temperature can ensure no heat effect on the surface of the sample.

(B)Non-pollution

Plasma cleaning machine itself is very environmentally friendly equipment, does not produce any pollution.

(C)Treatment effect is stable

The treatment effect of plasma cleaning is very uniform and stable. After conventional sample treatment, the effect is good for a long time.

(D)Samples of various shapes can be processed

For complex shape samples, plasma cleaning can find a suitable solution.

Plasma cleaning is more effective for cleaning the internal position of solid samples.

(1.2) Principles of Product

The structure of the plasma treatment system is mainly divided into three parts: high-voltage power supply, plasma generator sprayer and control system.

(A) High voltage power supply:

The generation of plasma requires high voltage excitation. Atmospheric low-temperature plasma is excited by medium frequency power supply with frequencies ranging from 10 to 40 KHz. High pressure is 4-10 KV. The parameters can be adjusted according to the actual situation of the sample, and the optimum modification effect has been achieved.

(B) The plasma generator gun:

The sprayer of atmospheric low temperature plasma generator can be divided into jet direct injection and rotary direct injection. The difference lies in the different treatment areas.

(C) Control system:

The function of the control system is to control the operation of the whole atmospheric low temperature plasma cleaning equipment and the protection of the whole system.

SPA-2800 Plasma Cleaning Machine/Plasma Cleaner/Atmosphere Plasma Treatment System

(2)Specifications
