Всесезонные наружные навесы для окон прозрачные твердые поликарбонатные тенты

Сохранить в закладки 1600572685097:


Цена:10,00 $ - 11,50 $*

Количество:

  • В избранное

Описание и отзывы

Характеристики















Product name:
Carport and canopy
Thickness:
1.5mm~20mm
Size:
customized
Surface:
UV-coating is regular.Anti-scrath and anti-fog are avaliable based on cutomer's requirement
Materials:
polycarbonate/Acrylic
Application:
 Sound insulation and noise reduction for highways and railways


Item
unit
Index Value
Test Method(ASTM)
Transmittance
%
88
D-792
Specific Gravity
g/cm3
1.2
D-792
Impact Strength(lzod,Nick)
J/M
907
D-256
Tensile Yield Strength
Mpa
69
D-638
Tensile Break Strength
Mpa
71
D-638
Tensile Elongation,yield
%
6.5
D-638
Tensile Elongation,break
%
120
D-638
Tensile Strength
Mpa
86
D-695
Tensile Modulus
Mpa
2400
D-638
Thermal Expansion Coefficient
W/m.℃
6.0*10-5
D-696
Thermal Conductivity
W/m.K
0.22
C-177
Heat Deformation Temperature
135
D-648
(Load 1.81Mpa)
135
D-648






























Q1: What is thermoforming and vacuum forming?
A:Thermoforming is the process of heating a sheet of plastic material, and using pressure to shape it using a mold. Vacuum forming refers to the use of vacuum to force the plastic into the shape of the mold

Q2:What are the benefits of thermoforming?

A:Thermoforming is efficient and very cost-effective for the production of many plastic parts depending on the part size, shape, and quantity. Up-front costs are usually much lower, and lead times to tooling and production are generally much shorter than other processes such as injection molding. Temporary tooling offers an inexpensive short-term test for design issues and product market acceptance.

Q3:What do you need from me to make a part?
A:We've started from a drawing on a UG, If you have a concept or Sample, then we can create a design, including CAD models, renderings, and detailed drawings. If, on the other hand, you already have a CAD (igs or stp)model or design, we can start from that and create molds and other tooling that will allow us to make the finished product. Our services include everything from design to prototypes to production, and we can do as much or as little as you need us to do.

Q4:What do you make molds from?
A:Production molds are typically cast or machined from aluminum. Deeper molds are usually cast, while shallower molds may be machined directly from a block of aluminum. Aluminum molds can be temperature controlled, which allows tight tolerances, better detail, and shorter cycle times (which translates into a lower cost part).

Q5: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity ordered.

Q6: Can you accept OEM/ODM service?
A: Yes,OEM/ODM is available, please send email to us for more detail.
