Новое поступление QSMOTOR 14x6 0 дюймов 3000 Вт 4000 макс. 13500 72 в 110KPH QS138 комплект двигателя среднего привода для электроскутера

Новое поступление QSMOTOR 14x6 0 дюймов 3000 Вт 4000 макс. 13500 72 в 110KPH QS138 комплект двигателя среднего привода для электроскутера

Категория: Motorcycle Motor >>>
Поставщик: Taizhou Sia Science And Technology Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

SIA New Arrival QSMOTOR 14 x 6.0inch 3000W 4000W Max 13500W 72V 110KPH QS138 Mid Drive Motor Kit for PCX Electric Scooter

Please noted that tire is not included as default.

For 138 3000W 4000W mid drive motor kit assembly, it could be used for electric scooter, electric motorbike, which could be 72V 110KPH, avaiable for 12inch wheel kits as default (14inch wheel assemble kits will comes out soon).

e.g. PCX big electric scooter

E-scooter weight, approx 130kg+2*80kg

Speed: max 110km/h

Gear ratio: 1:4.77 (double steps transmission )

Climbing slope: 30°@190kg

Battery: 72V50h NCM lithium battery

Tire: 180/50-14

One set including below kits

Combo 1

·1pc QS 14*6.0inch 3000W Mid Drive Motor assembly with Left/Right fork(Tire are not included)

·1pcs X Votol EM72150SP sine wave motor controller with standard CAN-BUS

·1pcs X DKD LCD speedometer

·1pcs X Z6 throttle with combination switch

Combo 2

·1pc QS 14*6.0inch 4000W Mid Drive Motor assembly with Left/Right fork(Tire are not included)

·1pcs X Votol EM72150SP sine wave motor controller with standard CAN-BUS

·1pcs X DKD LCD speedometer

·1pcs X Z6 throttle with combination switch

Combo 3

·1pc QS 14*6.0inch 4000W Mid Drive Motor assembly with Left/Right fork(Tire are not included)

·1pcs X Votol EM72200SP sine wave motor controller with standard CAN-BUS

·1pcs X DKD LCD speedometer

·1pcs X Z6 throttle with combination switch

Combo 4

·1pc QS 14*6.0inch 3000W Mid Drive Motor assembly with Left/Right fork(Tire are not included)

·1pcs X Votol EM72150SP sine wave motor controller with standard CAN-BUS

·1pcs X DKD LCD speedometer

·1pcs X Z6 throttle with combination switch

·1pcs X Vehicle Wiring suitable for EM50sp-EM150sp controller

Combo 5

·1pc QS 14*6.0inch 4000W Mid Drive Motor assembly with Left/Right fork(Tire are not included)

·1pcs X Votol EM72150SP sine wave motor controller with standard CAN-BUS

·1pcs X DKD LCD speedometer

·1pcs X Z6 throttle with combination switch

·1pcs X Vehicle Wiring suitable for EM50sp-EM150sp controller

PS. It's new powertrain, the delivery time is a bit longer.

Product description

Genearlly Spec:

QS 138 3kW mid drive motor

138 3KW V1 V2 spec.jpg

QS 138 4kW mid drive motor

138 4KW V1 V2spec.jpg

Dimension Drawing:

QS 138 3kW mid drive motor

QS 138 4kW mid drive motor

14x6.0inch 3kw assembly drawing

14x6.0inch 4kw assembly drawing

Test report

QS138 3kw Assembly

QS138 4kw single motor dyno test with EM150SP controller

2.EM72150SP Controller Description:

Specification

·Sine wave controller, programmable, with regen function

·Rated Current:180A

·BOOST Current: 220A

·Peak Current: 470A

·Max.Power: 12960W

·Flux Weakening Ratio:100~250%

·Max.Efficiency:88~93%

·Net weight: 1650g

·Waterproof IP67

3. DKD LCD speedometer, can-bus(optional, LIN as default)

4. Z6 throttle with combination switch

4. Vehicle Wiring suitable for EM50sp-EM150sp controller

Wiring Diagram

Application for QS 138 3kW mid drive motor
