Model | KCDD-1.2 | KCDD-1.5 | ||
Dehumidify Capacity(20°C,60%) | 0.6kg/hr | 1,2 kg/h | 1.5kg/h | |
Power supply | 220-240V/60HZ | 220-240V/60HZ | 220-240V/60HZ | |
Process air flow | 220m3/hr | 280m3/hr | 320m3/hr | |
Inlet size mm | 100 | 100 | 100 | |
Reactivation air flow | 60m3/hr | 95m3/hr | 110m3/hr | |
Outlet size mm | 80 | 80 | 80 | |
Applied Temperature | -20°C~60°C | -20°C~60°C | -20°C~60°C | |
Regeneration energy consumption | Steam KG/H | / | / | / |
0.4Mpa | / | / | / | |
ELec. | ELec. | ELec. | ELec. | |
Max power | Steam | / | / | / |
ELec. KW | 1.5KW | 1.6KW | 1.8KW | |
Power rating | 1.2KW | 1.4KW | 1.5KW | |
Current | 5.2A | 7.2A | 8.1A | |
Application Area | 10-20m2 | 20-30m2 | 20-40m2 | |
Dimension | 465*305*665mm | 465*305*665mm | 465*305*665mm | |
Packing size | 500*345*710mm | 500*345*710mm | 500*345*710mm | |
Net weight | 40kg | 42kg | 44kg | |
Gross weight | 45kg | 47kg | 49kg | |
Primary Filter | G4 efficiency | |||
Desiccant Rotor Brand | Sweden Proflute |
As per the below picture showing working principle:
desiccant dehumidifier Applications
Due to the solidity desiccant wheel, this equipment can be used to dry the air under atmospheric pressure. It can continue working right down to -20°C, up to 50°C.
The dehumidification equipment is suitable for:
• Places full of corrosive gas
• HVAC system
• Humidity of less than 35%RH
• Low dew point conditions
• Low temperatures, especially combined with low humidity
• Single pass air flow applications
• Pharmaceutical production, packaging, storage, testing and research
• Process air systems
• Photographic/film archive stores
• Pneumatic conveying of powders
• Pumping stations
• Confectionary production and packing
• Food production
• Clean rooms
• Electronic manufacture
• Cold stores
• Seed storage
• Drying & corrosion prevention inside power station turbines
• Injection moulding machines
• Tank drying ...
