Электрическая отрезная пила для металла 3000 Вт 355 мм электрическая
- Категория: >>>
- Поставщик: Kunshan DS Precision Machinery Co. Ltd.
Сохранить в закладки 1600613506981:
Описание и отзывы
Характеристики
Product Description
Product Name:
Hot Sale 300w Compound Miter Saw 355mm Metal Electric Cutting Saw Professional Cut Off Saw Machine
Power supply: AC
Operation:
desktop hand pressure
Cutting Angle:
support 45 degree cutting
Motor:
constant speed brushed motor
Dust-free cutting:
low spark/no dust
Application: round bar, square pipe, rectangular pipe cutting
Main Features
1. Cut the solid steel metal, the speed is generally set at 900-1100/rpm.
2. Cut pipe wall thin metal, the speed is generally set at 1300-1500/rpm.
3. Cut aluminum profiles,copper,wire and cable, the speed is generally set at 1500/rpm.
4. The machines are available in two regular models: 10" (255) and 14" (355).
5. Wire rolling machine, wire sleeve mounting machine models: 10" without base and 14" without base.
6. 10" power 3.0KW, cutting diameter up to 70mm, 14" power 3.0KW, cutting diameter up to 130mm.
7. It can cut 45 degree angles and the motor is constant speed brushed to better ensure the efficiency, environmental protection and longevity of service life.
8. The locking handle must be tightened when cutting; loose workpieces are prone to chipping of the cold cut saw blade.
9. Start the machine and wait until the speed is normal (it takes 1-2 seconds) before cutting.
Specification
Model | DS-355C |
Rated voltage frequency | single phase A.C.: 220V~50Hz |
Output power | 3kw |
Saw blade diameter | 355mm（14 inch） |
Hole core diameter | 25.4mm |
Cutting angle | 0°- 45° |
Torque | 27.1（1300rpm counted） |
Number of rotations | 1300r/min |
Net weight | 20Kg |
Motor model | Brushed Constant speed motors |
Saw blade diameter | 355mm（14 inch） |
Connection hole diameter | 25.4mm |
Saw blade body thickness | 1.8-2.5mm |
Round bar | Max. cutting diameter 130mm (Cutting depth: height * width) |
Square pipe | Max. cutting diameter 125*125mm (Cutting depth: height * width) |
Rectangular pipe | Max. cutting diameter 110*160mm (Cutting depth: height * width) |
Round bar | Max. cutting diameter 120mm (45° cutting: height * width） |
Square pipe | Max. cutting diameter 100*100mm (45° cutting: height * width） |
Rectangular pipe | Max. cutting diameter 100*140mm (45° cutting: height * width） |
Machine size | 52*30*39cm |
Machine unfolds | 52*30*60cm |
Package box size | 57*33*40cm |
Details Images
Why Choose Us
1. After nearly two decades of hard work and precipitation, DS Machinery has obtained more than 30 inventions, utility models and appearance patents and a number of software copyrights.
2. During the period, it obtained ISO9001: 2015 quality system certification, and at the same time obtained the honors of high-tech enterprises, private technology enterprises in Jiangsu Province, and Suzhou City for abiding by contracts and keeping promises, issued by the government.
3. DS owns 3,500 square meters of workshops, and has established two R&D centers in Huzhou, Zhejiang and Kunshan, Jiangsu, and three service bases in Jiangsu, Zhejiang, and Guangdong.
4. the products are exported to Southeast Asia, the Middle East, Europe, Africa and other places, and more than 3,800 customers have been served worldwide.
2. During the period, it obtained ISO9001: 2015 quality system certification, and at the same time obtained the honors of high-tech enterprises, private technology enterprises in Jiangsu Province, and Suzhou City for abiding by contracts and keeping promises, issued by the government.
3. DS owns 3,500 square meters of workshops, and has established two R&D centers in Huzhou, Zhejiang and Kunshan, Jiangsu, and three service bases in Jiangsu, Zhejiang, and Guangdong.
4. the products are exported to Southeast Asia, the Middle East, Europe, Africa and other places, and more than 3,800 customers have been served worldwide.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q: Are you manufacturer or trading company?
Q: Do you have overseas service? How to provide after-sales service？
A: We are a professional manufacturer dedicated to the research and producing of high quality aluminum cutting machines and saw blades for 20 years.
Q: Can I have your quotation?
A: First, please offer us the information of your cutting material and its size,without these parameter, we are not able to recommend you the suitable machine.
Q: Do you have overseas service? How to provide after-sales service？
A: Yes, we normally help our customers to solve the problems through phone, Email, skype, internet video. Very high efficiency.
Q: How long is the equipment warranty？
A: We offer one year guaranteen for main parts, within one year, if component of the machine broken, we freely offer the component, but the delivery fee should be paide by client.
Q: What is the voltage and Hertz in your country?
A: In China,the Voltage is 380V(3 Phase), the Hertz is 50Hz, we can change the voltage and Hertz according to your requirment.
Q: What is the delivery lead-time?
A: Aluminum cutting machine: normally 5-30 days upon receipt of your orders and its deposit. Saw blade: 5-30 days(depending on availability of saw blade stock or material stock) upon receipt of your order and deposit.
Q: What is your payment terms?
A: We accept L/C, T/T, D/P, Western Union and PayPal. As T/T, 30% deposit, 70% of balancepaid before shipment.
Q: Can you customize for us?
A: Yes.
Q: Can you OEM/ODM for us?
A: Yes
Q:Can I get a discount?
A:Yes, for the yearly order quantity of more than 5 sets, please contact us to get the best price.
Q:Do you inspect the finished products?
A:Yes, each step of production and finished products will be coming out inspection by the QC department before shipping.
Q: Do you provide equipment operation training? Do you have the operation instruction book in English?
A: Currently we can do on-line technical operation training for customer's staff. Yes, we have English version operation instruction book for each cutting machine.
Contact:
Email: export1@fjr88.com
Phone: +86-17312676618
Hotline: 400-6462-898
If you have any other questions, you can also contact this below email:
dantondeng@126.com for communication, thank you!
