Product Description


mini plastic one way duckbill check valve KH-CBDE1

When the duckbill valve is under no pressure inside, the duckbill outlet is closed under its own elastic force, and as the internal pressure gradually increases, the duckbill outlet gradually increases, keeping the liquid discharged at a high flow rate.







Duckbill Check Valve




   Cracking Pressure(<0.5KPa)







①Outlet                 ②Duckbill valve core                 ③Inlet




.................................................................... 1/16'' ....................................................................





Model No.
Size of Port
OD of Port
ID of Port
Material of Body
Material of Seal
KH-CBDE1
1/16"
2.2mm
1.6mm
PVDF
EPDM



.................................................................... 1/8'' ....................................................................





Model No.
Size of Port
OD of Port
ID of Port
Material of Body
Material of Seal
KH-CBPF2
1/8"
3.2mm
1.4mm
PP
FVMQ



.................................................................... 5/32'' ....................................................................





Model No.
Size of Port
OD of Port
ID of Port
Material of Body
Material of Seal
KH-CBPS532
5/32"
4.1mm
2.0mm
PP
Silicon
KH-CBDS532
5/32"
4.1mm
2.0mm
PVDF
Silicon
KH-CBPF532
5/32"
4.1mm
2.0mm
PP
FVMQ



.................................................................... 3/16'' ....................................................................





Model No.
Size of Port
OD of Port
ID of port
Material of Body
Material of Seal
KH-CBPF3
3/16"
4.7mm
3.2mm
PP
FVMQ
KH-CBDF3
3/16"
4.7mm
3.2mm
PVDF
FVMQ




Model No.
Size of Port
OD of Port
Material of Body
Material of Seal
KH-CBPST3
3/16" (4.8mm)
4.8mm
PP
Silicon


\t\t\t\t\t\t\t\t\tOther Check Valves \t\t\t\t\t\t\t


We have Six port sizes to choose: 1/16'', 1/8", 3/16", 1/4", 5/16" and 3/8".
Four housing materials: PVDF / PP / ABS / PA66
Three diaphragm materials: Silicone / V it on / EPDM











Different material check valve can been used in different application
If you need ozone resistant, we recommend PVDF material check valve
If you need high temperature resistant, we recommend PVDF material and PA66 material check valve
If you need low temperature resistant, we recommend ABS material
If you need corrosion resistant, we recommend PVDF and PP material
If you need oil, diesel fuel, gasoline resistant, we recommend PA66 material

If you are not sure which kind check valve to choose, pls check some points and we will give you our advices:
1. What's the size of the check valve port that you need? Or the inner diameter of the hose that the check valve connected to.
2. Where does the check valve you use in?
3. What medium can the check valve come into contact with? Such as Air, Ozone, Water, Oil ( Gasoline, Lubricant Or Edible Oil )
4. What is the using temperature about your check valve?
5. What is the Cracking pressure of the valve you require?
