Products Description
★★20KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ20GF | Steady state voltage regulation(%):≤±1 | |
Output power:20KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：36A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：1620*850*1580（L×W×H mm） | Oil consumption（100％ loading）：≤204g/kW·h | |
NET WEIGHT：610kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：4B3.9-G | Supply oil type：direct injection | |
Rated power：24kw | Standby power：28kw | |
Cylinder number：4/L type | Governor type：Mechancial | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：16.5:1 | Loading capacity：110％ | |
Starting mode：DC24V electric | RPM：1500rpm | |
Diesel engine size: 765mm × 582mm × 908mm | Net weight: 320KG | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
Lubricant capacity: 11L | Coolant capacity：5L | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN20（XN184H) | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：20KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★30KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ30GF | Steady state voltage regulation(%):≤±1 | |
Output power:30KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：54A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：1620*610*1380（L×W×H mm） | Oil consumption（100％ loading）：≤204g/kW·h | |
NET WEIGHT：610kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：4BT3.9-G1 | Supply oil type：direct injection | |
Rated power：36kw | Standby power：40kw | |
Cylinder number：4/L type | Governor type：Mechancial | |
Diesel engine displacement: | 3.9 Liters | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：16.5:1 | Loading capacity：110％ | |
Starting mode：DC24V electric | RPM：1500rpm | |
Lubricant capacity: | 11 Liters | |
Coolant Capacity: | 8 Liters（Engine Only) | |
Wet weight: | 320KG | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN30（XN184H) | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：30KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★40KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ40GF | Steady state voltage regulation(%):≤±1 | |
Output power:40KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：72A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：1760*710*1400（L×W×H mm） | Oil consumption（100％ loading）：≤204g/kW·h | |
NET WEIGHT：850kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：4BTA3.9-G2 | Supply oil type：direct injection | |
Rated power：50kw | Standby power：50kw | |
Displacement： | 3.9 Liters | |
Cylinder number：4/L type | Governor type：Electronic Speed Regulation | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：16.5:1 | Loading capacity：110％ | |
Starting mode：DC24V electric | RPM：1500rpm | |
Wet weight: | 340KG | |
Lubricant capacity: | 11 Liters | |
Coolant Capacity: | 8 Liters（Engine Only) | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN40 | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：40KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★50KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ50GF | Steady state voltage regulation(%):≤±1 | |
Output power:50KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：90A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：1850*850*1700（L×W×H mm） | Oil consumption（100％ loading）：≤204g/kW·h | |
NET WEIGHT：850kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：4BTA3.9-G2 | Supply oil type：direct injection | |
Rated power：50kw | Standby power：50kw | |
Displacement： | 3.9 Liters | |
Cylinder number：4/L type | Governor type：Electronic Speed Regulation | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：16.5:1 | Loading capacity：110％ | |
Starting mode：DC24V electric | RPM：1500rpm | |
Wet weight: | 340KG | |
Lubricant capacity: | 11 Liters | |
Coolant Capacity: | 8 Liters（Engine Only) | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN50 | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：50KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★75KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ75GF | Steady state voltage regulation(%):≤±1 | |
Output power:75KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：135A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：2150*830*1480（L×W×H mm） | Oil consumption（100％ loading）：≤204g/kW·h | |
NET WEIGHT：950kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：6BT5.9-G1 | Supply oil type：direct injection | |
Rated power：86kw | Standby power：92kw | |
Displacement： | 5.9 Liters | |
Cylinder number：6/L type | Governor type：Mechancial | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：17.5:1 | Loading capacity：110％ | |
Wet weight: | 425KG | |
Lubricant capacity: | 16 Liters | |
Coolant Capacity: | 11 Liters（Engine Only) | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
Starting mode：DC24V electric | RPM：1500rpm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN75(XN274CS) | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：75KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★100KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ100GF | Steady state voltage regulation(%):≤±1 | |
Output power:100KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：180A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：2250*920*1600（L×W×H mm） | Oil consumption（100％ loading）：≤205g/kW·h | |
NET WEIGHT：1250kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：6BTA5.9-G2 | Supply oil type：direct injection | |
Rated power：106kw | Standby power：112kw | |
Cylinder number：6/L type | Governor type：Electronic Speed Regulation | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：17.5:1 | Loading capacity：110％ | |
Wet weight: | 450KG | |
Lubricant capacity: | 16 Liters | |
Coolant Capacity: | 14 Liters（Engine Only) | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
Starting mode：DC24V electric | RPM：1500rpm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN100 | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：100KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
★★120KW CUMMINS diesel gensets specification★★ | ||
★Diesel gensets parameter: | ||
Model number:KWHQ120GF | Steady state voltage regulation(%):≤±1 | |
Output power:120KW | Voltage fluctuation rate(%):≤±0.5 | |
Pwer factor：COSΦ=0.8（lagger） | Transient voltage regulation（％）：＋20～－15 | |
Output voltage：400V/230V | Voltage settling time（s）：≤1 | |
Output currency：216A | Steady state frequency regulation（％）：≤±1 | |
Rated frequency：50Hz | Frequency fluctuation rate（％）：≤±0.5 | |
Rated RPM：1500rpm | Transient frequency adjustment rate（％）：＋10～－7 | |
Fuel brand：(Standard) 0# light diesel oil (at room temperature) | Frequency stabilization time（S）：≤3 | |
Overall size：2250*920*1600（L×W×H mm） | Oil consumption（100％ loading）：≤205g/kW·h | |
NET WEIGHT：1350kg | Noise（LP7m）：95dB（A） | |
★Diesel engine parameter: | ||
Brand：DCEC CUMMINS | Cooling mode：full-closed water-cooling | |
Model number：6BTAA5.9-G2 | Supply oil type：direct injection | |
Rated power：120kw | Standby power：130kw | |
Displacement：5.9 Liters | ||
Fuel Injection Pump: | PN Injection Pump | |
Governor: | Electrical Governor RSV Mechanical Governor | |
Cylinder number：6/L type | Governor type：Electronic Speed Regulation | |
Bore & Stroke：102*120 mm | Intake：Turbo Charge | |
Compression：17.5:1 | Loading capacity：110％ | |
Wet weight: | 425KG | |
Lubricant capacity: | 16 Liters | |
Coolant Capacity: | 11 Liters（Engine Only) | |
Coolant Intake Size: | Φ58mm | |
Coolant Outlet Size: | Φ45mm | |
Starting mode：DC24V electric | RPM：1500rpm | |
★Alternator parameter: | ||
Brand：Kangwo | Indication of protection：IP23 | |
Model number：HQF-XN120 | Connecting type: Three phase and 4 wires,“Y”type | |
Rated power：120KW | Regulating type：AVR（Automatic voltage regulator） | |
Rated voltage：400V/230V | Output frequency：50Hz | |
Insulation class：H grade | Power factor：COSΦ=0.8（lagger） | |
Company Profile
Shandong Kangwo Holding Co., Ltd
Shandong Kangwo Holding Co., Ltd was established in 2019 with a registered capital of 390 million yuan. It is a national high-tech enterprise specializing in the Research & Development, manufacturing, sales and service of “diesel engine/gensets, natural gas engine/gensets, methanol engine/gensets, water pump diesel gensets and lighting tower” which have been export to many countries.
The headquartered located in Heze Shandong China covering its about 73000 square meters in local plant, the main products cover 9 series with more than 200 categories in which used in "Power generation equipment, Industrial water pumps, Agricultural machinery, Marine and Ship, Engineering machinery, Vehicle & Special machinery”,etc.
The headquartered located in Heze Shandong China covering its about 73000 square meters in local plant, the main products cover 9 series with more than 200 categories in which used in "Power generation equipment, Industrial water pumps, Agricultural machinery, Marine and Ship, Engineering machinery, Vehicle & Special machinery”,etc.
Certifications
Production Line
Sample Room
Exhibition
Product Packaging
1) Wrap the generator set by stretch film, and put some drying agent.
2) Adopt steel plate or wood rib to make it stronger, can afford rough handling.
3) Design for forklift truck working in 4 directions. Fastened by 8cm length galvanized nail.
4) Load the case into container by forklift truck.
2) Adopt steel plate or wood rib to make it stronger, can afford rough handling.
3) Design for forklift truck working in 4 directions. Fastened by 8cm length galvanized nail.
4) Load the case into container by forklift truck.
FAQ
1.What is your main products and applications?
Our main products are 4-cylinder/6-cylinder/12-cylinder diesel engine and diesel gensets.
Our engine is usually used on "Power generation equipment, Industrial water pumps, Agricultural machinery, Marine and Ship, Engineering machinery, Vehicle & Special machinery”,etc.
Our engine is usually used on "Power generation equipment, Industrial water pumps, Agricultural machinery, Marine and Ship, Engineering machinery, Vehicle & Special machinery”,etc.
2.How soon will I get my engine after payment?
Our warehouse has sufficient regular sizes stocking, ready to deliery, and we have lots of raw materials storage, customer specifications can be arranged in a timely manner production, So the lead time within 7-10days for orders under 100units/order, delivery time will be 20-60days depends on the arrival ports.
3.When Can I get the price?
We will reply you within 24 hours after we get your inquiry, Or you could directly call us if you are urgent.
4.How to do the trouble shooting of our products?
We have a professional technical team, will be online to solve the use of the process encounterd various problems, if can not be resolved online, technical staff will arrange timely home visits.
5.Do you have any othe services?
You can provide us with your needs, we will do our best to meet your needs.
Похожие товары
КВт, кВт, кВт, комплект запасных частей для дизельного двигателя, Эфиопия, доступен корпусный генератор
Бесшумные магнитные дизельные генераторы 6 кВт кВА
580,00 $ - 620,00 $
Звукоизоляционный Тип 2200 кВт дизельный электрический генератор 2750KVA с MTU
420 800,00 $ - 422 800,00 $
AOSIF поставка AC30 генератор мощности двигателя с сертификацией CE 22 кВт 28 кВА дизельные генераторы 24 30 в режиме
5 489,00 $
Бесшумный портативный инвертор Excalibur бензиновые генераторы с электрическим стартером новый дизайн 5
560,00 $ - 620,00 $
США двигатель генератора 80kw 100kva 100% Медь Автоматический молчание дизель-генератор, Прямая продажа со склада в Южной Африке
9 300,00 $ - 9 500,00 $
10 кВт 12 15 20 25 30 40 50 головка генератора с
99,00 $ - 199,00 $
Новые поступления
Новинки товаров от производителей по оптовым ценам
Светлая Золотая морская солнечная энергия ландшафтное украшение постмодерн минималистский стиль чистая ручная роспись маслом 24x3 1 дюйм/60x80
35-53 $
Европейские антикварные простой Последние двойной металлической кровати
Автоматизированная складская система автоматического хранения в Гуанчжоу Eyda с эффективными стеллажами и
10 000-35 000 $
Декоративный чехол для PS5 Сменный Чехол консоли пластины Playstation5 пылезащитный с защитой от царапин
7,50-7,70 $
Лучшее качество детские подгузники для сухих подгузников новорожденных размер 2 4 и большие доставка или
3 $
Выключатель для формованного корпуса Schneider NSX100N 50KA AC 3P3D 25A TMD новая модель C10N3TM025
Буф2-.. М .. Краны
Оптовая продажа высококачественный сублимированный клубничный порошок Заводская поставка
5,50-6,40 $
