WH138 1AK 1 15V поворотный потенциометр с переключателем для управления скоростью вращения вентилятора диммер 1000 Вт Пакистан
- Категория: >>>
- Поставщик: Changzhou Kennon Electronics Co. Ltd.
Сохранить в закладки 1600663371423:
Описание и отзывы
Характеристики
Product Description
Drawing
Specification
项目 ITEM | 规格 SPECIFICATION | ||
电气性能 Electrical Characteristics | 工作温度 Temp Range | -10℃～70℃ | |
额定功率 Rated Power | Curve B:0.5W Other curve B:0.25W | ||
最大工作电压 Max Operation Voltage | Curve B:AC 500V Other than B:AC 250V | ||
阻值范围 Resistance Range | 1KΩ～2MΩ | ||
阻值允许偏差 Allow Desistance Tolerance | ±20%(1MΩ or more30%) | ||
转动噪声 Rotational Noise | ≤47mV | ||
终端电阻 Terminal Resistance | R≥250KΩ 0.1%R max 250KΩ>R>10KΩ 20Ωmax 10 KΩ≥R 10Ωmax | ||
电阻规律 Resistance Law | A、B、C | ||
抗电强度 Dielectric | AC500V,1minute | ||
开关接触电阻 Switch contact resistance | Less than 30mΩ | ||
开关额定功率 Rated switching power | AC125V 1A、4A、6A | ||
绝缘电阻 Insulation Resistance | More than 100MΩ at DC250V | ||
机械性能 Mechanical Characteristics | 旋转力矩 Rotational Torque | 2～20 mN.m（20～200gf.cm） | |
总旋转角度 Total Rotational Angle | 300°±5° | ||
止挡强度 Shaft Stopper Strength | 6Kgf.cm | ||
开关操作力Switch working force/torque | 150～450gf.cm | ||
开关动作角度Switch working angle | 50°±10° | ||
开关寿命Switch life | 10,000 times | ||
旋转寿命 Rotary life | 10,000 cycles | ||
焊接Soldering | T≤260ºC，t≤3s | ||
Company Profile
Changzhou Kennon ELectronics Co.,Ltd. is a leading manufacturer and exporter of all kinds of potentiometers, rotary switches ,encoder ,air pressure switch ,capacitor ,resistor ,power strip ,relay,diode, transistor and other many kinds of electronic components.With the ISO9001, ISO14001, VDE, NEMKO, CB, CQC certification and long-term experience of manufacturing,Reach RoHS compliant.
Since its foundation in 1991, the company has been developing itself to establishing its brand as a high quality one. The company has its R&D, tooling, injection, punching and assembling department, pipelining workshop etc . And now the company has formed into series of professional, systemic manufacturer which with ability of 5000000 PCS per month output. The products are used widely in
telephone, display, auto acoustics, meeting loud-speaker, recorder, home cinema(DVD ,VCD), toys, mix-sound machine, home electronic products and modern intellective system etc.
All staff members believe that improvement should be made all the time, quality first customer pleased, continuously improvement strive better, we wish to have a close cooperation with personalities from various fields and develop together further, walkingwith firm steps on the way.
Since its foundation in 1991, the company has been developing itself to establishing its brand as a high quality one. The company has its R&D, tooling, injection, punching and assembling department, pipelining workshop etc . And now the company has formed into series of professional, systemic manufacturer which with ability of 5000000 PCS per month output. The products are used widely in
telephone, display, auto acoustics, meeting loud-speaker, recorder, home cinema(DVD ,VCD), toys, mix-sound machine, home electronic products and modern intellective system etc.
All staff members believe that improvement should be made all the time, quality first customer pleased, continuously improvement strive better, we wish to have a close cooperation with personalities from various fields and develop together further, walkingwith firm steps on the way.
Packing & Delivery
Certification
We company has ISO9001 and ISO14001 approval and product with UL CB VDE CQC SGS REACH APPROVAL
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Sample:
1.free charge of sample, we can supply free sample less than 5pcs and freight collected
2. we may need 2-7days to prepre the sample
3.we can send sample by DHL, FEDEX,UPS, T NT, Shunfeng, EMS and so on
Payment term
1.pay from alibaba by credit card
2.T/T to our bank account
3. Western Union
4. Paypal
Delivery time
,10000pcs of cargo can be deliveried in 7days
2. 10000pcs-50000pcs may need 15days,it depends on different product
3. After we get your order, we will confirm with you the lead time on line or by emailshipping
1We package the cargo according to customer order quantity
2. most of cargo will be send from shanghai port by sea or by air.
3, if you use express DHL, UPS, TNT, EMS,can ship directly from our factory
4.we can support EXW, FOB, CFR, CIF trade term
After service
1.email will be replied in 24hours
2. we can support SKY PE, TRADE MANAGER, WECHAT, WHATSAPP,QQ ON LINE 8: 00-20: 00
3. You can also call me on 0086013775187075 from 8:00AM-23: 00 PM4: skype: fanyu1523
1.free charge of sample, we can supply free sample less than 5pcs and freight collected
2. we may need 2-7days to prepre the sample
3.we can send sample by DHL, FEDEX,UPS, T NT, Shunfeng, EMS and so on
Payment term
1.pay from alibaba by credit card
2.T/T to our bank account
3. Western Union
4. Paypal
Delivery time
,10000pcs of cargo can be deliveried in 7days
2. 10000pcs-50000pcs may need 15days,it depends on different product
3. After we get your order, we will confirm with you the lead time on line or by emailshipping
1We package the cargo according to customer order quantity
2. most of cargo will be send from shanghai port by sea or by air.
3, if you use express DHL, UPS, TNT, EMS,can ship directly from our factory
4.we can support EXW, FOB, CFR, CIF trade term
After service
1.email will be replied in 24hours
2. we can support SKY PE, TRADE MANAGER, WECHAT, WHATSAPP,QQ ON LINE 8: 00-20: 00
3. You can also call me on 0086013775187075 from 8:00AM-23: 00 PM4: skype: fanyu1523
wechat: leozouoo7 whatsapp: +86 137 75187075
Contact us
Changzhou Kennon Electronics Co.,Ltd.
Address:No.118,Xihu Road,Wujin,High-New Technology District,Jiangsu,P.R.China
Website: www.czkennon.com www.china-spike.com
E-mail: leo@czkennon.com
Skype: fanyu1523 Mobile:0086-013775187075 Wechat: Leozou007
WHATSAPP: +86 13775187075
Tel:0086-519-86461533,86471236
Fax:0086-519-86462341
Post Code: 213167
Address:No.118,Xihu Road,Wujin,High-New Technology District,Jiangsu,P.R.China
Website: www.czkennon.com www.china-spike.com
E-mail: leo@czkennon.com
Skype: fanyu1523 Mobile:0086-013775187075 Wechat: Leozou007
WHATSAPP: +86 13775187075
Tel:0086-519-86461533,86471236
Fax:0086-519-86462341
Post Code: 213167
