Печь с газовым порошковым покрытием 20

Категория: Metal Coating Machinery >>>
Поставщик: Hangzhou Color Powder Coating Equipment Co. Ltd.

Цена:7 000,00 $ - 8 500,00 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

20ft gas powder coating oven

This powder coat oven heating by gas, meet the most demands of batch curing of products after sprayed. Inside high performance heating elements enables the oven to a quick raising of required temperature, and a circulation fan provides uniform heat distribution, ensures a high quality surface finish on parts.

Detailed Images

COLO Gas Powder Coating Oven Features

1. It is easy to operate thanks to the PLC control unit with precise temperature regulation and timer.
2. Italy imported Riello burner fully burns fuels, quickly reaching to required temperature.
3. Circulation fans causes uniform temperature in the entire chamber that results in quality cured finishes.
4. 100 mm thickness rockwool board always keeps the chamber warm with minimum heat loss.
5. We can custom powder coating ovens with different sizes, heated by electric, gas or diesel.

Easy and simple control panel

PLC Control provides high precision heating process, with overheat self-protection device, and temperature detector, it offers all the features you need.

The panel allows you to set the accurate temperature and duration you require, as well as control the working of fan.

Riello burner

Natural gas or LPG available

Italy imported Riello burner takes full utilization of fuels, gives much quicker raise to a required temperature comparing with electric heating, as well as more environmental-friendly than diesel fired oven.

100mm thick insullation board

The powder coating oven insulation material is 100mm thickness rock wool board, which always maintain the warmness in the oven chamber.

The inner wall is 1mm galvanized steel which is heat-resistant, while the outerwall is durable color steel sheet.

Parts Transporting System

COLO powder coating ovens are available with inner and outer trolleys.

It is easy for loading and transporting workparts. The trolley holding parts always stays clean that will not pollute the oven chamber, keeping the purity of cured parts.

Manufacturing Technique

Model	COLO-6220
Inner Size	W2000 x D6000 x H2000mm
Material	rock wool board, t=100mm
Fan motor	1 set, 7.5kw，415v 3p 50hz
Voltage/Frequency	As required
Burner	Italy Riello, 200,000kcal
Warm-up Time	15-30 min. (180° C)
Temperature Stability	< ± 3-5°C
Temperature	Max.250° C
Ventilation Performance	1131-2565m3/h
Transport	2pcs Trolley

Application

COLO-3210 gas powder coating oven is often used to coating batch certain metals in a variety of industries, and increasingly for coating aluminum extrusion used in building products, home appliance industry, furniture industry, refrigeration industry, medical industry.

Related Products

Packing&Shipping

Standard exportation packages

1. Inside sofy poly Bubble wrapped well
2. Five-layer corrugated box for air delivery
3. Strong wooden box for sea shipping

Company Introduction

Colo is the leading powder coating equipment manufacturer in China, which provides high quality equipments all oven the world with advanced manufacturing machines and professional technicians.

Colo offers a wide range of powercoating equipments, namely powder coating machine, powder coating gun, spray booth, curing oven, automatic powder coating applicator, powder coating line.

Welcome guests from all countries in the world to visit our factory.

FAQ

Powder Coating Oven FAQ

1. Q: Are you trading company or factory?
A: we are factory since 2009, we have own workshop, warehouse, and professional technique team, we can provide customized and OEM service. Welcome to visit our factory.

2. Q: What certificates you can supply?
A: CE, LVD, ISO, ATEX certificate available. If you need other certificates, we will help with it, for example: FORM A, FORM E and COC.

3. Q : What is the warranty of the powder coating oven?
A: One year warranty period.

4. Q: If the size of powder coating oven can be customized?
A: Yes, not only we have standard sizes of powder coating oven, but also we can design the custom-model according to your requirement.

5. Q: What is the package and delivery ?
A: We use pearl cotton or wooden case to pack the oven and shipped with sea container, or pick up by yourself.

6. Q: How about the delivery time?
A: Standard ovens cost about 15-20 workdays; customized ovens will cost around 30-35 workdays from the design to the end of the producing process.

7. Q : Whether the voltage and frequency of the oven can be customized?
A: Yes, we can make the voltage and frequency according to your need.（For example: 110V/220V/380V/415V...）

8. Q:What are the heating method available?
A: We have Electrical/Gas/diesel/LPG heating method for choosing.

9. Q: What is the heating time and temperature of powder coating oven?
A: The powder coating oven has to be exposed to a temperature range 160 to 210 (Celsius Degree) for 15-30 minutes.
