Large Battery Bank Dual Studs MRBF Fuse Block Holder Clip Box 58V 500A Max

The Description of Marine Rated Battery Fuses Automotive Marine Battery Fuse MRBF Fuse

Marine-grade, ignition-protected fuse blocks accommodate high amperage MRBF fuses. Suitable for protecting DC main, inverter, windlass, and bow thruster circuits. Mounts on a 3/8" battery post, battery switch or busbar, allowing for easy installation in tight space constraints and satisfies circuit protection rule. Includes insulating cap to prevent accidental shorts.   Surface mount fuse blocks accommodate 1 MRBF fuses, for consolidated high amperage circuit protection. Utilizes marine-grade stainless steel and UV-stabilized plastics, and are ignition protected. Clip-on cover insulates terminal connections and includes label recesses for easy circuit identification.

Advantages Of The Storage Battery Fuse

- Visiable -High quality : Ignition Protection safety devices, safety application,small size,can save installation space of battery main circuit

- High loading capacity: advanced manufacturing technology,professional production skill,strictly materials selected,can withstand current range 30A-500A,breaking class can meet requirements - main circuit protection of large battery pack.

- Imported mateirals: main body is made of Thermoplasticity PPS, good temperature withstand ability,wear-resistant,better conductive for thread & nut made of stainless steel,strong antioxidant,ceramic in fuse can withstand high temperature,anti-oxidation for fuse element made of nickel plated copper,good conductivity and thermal conductivity,great mechanical strength,long life.

- Exquisite design:Insulation caps can prevent short circuits of accidents,dust-proof and reduce performances influnences by environments.Compact design,high current fuse suitable for circuit protection of DC main power supply,inverters,anchor. High current protection in narrow space limited, can be function as Ignition Protection when working with fuse block.The isolated thread uses standard M8 hard metal and allows terminals to stack,available for 5/16'' OT ring terminal, installed on 3/8'' latch.

- Visial melting element: we can see blown situation of melting element via transparent PES plastic housing, current value would be print on the surface of housing clearly,fuse can be sold indivually.

Application

Full range circuit protection for automotive and marine applications. The breaking capacity meets the requirements of conventional vehicle batteries and 12V, 24V and 42V electrical networks. Compact, high-amp fuse appropriate for DC Main, inverters, windlass, and bow thruster circuit protection. Provides high current protection in tight space constraints. Ignition protected when used with MRBF Terminal Fuse Blocks. Isolated stud design uses standard M8 hardware and permits stacking of terminals.

Marine Rated battery Fuses

Designed for the most demanding environment to provide high current protection for the tightest space constraints. Suitable for main and auxiliary circuit protection such as alternator outputs, starter motor inputs and accessory circuits. Alleviates having to make up a short wire to connect to a standard fuse block to the battery. Safe for installation aboard gasoline powered boats. DO NOT mount fuse directly onto battery post. Fuses should be mounted on the MRBF terminal fuse block. (See examples below) Ingress Protection: IP66, protected against powerful water jets Ignition Protected: Per SAEJ1117

Fuse Size List: 30 Amps 40 Amps 50 Amps 60 Amps 75 Amps 80 Amps 90 Amps 100 Amps 125 Amps 150 Amps 175 Amps 200 Amps 225 Amps 250 Amps 300 Amps....500Amps.
