Сетевой видеорегистратор Dahua DH IPC HDW1230T1P A S4 камеры DAHUA с разрешением 2 МП входной ИК фиксированная Фокусное глазного яблока круглые инфракрасные сетевые встроенный микрофон. AI IR POE dahua 2MP камера

Camera

Image Sensor

1/2.8” 2Megapixel progresive CMOS

Effective Pixels

1920(H) x1080(V)

RAM/ROM

64MB/16MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.01 lux F2.0 (Color, 30 IRE)

0.001 lux F2.0 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio

More than 56dB

IR Distance

Distance up to 30m(98.4ft)

IR On/Off Control

Auto/ Manual

IR LEDs

1

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8 mm

3.6 mm

Max. Aperture

F2.0/F2.0

Angle of View

2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°

3.6 mm: Horizontal: 88°; Vertical: 47°; Diagonal: 104°

Focus Control

Fixed

Close Focus Distance

2.8 mm: 0.5 m (1.6 ft)

3.6 mm: 0.8 m (2.62 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

38.6 m (126.64 ft)

15.4 m (50.52 ft)

7.7 m (25.26 ft)

3.9 m (12.80 ft)

3.6 mm

49.7 m (163.06 ft)

19.9 m (65.29 ft)

9.9 m (32.48 ft)

5.0 m (16.40 ft)

PTZ

Pan/Tilt Range

Pan:0° ~360° ;Tilt:0° ~78° ;Rotation:0° ~360°

Intelligence

IVS

NA

Video

Compression

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Streaming Capability

2 Streams

Resolution

Frame Rate

Main stream: 1920 × 1080@1–25/30 fps

Sub stream: 704 × 576@1–25 fps 704 × 480@1–30 fps

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps

Day/Night

Auto(IR-Cut) / Color / B/W

BLC Mode

BLC / HLC /DWDR

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detetion

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image

Support

Smart IR

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

Built-in MIC

G.711A; G.711Mu; G.726

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP

Interoperability

ONVIF, PSIA, CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users / 20 Users

Edge Storage

NAS

Local PC for instant recording

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS,Easy4ip

Smart Phone

IOS, Android
