Оригинальный Пластиковый оптоволоконный кабель AVAGO HFBR 4531/4533 10 мм * 22

 Model

 SM

 MM

 Connector A:SC/APC-FC/APC

 Connector Fiber Count

 8,12,24,48 Core

 Polish

 PC,APC

 PC

 Insertion Loss

 Standard

 ≤0.70dB

 ≤0.50dB

 Elite Low Loss

 ≤0.35dB

 ≤0.30dB

 Return Loss

 PC≥50dB,APC≥60dB

 ≥30dB

 Durability(500 Matings)

 ≤0.2dB

 Test Wavelength

 1310/1550nm

 850/1300nm

 Connector B:LC,LC Uniboot,SC,FC,ST

 Polish

 PC,APC

 PC

 Insertion Loss

 ≤0.2dB

 ≤0.2dB

 Return Loss

 PC≥50dB,APC≥60dB

 ≥35dB

 Durability(500 Matings)

 ≤0.2dB

 Test Wavelength

 1310/1550nm

 850/1300nm

MPO/MTP trunk multicore cable assemblies facilitate rapid deployment of high density backbone cabling in data centers and other high fiber environment, reducing network installation or reconfiguration time and cost, they are used to interconnect cassettes, plane or fan outs. It offered in fiber types in standard 8, 12, 24 or 48 cores versions using a compact and rugged microcables structure.The compact cable optimize cableway use and improve airflow.These MPO/MTP cable are built with highest quality components.Low loss elite versions are offered, featuring low insertion loss for demanding high speed networks where power budgets are critical.

 Fiber type

 SingleMode(G652)

 MultiMode(OM1/OM2/OM3/OM4)

 Connector type

 SC/APC or FC/APC

 Fiber end face type

 PC or APC

 Insert loss

 SingleMode: Typical value (average ) ≤ 0.55dB  Maximum value ≤0.75dB

 MultiMode: Typical value (average ) ≤ 0.65dB  Maximum value ≤0.80dB

 Return loss

 SingleMode: Typical value (average ) > 40dB(PC); >55dB(APC)

 Minimum value >35dB(PC); >50dB (APC)

 Suitable type of optical cable

 Ribbon or bundle cable

 Operation temperature

 -40℃~+ 85℃
