vascular lesions removal 980 nm diode laser vein removal

for All kinds of blood vessel removal

Below is a rf high prequency vein vascular removal machine for you :send enquiry via alibaba for more details and discount !

The 980nm laser pierces the skin and penetrates the superficial blood vessel. The heat

generated from the laser coagulates the blood inside the vessel causing it to collapse

and seal. Over the next few weeks, the vessel will disappear and all the blood will be

removed by the body's scavenging cells. The newer laser treatments allow the delivery

of a precise dosageof energy to each blood vessel without injuring any nearby structures.

Laser can stimulate the dermal collagen growth while vascular treatment, increase

epidermal thicknessand density, so that the small blood vessels are no longer exposed,

at the sametime, the skin's elasticity

and resistance is also significantly enhanced.

Application of Vein Removal Vascular Therapy

(1) Vascular removal: face, arms, legs and the whole body

(2) Pigment lesions treatment: speckle, age spots, sunburn,pigmentation

(3) Blood Clots
(4) Blood Spider clearance
5) Vascular clearance ,Vascular lesions

Advantages for 980nm diode laser for vascular /veins / spider veins removal machine

1. The advanced laser technology for red blood veins/vascular/spider veins removal in

contrast with high frequency in the market.

2. 0.1-15W adjustable energy to satisfy different requirements.

3.Three modes:CW, Single, Repeat

4.Short time operation, no injury, no bleeding, no burning, redness or scar.

5.The obvious effectiveness: Only one or two treatments are required

6. Features:

1). Painless

2). Immediate effects

3). First treatment completely clear

4). No postoperative complications

5). Efficient and safe

6). High patient satisfactions

Technical Specifications
Laser Type                                      Semiconductor laser
Model                                              it+
Wavelength                                   980nm±10nm
Output power                                  0.1W-15W
Operation mode                              CW, Single, Repeat
Pulse width                                     25μs -10s or continuous
Application / Light delivery system    Fixed fiber systems,

Core Size (Use only approved systems)≥200µm, SMA 905 connector
Numerical Aperture                         NA = 0.22 – 0.48
Fiber Connector                             SMA 905
Aiming Beam  Diode laser of 650nm±10nm, 5mW (Max.), adjustable brightness.
Laser Class                                     4

Operation interface                        Color LCD touch screen
Power Supply Model:     FSP105-KGAM1 input: 100-240Vac 1.4-0.7A , 47-63HZ output: 15V 6.79A Max.            Cooling                                          Air cooling
Safety classification                       ClassⅠType B
Dimensions                                   186(W)*172(L)*260(H)mm
Weight                                           2.2 kg
Operating Temperature  10℃~40℃(In order to better heat dissipation, it is recommended to use temperature of 10-35 ℃)Storage/Transport Temperature -10℃ to +50℃
Humidity Storage/Transport : 10% - 80%,
Operating:                                     30% - 60%
Waterproof level                             IPX1

Footswitch Waterproof level           IPX8
Safefy Compliance                         CE 0197

Vascular removal machine heat:

1. Laser is converted into heat
2. Heat is transferred to the vessel wall
3. The thermos chemical acts on the tissue components of vessel wall
4. The vessel wall is destroyed
