Индивидуальное прозрачное круглое кварцевое вафельное Смотровое
5,00 $ - 10,00 $
Новый стиль перфорированный плавленый силикагель штамповка стеклянная пластина Индивидуальный
- Категория: Quartz Plate >>>
- Поставщик: Suining Risen Information Technology Co. ltd.
Сохранить в закладки 1600768296213:
Описание и отзывы
Характеристики
please contact us to check whether have the stocks and accurate price for you.
Why Choose Us
Best Selling
Product Description
Fused Silica Plate Further processing.
We can do edge flame polishing, optical polishing, grind, general polishing, two sides polishing, one side polishing and the other side grind. In a word, we can process as your requirement.
Heat resistant temperature:1200 degree C
We can do edge flame polishing, optical polishing, grind, general polishing, two sides polishing, one side polishing and the other side grind. In a word, we can process as your requirement.
Heat resistant temperature:1200 degree C
1.Fused Silica Plate Size and shape:
The thickness:0.5-50mm Fused Silica Plate: 10-500mm diameter Quartz Sheet MAX Size:1000mm×2000mm(square)
Round, Square, Rectangular and Various shapes available
Used for window material,mask substrate or heat insulation,optics,electronics,medical treatment,laser industries ect.
2.Main product:
We supply all kind quartz product, containing:clear quartz tube, red quartz tube, opaque quartz tube, gold coated quartz tube, quartz substrate, quartz rings and all kinds quartz labware. If you need any of them, please contact us for free.
3.Material
1.JGS1( High-purity UV optical quartz glass)
JGS1 optical quartz glass plate is a very good kind of light transmission glass, because it nearly has no any air-bubbles in glass. At 185nm wavelength, the UV transmission can be up to 90%. JGS1 is generally used in the range of 185-2500nm wavelength.
2.JGS2 (UV quartz glass)
JGS2 quartz glass plate has little air-bubbles in glass, and is generally used as heat-resistant glass. If used as optical glass, its transmission wavelength is 220-2500nm.
3.JGS3 (Infrared quartz glass)
It has a good performance of infrared light transmission with a transmittance of over 85%. It is recommended for applications in the wavelength range of 260-3500nm.
The thickness:0.5-50mm Fused Silica Plate: 10-500mm diameter Quartz Sheet MAX Size:1000mm×2000mm(square)
Round, Square, Rectangular and Various shapes available
Used for window material,mask substrate or heat insulation,optics,electronics,medical treatment,laser industries ect.
2.Main product:
We supply all kind quartz product, containing:clear quartz tube, red quartz tube, opaque quartz tube, gold coated quartz tube, quartz substrate, quartz rings and all kinds quartz labware. If you need any of them, please contact us for free.
3.Material
1.JGS1( High-purity UV optical quartz glass)
JGS1 optical quartz glass plate is a very good kind of light transmission glass, because it nearly has no any air-bubbles in glass. At 185nm wavelength, the UV transmission can be up to 90%. JGS1 is generally used in the range of 185-2500nm wavelength.
2.JGS2 (UV quartz glass)
JGS2 quartz glass plate has little air-bubbles in glass, and is generally used as heat-resistant glass. If used as optical glass, its transmission wavelength is 220-2500nm.
3.JGS3 (Infrared quartz glass)
It has a good performance of infrared light transmission with a transmittance of over 85%. It is recommended for applications in the wavelength range of 260-3500nm.
Product Paramenters
Purity | Total Impurities, including Al, Fe, Ca, Mg, Ti, Cu, Ni,Co, Mn, k, Na, Li, B |
Thermal Data | Annealing Point Strain Point Softening Point Melting Point Expansion Index |
1120°C 1210°C 1570°C 1730°C 5.5×10-7/°C | |
Operation Temperature | Short-term Long-term |
1300°C 1100°C | |
Mechanical Data | Rigidity Modulus Density Mohs Hardness Young`s Modulus Compression Strength Poisson Ratio Elongation Strengtn |
3.1×104Mpa 2.2/cm3 6 7.2×104Mpa >1.1×103Mpa 0.17 48Mpa |
Detailed Images
Grind Quartz Plate
Fire Polish Quartz Sheet
Mini Quartz Disc
Company Introduction
RISEN is one of the leading high quality quartz glass and precise ceramics manufacturer supplier in China.supply all kind quartz product, containing:clear quartz tube, red quartz tube, opaque quartz tube, gold coated quartz tube,quartz substrate, quartz rings and all kinds quartz labware and so on.
1.will replenish Fused Silica Plate or free if it break in the transparent when you entrust us to arranged the delivery
2.perfect repairment system and technical guidance during the usage
3.Give enough suggestion about your design
4.Help making the drawing of OEM Quartz Plates
1.will replenish Fused Silica Plate or free if it break in the transparent when you entrust us to arranged the delivery
2.perfect repairment system and technical guidance during the usage
3.Give enough suggestion about your design
4.Help making the drawing of OEM Quartz Plates
Product packaging
Packing:
1. Special logistics packaging 2. Suitable carton size
3. Shock bubble film 4.Professional placement
5. Professional shock 6. Complete package
1. Special logistics packaging 2. Suitable carton size
3. Shock bubble film 4.Professional placement
5. Professional shock 6. Complete package
Delivery:
Different packing methods according to different products, or we can use customized packing.
FAQ
1.Q: How can I get some samples of Fused Silica Plate?
A: If have sample in stock, we can offer it free. However, you need to afford the freight charge. If it is need to be customized, we will charge you some fees without profit.
2.Q: How can I place the order to you?
A: You can contact us by TraderManage and send the inquiry through Alibaba.Also can place the order on line or through Aliexpress are all ok.
3.Q: How can I pay for you?
A: T/T, L/C, West Union and Aliexpress credit card payment.
4.Q:How to protect my product?
A:We have more than 10 years export experience and have received high recognition and praise from our customers.We have many
skilled workers and they know how to protect the product. During the 10 years, there's no breaking.
5. Q: How to send the product to me?
A: By ocean, air or by express.
6. Q: Can you offer door to door service?
A: We have much experience in door to door service and price is competitive.
7.Q:Which certificates do you provide?
A:ISO, RoHS and CE certificates.
A: If have sample in stock, we can offer it free. However, you need to afford the freight charge. If it is need to be customized, we will charge you some fees without profit.
2.Q: How can I place the order to you?
A: You can contact us by TraderManage and send the inquiry through Alibaba.Also can place the order on line or through Aliexpress are all ok.
3.Q: How can I pay for you?
A: T/T, L/C, West Union and Aliexpress credit card payment.
4.Q:How to protect my product?
A:We have more than 10 years export experience and have received high recognition and praise from our customers.We have many
skilled workers and they know how to protect the product. During the 10 years, there's no breaking.
5. Q: How to send the product to me?
A: By ocean, air or by express.
6. Q: Can you offer door to door service?
A: We have much experience in door to door service and price is competitive.
7.Q:Which certificates do you provide?
A:ISO, RoHS and CE certificates.
